Product catalog summary

Overview
Omron provides a variety of vision systems and sensors aimed at industrial automation, prioritizing ease of use, flexibility, and cost-effectiveness. These systems are designed for process engineering with minimal investment and straightforward installation.

Smart Vision Sensor ZFV
The ZFV is a scalable vision system in a sensor format featuring an integrated LCD monitor for intuitive setup. It supports up to five controllers and is available in both grayscale and color versions. Key features include up to eight inspection tools, an adjustable field of view from 5 to 150 mm, and a cycle time as low as 4ms.

Intelligent Sensor F160
The F160 offers high-speed image acquisition and processing, including Optical Character Recognition (OCR) and verification tools. It supports two camera connections and provides a configurable user interface with password protection.

Mid-range Vision System F210
Designed for quality inspection, the F210 includes powerful algorithms like Edge Code technology and a Fine Matching tool. It offers macro programming for customization and supports two camera connections.

High-speed Vision System F250
The F250 features new Edge Code technology for high-resolution inspections and supports four camera connections. It includes advanced algorithms for precise detection and offers Ethernet connectivity for network integration.

Network-ready Vision Systems F500 & F210ETN
These systems are equipped with Ethernet ports for high-speed data transfer and support high-resolution cameras. They feature advanced inspection tools and optional PC-based configuration software.

2D Code Readers
The V400 is a handheld reader with a built-in screen for easy targeting and feedback. It reads direct marked codes on various surfaces and supports data logging via an SD card. The V530-R160 is a fixed reader designed for highly degraded codes, offering reliable reading and quality analysis features.

Specifications and Features
The vision system supports 360° monitoring, trend monitoring, and statistics functions for quality feedback. It can store 35 images internally and up to 400 images per compact flash card. Configurations can be stored in non-volatile memory, with over 1,000 configurations possible using a compact flash card. Communication is facilitated via RS232/422 and 11 digital I/Os. The system can read 2D codes directly marked onto objects, enhancing traceability management even on non-uniform backgrounds.

Vision Systems Overview
The document provides an overview of various vision systems and sensors, including types ZFV, ZFV Colour, F160, F210, F250, and F500/F210ETN. These systems vary in tools, cameras, scenes/banks, and interfaces, supporting different network capabilities, including Ethernet and Vision Composer Net software.

Lighting and Engineering Support
Omron offers support in selecting appropriate lighting systems for vision applications, emphasizing that no universal lighting system fits all applications. The document highlights the importance of service and support, offering workshops and training as part of their service package. The F-series controller menus allow operators to control lighting conditions easily, with settings stored as numeric data for consistency across machines.

2D Code Readers
The document describes two types of 2D code readers: V400-H Handheld and R160 Fixed Station, both capable of reading Data Matrix and QR codes. The R160 model includes two cameras and interfaces via RS232 and 11 digital I/Os.

Contact Information
Contact details for Omron representatives across various countries in Europe and the Middle East are provided, ensuring accessibility for customer support and inquiries.
