Part number: 043-610022
Focus Drive OC Coarse / Fine
- Travel Range: Coarse focus 70mm (+35/-35mm); Fine focus 0.24mm (288 rotation).
- Fine Focus Mode: Activates after a direction change in coarse focus and remains active within 288 rotations.
- Scale on Knob: 100 sections, with each section corresponding to 2.9µm in fine focus.
- Dimensions: 50 x 99 x 125mm.
- Weight: Approximately 1.2 kg.
- Maximum Load: 15 kg.
Accessories
- Adapter plate for wall and Track Stand (Part number: 043-610904-002).
- Clamp for Ø 32 mm column and Post Stand (Part number: 043-610904-320).
- Clamp for TV Microscope Ø 35mm (Part number: 043-610911).
Additional Information
- Opto Imaging Modules attach directly with optimized clamps.
- Suitable for objectives with magnification up to 50x.
- Features a combined focus drive for coarse and fine alignment.
- Includes a freewheel mechanism at the end of the travel range to prevent damage, requiring manual re-engagement.
Contact Information
Opto GmbH, Floriansbogen 2/4, 82061 Neuried, Germany
Tel: +49 89 8980 55 0
Email: [email protected]
Website: www.opto-gmbh.com
Catalog excerpts
J^)tO Focus Drive OC, Coarse / FineFokussiertrieb OC, Grob / Fein Technical Features Part number 043-610022 Opto Imaging Modules attach directly with the optimized clamps delivered with the IM * The side has a freewheel at the end of the travel range to prevent damage to the drive. It should therefore be noted that the drive drops down approx. 1mm at the end of the lower travel range. The drive must then be pushed up again manually to re-engage. 09/2023 - Specifications are subject to change without prior notice. Opto GmbH • Floriansbogen 2/4 • 82061 Neuried • Germany • Tel: +49 89 8980 55 0 • [email protected]
Open the catalog to page 1
Technical Drawing Detailed drawing on request www.opto-gmbh.com Opto GmbH • Floriansbogen 2/4 • 82061 Neuried • Germany • Tel: +49 89 8980 55 0 • info@
