Grinding Fluids
20Pages

Grinding Fluids High-performance lubricants for tool production

Philipp and Martin Storr • Managing Directors Your partner for metalworking fluids oelheld is a medium-sized company, which has more than 130 years of tradition and experience. Since the foundation in 1887 by Carl Christian Held, oelheld has become an established specialist for lubricants. Partnerships, research, and human resources technology have grown as a valuable tradition of which we are proud of. Numerous customers and machine manufacturers along with national and international universities have partnered with us to develop high quality lubricants. Through this cooperation we are...

Human Technology innovations for man, environment and machines Hutec is our main focus in the development and production of our products. It is also our mission statement in our use of resources and at oelheld always presence. What does this mean? • REACH requirements are fulfilled • Skin reviews and approvals available for most products • Low emission and aromatics free / low aromatic products • Products free of heavy metal • State-of-the-art production facilities • Environmentally friendly production processes • Products are tested for compatibility with machine components •...

The right grinding oil for every machine oelheld has earned a reputation for proven, unrivalled high-end metalworking fluids designed to meet the highest requirements. The constantly growing need for increased productivity, cost efficiency and optimal utilization of existing production capacities makes it necessary to continuously optimize all process influencing factors. The selection of the right grinding oil is particularly important, as it has a major influence on productivity, production costs, process stability and ultimately the quality of the tools produced. In our own R&D...

Manufacturer approvals Our products are specially designed for use with: sharp solutions? 0SMS strausah Cstuder V g ajm Rallofnatic Group

Your advantages when using our grinding oils Increased productivity Optimized surface quality Increased grinding wheel service life Inhibitors to prevent cobalt leaching Co-leaching

Improved release time of entrained air Your way to the perfect tool! Conclusion By choosing the right grinding fluid you not only save time and money, but you eliminate your other concerns so you can focus on manufacturing. Improved filterability

Your strong partner In-house production! Worldwide availability! Seminars and training available! Personal consulting! Laboratory service! Protecting employee health!

Structure of grinding oils Grinding oils consist of a base oil and additives and oelheld uses only the best ingredients. With more than a 130-year-old tradition in the production of high quality metalworking oils this guarantees you the maximum performance out of your grinding process. Base oils Hydrocrack (HC), gas-to-liquid (GTL) and polyalphaolefins (PAO) are available, which have the characteristics of good air separation and low foam formation. All base oils used are colorless, odorless, dermatologically tested and very low in misting. mineral oil air release: 60 seconds hydrocrack...

Product overview Material: carbide and steel < 30% SintoGrind TTK SintoGrind TTS SintoGrind TC-X 630 Grinding oils for the machining of carbide and steel of < 30% These grinding oils are suitable for flute grinding, profile grinding, external and internal cylindrical grinding of carbide, HSS, CBN, PCD, cermet and ceramics. If you are primarily grinding carbide, then following products are available: ToolGrind TC-X 620 Technical data Testing method Density at +15 °C (g/cm³) Kin. viscosity at +40 °C (mm²/s) Flashpoint (°C) Copper corrosion For other materials and applications please contact...

Flashpoint (°C)>150DIN EN ISO 2592 Copper corrosion 1a DIN EN ISO 2160 Flashpoint (°C)>150DIN EN ISO 2592 Copper corrosion 1a DIN EN ISO 2160 Flashpoint (°C)>150DIN EN ISO 2592 Copper corrosion 1a DIN EN ISO 2160 Flashpoint (°C)>150DIN EN ISO 2592 Copper corrosion 1a DIN EN ISO 2160

Product overview Material: carbide and steel > 30% Grinding oils for the machining of carbide and steel > 30% These grinding oils were developed for flute grinding, thread grinding, profile grinding, as well as external and internal cylindrical grinding of steels such as HSS, PM and medical steels. Surface burning and burr formation are successfully prevented. In addition, these grinding oils are also designed for machining carbide, PCD, CBN, cermet and ceramics. If you are primarily grinding HSS and carbide, then following products are available: ToolGrind TC-X 1000 Technical data Testing...

Flashpoint (°C)>150DIN EN ISO 2592 Copper corrosion 1a DIN EN ISO 2160 Flashpoint (°C)>150DIN EN ISO 2592 Copper corrosion 1a DIN EN ISO 2160

Product overview Grinding oils for machining steel / HSS These grinding oils have been developed for flute grinding, thread grinding, profile grinding as well as external and internal cylindrical grinding of steels such as HSS, PM and medical steels. Surface burning and burr formation are successfully prevented. Since the grinding oils are specially designed for high-performance grinding of steels, materials such as carbide, PCD, CBN, cermet and ceramics should not be machined. If you are primarily grinding HSS and other steels, then following products are available: ToolGrind HSS-X 1400...

Innovative technology had made two machines into one by combining grinding and spark erosion. This saves time and money. That's why oelheld developed the IonoGrind specialty fluid for this process. IonoGrind is a multifunctional fluid that is equally suitable as a grinding oil and for spark erosion. It was designed for use in combination machines (two in one) and combines the advantages of a low-foaming and low-evaporation high speed grinding oil with a high-performance dielectric for extraordinarily high erosion rates and surface quality. IonoGrind is the right fluid for grinding PCD...
