Asynchronous Motors with IP67 FPW Series
20Pages

Overview, Product Series Constant Speed Motors Single-Phase Induction Motors Watertight, Dust-Resistant Motors Three-Phase Induction Motors Reversible Motors Electromagnetic Brake Motors Torque Motors Watertight, Dust-Resistant Motors Watertight, Dust-Resistant Motors Brake Pack

C-142 Watertight, Dust-Resistant Motors FPW Series Induction Type •Geared motors that conform to IEC Standard IP67. •Suitable for use in locations where the equipment is splashed or needs to be washed with water periodically. •Output powers of 25 W, 40 W, 60 W and 90 W are available. ■Features ●Watertight and Dust-Resistant Performance IP67 The FPW Series motors are watertight, dust-resistant geared induction motors which conform to the IEC Standard IP67. They can be used where they are splashed with water. ●Designed and Constructed for Watertight and DustResistance Special anti-corrosive...

System Configuration Overview, Product Series Constant Speed Motors Single-Phase Induction Motors Three-Phase Induction Motors •System Configuration Example ■ Product Number FPW 4 25 C 2 - _5 E © © ® © © © © • The product name listed on the motor nameplate does not include the code (E) that indicates the type of capacitor. Certification regarding various safety standards is acquired for the product name on the motor nameplate, please visit www.orientalmotor.eu. (Example) Product Name: FPW425C2-15E ^ Motor nameplate and product approved under various safety standards: FPW425C2-15

Watertight, Dust-Resistant Motors ■Product Line For the single-phase 100 VAC, the single-phase 110/115 VAC and the single-phase 200 VAC models, please contact the nearest Oriental Motor sales office. TP: This indicates that there is a built-in thermal protector (automatic return type). If a motor overheats for any reason, the thermal protector is activated and the motor is stopped. When the motor temperature drops, the thermal protector closes and the motor restarts. Be sure to turn the power supply off before inspecting. •The values for each specification are the characteristics for when...

■General Specifications Item | Note • Since these are special watertight, dust-resistant geared motors, the motor and gearhead sections cannot be disassembled. • The capacitors for the motors are neither watertight nor dust-resistant. Overview, Product Series Constant Speed Motors Single-Phase Induction Motors Three-Phase Induction Motors Reversible Motors • A number indicating the gear ratio is entered where the box □ is located within the product name. • The speed is calculated by dividing the motor's synchronous speed (50 Hz: 1500 r/min, 60 Hz: 1800 r/min) by the gear ratio. The actual...

C-146 Watertight, Dust-Resistant Motors ■Permissible Radial Load and Permissible Axial Load Product Name FPW425 Type FPW540 Type FPW560 Type FPW690 Type Permissible Axial Load N 50 100 150 200 ■Permissible Inertia J Product Name Gear Ratio 3 FPW425 Type 2.79 FPW540 Type 6.75 FPW560 Type 9.9 FPW690 Type 18 ● Mounting screws are included. ● A number indicating the gear ratio is entered where the box □ is located within the product name. ◇Key and Key Slot (Included) Motor Cable UL Style 2517 30 ϕ7.8, 2000 mm Cable Cores: 3 Motor Leads UL Style 3266, AWG20 1 Protective Earth Lead UL Style 3266,...

C-147 •60 W O Geared Motor FPW560C2-DE, FPW560S2-D Motor: FPW560C2-D, FPW560S2-D Mass: 5.0 kg Overview, Product Series Constant Speed Motors Single-Phase Induction Motors Three-Phase Induction Motors Reversible Motors •90 W O Geared Motor FPW690C2-DE, FPW690S2-D Motor: FPW690C2-D, FPW690S2-D Mass: 7.5 kg Electromagnetic Brake Motors Torque Motors Watertight, Dust-Resistant Motors Brake Pack O Mounting Screws (Material: Stainless Steel) • 4 flat washers and hexagonal nuts are included.

C-148 Watertight, Dust-Resistant Motors ◇Capacitor (Included with single-phase motors) Dimensions Number ① ◇Capacitor Dimensions (mm) Product Name FPW425C2-□E FPW540C2-□E FPW560C2-□E FPW690C2-□E ●A capacitor cap is included with the capacitor. ●A number indicating the gear ratio is entered where the box □ is located within the product name. ■Connection and Operation ● The rotation direction of the motor is as viewed from the output shaft of the motor. CW represents the clockwise direction, while CCW represents the counterclockwise direction. ● The connection method varies with the output...

Overview, Product Series Constant Speed Motors Single-Phase Induction Motors Three-Phase Induction Motors Reversible Motors Electromagnetic Brake Motors Torque Motors Watertight, Dust-Resistant Motors Brake Pack Motor and Gearhead Mounting Brackets················ C-154 Flexible Couplings ··················································· C-158 Watertight Power Relay Box ··································· C-163 Watertight Extension Cables ········

Mounting Brackets Torque Arms This is an aluminum die cast mounting bracket for gearheads and geared motors. There are also high-strength models available for high-power motors and gearheads. Long, horizontal holes make it easy to make fine adjustments during installation. ■ Product Line Material: Aluminum alloy Surface treatment: paint • Standard AC Motors, Speed Control Motors •Select the pinion shaft type based on the gearhead to be attached. Extension Cables CR Circuit for Surge Suppression • Letters are provided in the applicable products table for identifying the series. | Note • Not...
