IDS-5011-WG

Product catalog summary

Introduction
The IDS-5011-WG is a secure industrial device server that converts serial data to IEEE 802.11b/g wireless communication. It supports high-speed WLAN connectivity up to 54Mbps and features a single RS-232/422/485 port and a 10/100Base-T(X) LAN port. The device offers multiple operating modes including Virtual Com, Serial Tunnel, TCP Server, TCP Client, and UDP, making it versatile for various applications.

Key Features

High-Speed Connectivity: Supports WLAN interface with up to 54Mbps link speed.
Operating Modes: Includes Virtual Com, Serial Tunnel, TCP Server, TCP Client, and UDP.
Security: Features SSL data encryption, HTTPS, SSH, and IP access control with IP white lists. Supports WEP/WPA/WPA2/802.1X/TKIP for wireless security.
Redundancy: Can connect to up to 5 host devices in Virtual COM and TCP modes, and 4 IP ranges in UDP mode.
Management: Configurable via web-based interface and Windows utility (DS-Tool). Supports NAT Pass-Through, DDNS, and PPPoE for remote management.
Power Supply: Dual redundant power inputs (12~48 VDC) ensure continuous operation.
Environmental Robustness: Operates in temperatures from -10 to 65°C and features an IP-30 rated enclosure.

Technical Specifications

WLAN Features: Supports IEEE802.11b/g standards with DSSS and OFDM radio frequency types. Transmission rates vary from 1 to 54 Mbps depending on the standard.
Serial Ports: Configurable RS-232/422/485 modes with baud rates from 110 bps to 230.4 Kbps.
Network Protocols: Supports ICMP, IP, TCP, UDP, DHCP, BOOTP, SSH, DNS, SNMP V1/V2c, HTTPS, SMTP, SSL, PPPoE, and DDNS.
Physical Characteristics: Dimensions are 72 x 29.4 x 123.4 mm, and it weighs 346 g.
Environmental Specifications: Storage temperature ranges from -40 to 85°C, and operating humidity is 5% to 95% non-condensing.

Regulatory Approvals

EMI: Complies with FCC Part 15, CISPR (EN55022) class A.
EMS: Meets EN61000 standards for ESD, RS, EFT, Surge, CS, and more.
Safety: Certified under EN60950-1.

Accessories and Options

Includes DIN-Rail Kit, Wall-mount Kit, 2dBi Antenna, ORing Tool CD, and Quick Installation Guide.
Optional accessories include various power supplies, WLAN RF Antenna Series, and RF Surge Protector Series.

Catalog excerpts

Industrial Device Server 1-Port Wireless Device Server > Industrial 1-port secure serial to IEEE 802.11 b/g wireless device server with 1xRS-232/422/485 and 1x10/100Base-T(X) High Speed Air Connectivity : WLAN interface support up to 54Mbps link speed Operating Modes : Virtual Com, Serial Tunnel, TCP Server, TCP Client, UDP Redundant multiple host devices : 5 host devices : Virtual COM, TCP Server, TCP Client mode NAT Pass-Through : the user can manage IDS-5011-WG through NAT router High Security Capability : SSL data encryption ; secured management by HTTPS and SSH ; IP Access : IP White List ; wireless : WEP/WPA/PA2/802.1X/TKIP Internet Communication : PPPoE authentication Update DNS Hostname : DDNS Event Warning by Syslog, Email, SNMP trap, and Beeper Configurable by Web-based and Windows utility (DS-Tool) Various Windows O.S. supported : IDS-5011-WG is an innovative secure 1-port RS232/422/485 to 802.11 b/g WLAN, up to 54Mbps, and 1-port LAN device server featuring the standard features of device server, such like TCP/IP interface and versatile operation modes : Virtual Com, Serial Tunnel, TCP Server, TCP Client, UDP. In addition, the Windows utility, DS-Tool, could configure multiple devices and set up the mappings of Virtual Com. The features of NAT Router Pass-Through, DDNS, and PPPoE make it more convenient for administrators to configure ORing's device servers through NAT router from different IP domains or Internet via modem remotely. On the other hand, IDS-5011-WG can simultaneously transfer data up to 5 redundant host PCs to aovid Ethernet connection breakdown or any host PC fails. Further, IDS-5011-WG features HTTPS, SSH, SSL encryption, and 802.1X to assure the security of critical data transmission. IDS-5011 -WG supports RS-232/422/485 and provides dual redundant power inputs, 12-48 VDC, on DC power jack and terminal block to guarantee a non-stop operation. With wide operating temperature, -10~65°C, and rugged IP-30 housing design, IDS-5011 -WG could operate in the harsh industrial environment. Therefore, IDS-5011 -WG is the best solution to the high demand of secure serial to WLAN critical data communication. Practical Operation In practical operation of serial device servers, Windows utility (DS-Tool) is supported. This utility is very helpful for you to manage and monitor all of industrial device servers in the industrial network.

Open the catalog to page 1

Industrial Device Server 1-Port Wireless Device Server v1.4 / Nov, 2010 Company Information WLAN LAN Serial Data Encryption IDS-5011-WG RS232/422/485 Credit Card Machine 2011 Product Overview IAP-120 IAP-120 WLAN Serial Data Encryption IDS-5011-WG Vertical Market Applications SSL Data Encryption Wireless Client Mode IDS-5011-WG RS232/422/485 TCP Client IDS-5011-WG RS232/422/485 TCP Server IDS-5011-WG RS232/422/485 PPPoE and DDNS TCP Client / Server Modes Industrial Media Converter WLAN Serial Industrial Ethernet Switch WLAN Serial Industrial Device Server Industrial Wireless Access Point DS-Tool...
