BRICKMAN 300 Stainless Steel

BRICKMAN 300 Stainless Steel

BRICKMAN 300 Stainless Steel

Product catalog summary
Introduction
This document provides an overview of the BRICKMAN 300 Stainless Steel, a compaction machine designed for efficient handling of waste materials such as PET bottles, aluminum cans, and Tetra Paks containing liquid. The machine is noted for its automated operation, compact size, and low noise emission, making it suitable for indoor placement near waste sources.
Specifications
  • Capacity: Up to 170 kg/h for PET bottles and 160 kg/h for aluminum cans.
  • Machine Weight: 1700 kg.
  • Press Force: 25 ton (250 kN).
  • Noise Level: 68 dB(A).
  • Operating Power: 400 V, 3-phase, 50 Hz with a 7.5 kW engine.
  • Protection Class: IP 55.
Design Features
  • Extended press cylinder and automatic greasing for efficient compaction.
  • Reinforced materials in critical components for durability.
  • Stainless steel construction for key parts to handle liquid-filled containers.
  • Optional accessories include different chute options, start systems, and sound absorption plates.
Benefits
  • Automated solution reduces time spent on waste handling, allowing more focus on core activities.
  • Significant volume reduction (up to 20:1) leads to fewer transports and lower costs.
  • Compact dimensions and low sound emission allow for strategic indoor placement.
Logistics and Integration
The BRICKMAN 300 can be easily integrated into existing waste management systems, with features like continuous feeding and optional photocells for automated start functions.
Contact Information
Orwak AB, Svetsaregatan 4, S-576 33 Sävsjö, Sweden. Tel: +46-(0)382-15700, Email: [email protected], Website: orwak.com
See more

Catalog excerpts

BRICKMAN 300 Stainless Steel-1

AUTOMATIC SOLUTION BRICKMAN 300STAINLESS STEEL This version of BRICKMAN 300, with extended cylinder and all vital components made of stainless steel, is designed for effective compaction of large amounts of PET bottles, aluminum cans and Tetra Paks containing liquid. The automated solution is time-saving and convenient. Due to a small footprint and low sound emission, BRICKMAN 300 can be placed indoors close to the source of waste. CAPACITY FILLED PET BOTTLES MORE PRODUCTIVE USE OF TIME Less time spent on waste handling, more time for your core activities! MORE SPACE & ORDER Our balers rapidly minimize the space the waste takes up, keeping aisles free and tidy. LESS COSTS, MORE VALUE More compaction = less waste volume to transport. Fewer transports required results in lower transportation costs and reduced CO2 emissions. Sorting at source yields a higher quality of waste material for recycling. WHY BRICKMAN? ■ Convenient fully automated compaction solution ■ Impressive volume reduction of up to 20:1 ■ Great placement opportunities indoors ■ORWAK' PART OF SULO' GROUP

 Open the catalog to page 1
BRICKMAN 300 Stainless Steel-2

BRICKMAN 300STAINLESS STEEL IS OPTIMIZED FOR: FILLED CAPACITY DESIGNED FOR CONTAINERS FILLED WITH LIQUID Thanks to the following features, this sturdy version of BRICKMAN 300 is especially designed for compaction of bottles, aluminum cans and Tetra Paks containing liquid: ■ Extension on the press cylinder ■ Automatic greasing of the press plate Reinforced material in press chamber, press plate, cutting blades, guide piston and press loop ■ Hopper, all cover plates, shafts, cover plate guilliotine, feeding plate, brackets, machine stand reinforcement, guides, back plate, brake, stand to cover...

 Open the catalog to page 2
