IM•compact_M

IM•compact_M

Product catalog summary

Overview: The document provides specifications for the IM•compact M Machine Vision Microscope, available in USB 3.1 and GigE versions. It includes details on integrated lighting, field of view (FoV), working distance (WD), sensor type, and image interface.

Specifications:

USB 3.1 Version: Features integrated coaxial and ring light, with various configurations based on FoV, WD, and sensor type (Colour or Mono). The sensors used are Sony IMX264 (5.01 MP) and IMX265 (3.19 MP).
GigE Version: Similar configurations as the USB version, but with a GigE RJ45 interface and 24V M8 Plug 4pol connection.

Key Features:

Integrated optics and lighting for brightfield and darkfield imaging.
Plug & play functionality with OptoViewer software.
Robust, compact design with aluminum housing.
Long working distance and high numerical aperture objectives for high contrast and resolution.

Compliance and Software: The device complies with CE, RoHS, and WEEE regulations and includes OptoViewer software for ease of use.

Additional Information: Specifications are subject to change by March 2024. Contact details for Opto GmbH are provided for further inquiries.

Catalog excerpts

Imaging Modules • compact M IM^compact MMachine Vision Microscope For measuring instruments, analysis-, bio- and imaging systems Camera with integrated optics and light Brightfield and darkfield in one unit Plug & play with free OptoViewer software Robust, one cable, aluminum housing, ultra compact USB 3.1 with Sony IMX Pregius sensor Long WD, high NA objectives IM^compact M - USB Version Integrated coaxial and ring light Item number Image sensor: IMX264 | 5.01 MP / Sony Pregius sensor IMX265 | 3.19 MP Weight [g]: 700 | CE / RoHS / WEEE-Reg.-No. DE 68564667 | OptoViewer software included Opto GmbH • Floriansbogen 2/4 • 82061 Neuried • Germany • Tel: +49 89 8980 55 0 • [email protected]

Open the catalog to page 1

Specification • GigE IM^compact M - GigE Version Integrated coaxial and ring light Opto GmbH • Floriansbogen 2/4 • 82061 Neuried • Germany • Tel: +49 89 8980 55 0 • [email protected]

Open the catalog to page 2
