Power and Torque Diagram Overview

The document provides a diagram illustrating the relationship between power output, torque, nominal speed, and frequency for an electrical device operating at 380V.

Key Specifications

• Rated Output Power (P): Values include 6 kW, 7.5 kW, and 8 kW.
• Voltage (U): 380 V.
• Nominal Torque (Mt): Corresponding torque values are 200 Nm, 253 Nm, and 266 Nm respectively for the power ratings.
• Nominal Speed (n): Expressed in thousands of revolutions per minute (x1000 min⁻¹), with values around 6, 7.5, and 8.
• Frequency (f): Frequencies associated with the nominal speeds are 6 Hz, 7.5 Hz, and 8 Hz.

Current Ratings

• 15 A (S1) at 300 V for certain operating points.
• 22 A (S1) at 300 V for higher power or torque conditions.

Additional Information

The diagram and data appear to be related to continuous duty operation (S1). The nominal speed and frequency values indicate the operating range for the device.

Manufacturer Contact Details

Headquarters: 12040 Ceresole d'Alba (CN), Italy
Address: Via Carmagnola, 24
Phone: +39 (0) 0172 575000
Fax: +39 (0) 0172 575003
Email: [email protected]
Websites: www.omlat.com, www.omlatusa.com, www.directindustry.it/tab/omlat.html
