True Zero Backlash Օ 400% Shock Load Capacity Exceptional TorsionalStiffness Օ Rigid Bearing Construction Smooth, Quiet Operation > Օ Unique Cam Design Allows for MoreThan 50 Standard Ratios Same Low Profile Design Regardless of Ratio Օ Integral Output Bearing > Balanced Cam for Higher Speeds Օ Low Inertia High Safety Factor Օ Input Speeds to 6000 rpm Great for High Reversing Applications > 1ONVIO Օ Zero Backlash Speed Reducers www.onviollc.com size="-1">

In applications that demand the greatest positioning accuracy, highest torsional stiffness,and lowest backlash, Onvio's Dojenٙ, with its compact axial design, is the only choice. Choose from the following options Nine Frame Sizes > Diameters from 4 inches up to 19 inchesՕOutput Torques from 100 Lb-in to over 100,000 Lb-in Input speeds to 8,000 RPM Widest Ratio Range Available > Օ49 Ratios Available 9:1 up to 256:1 ՕStacking stages not required Modularity > Add OnvioՒs Right angle reducer for applications where axial space is crucial Add a planetarystage and create ratios of 256,000:1 and...

Onvio reducers are designed with cantilevered needle bearing cam followers and rollersnot with pins and bushings found in other cycloidal designs. This allows for a con-trolled pre-load between the cam andcam followers, assuring zero backlash. Pre-load is maintained throughout the design life of the reducer.Every cam follower is in contact at alltimes, the load is equally shared. This guarantees consistently high torsional rigidity independent of load position.With a high capacity output bearingand output flange, Onvio's cycloidal reducer can support most loads. Machine designs are...

Zero Backlash Speed Reducers 4 >

3 times the power in the same diameterՕ Full complement output bearing Higher ratios՗up to 256:1 Higher input speeds՗up to 4500 rpm Greater positioning accuracy (ձ330 arc seconds) Thru-hole capability > ModelDiameter A Length BWeight No. Inch mmInch mmLbsKgM247.250184.155.38136.653515.91 > ModelPilot Diameter C > 1 Pilot Depth FThread Size Bolt CircleNo. of No. Inch mmInch mmInch mmInch mm holes M245.999152.370.8822.351/4-28 UNF x .56 dp M6 x 1.00 x 14.2 dp 6.500165.10012 > Mount Face to Load FaceLength E ModelPilot Diameter D > 2 Pilot Depth GThread Size Bolt CircleNo. of No. Inch mmInch...

Standard Grease Extreme Cold Temps Extreme High Temps > 1 1 The Dojen is grease lubricatedand sealed for life. However, in some high cycle applica- tions or in environments that can prematurely cause lubri- cant to breakdown, we rec- ommend purging old grease with fresh new grease. The reducer is equipped with grease ports on the outer diameter. Contact Onvio cus- tomer service for lubrication procedures and available equipment. Model 02Shell Alvania IIAmoco Supermil Magnalube G1/3 Model 03Shell Alvania EP1Amoco Supermil > 1 Magnalube G1/3 > 1 Model 04Shell Alvania EP1Amoco Supermil > 1...

Perfect for direct mount-ing in close quarters to a servo motor. Օ No keyways, no backlash. Specify motor shaft diam-eter when ordering.Օ Motor sleeves providedfor any motor shaft diam- eter smaller than the maximum shaft diameter. Eliminates costly couplings. > Օ Has fully supported input shaft. Removes radial load frommotor bearings. Օ Ideal for shaft-to-shaft couplings, pulleys, gears, etc. Allows reducer to be usedas a speed increaser in specified ratios. Օ Both metric and inch sizes. Thru-holes available for routing wires, etc. >

ModelShaft Diameter Shaft Length Keyway Keyway LengthNo. Bolts directly to output face. Օ Ideal for shaft-to-shaft couplings,pulleys, gears, etc. Available in aluminum or steel. Օ Nickel plating available for wash-down compatibility. Both metric and inch sizes. Օ Thru-holes available for routingwires, etc. Inch Metric Inch Metric Inch Metric Inch MetricM020.62516 mm1.25030 mm.1875 x 5 mm1.00024 mmM030.87522 mm1.37535 mm.2506 x 6 mm1.12530 mm M041.25032 mm2.37560 mm.31210 x 8 mm2.00055 mm M051.50040 mm2.75070 mm.37512 x 8 mm2.37565 mm M062.00050 mm3.37585 mm.50014 x 9 mm2.87580 mmM242.00050...

Torque-in.-lbs.X Collet Centerline 0.53 0.62 0.83 0.97 .831.06 1.19 1.19 1.45 > Note: Use Loctite on all hardware.1. Insert allen wrench into the colletcollar before sliding the motor shaft into the input shaft of the reducer. This will cause proper positioning of the collar for later tightening.2. Tighten flange bolts of the motorto the flange and to the reducer before tightening collar. Use a crossing pattern when tightening all bolts to minimize axial load on the input shaft.3. Tighten collar according to recom-mended torque specs above.4. The load coupling can be trued up,match...

Reserved for SpecialConsult FactoryInput Shaft:N > Model:DM = Collet Shaft = Dojen Mechanical S = Straight Shaft DE = with Integral Servo F = Special Shaft DB = with Servo and Brake Size: Grease:0 Ratio: 020510 030612 040824 See data for availabilityExample Ratio 055 = 55:1, 225 = 225:1 = Standard Grease 1 = Low Temp Grease 2 = High Temp Grease Finish:B Thread Size: E = Black Oxide = Inch N = Electroless Nickel M = Metric > 17ONVIO ҕ Zero Backlash Speed Reducers www.onviollc.com size="-1">

Planetary Timing Pulleys Right Angle Power Pulley Power Roller Planetary Right Angle > Onvios revolutionary, modularapproach to gearbox design has resulted in three unique families of products that offer the right per- formance and value for any applica- tion. The modular concept allows Onvio to provide complete OEM solutions quickly and economically. In keeping with OnvioҒs modularconcept, the right angle module is a self contained, helical bevel stage that can bolt directly on to all of Onvios AP series products. This module provides ratios of 1:1, 3:1 and 5:1 as a standalone gearbox or...
