Ortlinghaus – Plates. Clutches. Brakes. Systems. Mechanically actuated clutches

For many years Ortlinghaus mechanical clutches have been extremely popular and problem free. They offer a free choice in terms of the selection of the friction combination and the method of generating the engagement force. They are supplied with the friction combinations steel/steel, steel/sintered lining and steel/organic lining and as a result are suitable for wet-running and dry-running, i.e. they can be used in either an open design or a closed design. Engagement and disengagement of the clutches is by means of a „sliding sleeve“ with a cam profile which is moved axially over resilient angle...

Mechanically actuated multi-plate clutches for wet- and dry-running 1/2 Series 0100 and 0300 The many different design variations of the plate stack, driving housing and actuating elements, makes this clutch versatile for all applications. They are to be found in the transmission systems of construction and agricultural machines. As a double clutch on one common clutch hub, they can be used, for example, to permit a speed change or one of the two sides can be used as a brake. 3 Accessories We can supply the following accessories for manual actuation of the clutches: - Actuation rings which surround...

Fax questionnaire for clutches and brakes Please complete in block capitals! Sender: Name, first name Company Department Telephone (extension) Fax Recipient: Ortlinghaus-Werke GmbH Kenkhauser Straße 125 · Postbox 14 40 42907 Wermelskirchen · Germany Tel. +49 2196 85-0 · Fax +49 2196 855-444 [email protected] · www.ortlinghaus.com for the attention of (if known) Fax-No. +49 2196 855-444 Actuation type: mechanica electromagnetic hydraulic pneumatic spring-loaded Driving machine: Electric motor Combustion engine Hydraulic motor Other:__________________________ Transmission situation: __________________________________________________________________________...
