Floorcare Catalogue

Product catalog summary
Introduction
The document outlines the evolution of floor maintenance, focusing on the significance of maintaining cleanliness standards across various environments. It highlights the role of single disc rotary floor machines in achieving these standards.
Product Overview
Several models of floorcare machines are introduced, including the Loline, NuPower, and NuSpeed ranges, each designed to meet different floor maintenance needs with specific features and specifications for efficient performance and user satisfaction.
Loline Range
The Loline range, featuring models like NLL332 and NLL415, is designed for compactness and ease of use. These machines are lightweight, easy to store, and offer high performance with various brushes and pad drives.
NuPower Range
The NuPower range includes models such as NPR1515, NPR1523, NPR1530, and NPR1545, equipped with powerful motors and features like Automatic Torque Control (ATC) for consistent performance in tasks ranging from scrubbing to polishing.
NuSpeed Range
The NuSpeed series, including models like NR1500 and NRL1500, offers increased power output and weight for handling large areas, featuring ATC for consistent performance and various speed settings for different floor maintenance tasks.
Key Features and Specifications
Each machine is detailed with specifications such as motor power, brush size, operating speed, and weight. Features like optional dust filters, solution tanks, and various brush and pad options enhance versatility and performance.
Conclusion
The document emphasizes selecting the right equipment for specific floorcare tasks to achieve optimal results, considering both application needs and operator capabilities for satisfaction and efficiency.
Specifications
Detailed specifications for various floorcare machines, including the NuSpeed Spraytec NRS450 and NuSpeed Ultra NRU1500, are provided. Key specifications include motor power, disc brush size, speed, vacuum range, weight, and dimensions.
Features and Innovations
The NuSpeed Ultra series is noted for features like the automatic floating head pad drive and Automatic Torque Control (A.T.C), enhancing performance by adjusting to floor conditions and boosting torque as needed. The Dustrol vacuum system can be retrofitted for combined vacuuming and polishing.
Accessories
A comprehensive list of accessories is provided, including various brushes, pad drive boards, and optional kits like the Dustrol Kit and Spraytec Kit, categorized by compatibility with different models and specific functions.
Twintec Range
The Twintec range offers scrubber dryers for different applications, from compact models like the TT1535S for small areas to larger models like the TT6650S for big area maintenance, designed with ease of use in mind.
Battery and Charger Systems
Numatic Twintec products feature maintenance-free gel batteries and matched chargers for long operational life, with guidelines for proper battery care to extend battery life and maintain performance.
Battery Care Guidelines
  • Recharge batteries after every use, regardless of usage duration.
  • If unused for 30 days or more, fully recharge and isolate the battery by removing fuses.
  • Replace fuses and recharge every 3 months as part of maintenance.
Twintec 3450 Series Overview
  • Features a stainless steel chassis, tilting power head, and adjustable battery system with built-in charger.
  • Models include TTB3450S, TTB3450T, TTB3450C, and TTB3450CRS, each with a 30L capacity, 450mm deck, and 2.25-hour runtime.
  • TTB3450T includes twin 15-litre tanks for easy emptying.
  • TTB3450C offers a cylinder power brush for deep cleaning in narrow spaces.
Twintec 4552 Series
  • Mid-range twin-brush machine with stainless steel chassis and ABP system.
  • TTB4552S and TTB4552ST models offer 40L capacity and 550mm cleaning path.
  • TTB4552ST includes a 24V power-drive traction system for enhanced maneuverability.
Twintec 6652 Series
  • Large capacity machines with 60L tanks and twin brush systems.
  • Models TTB6652S and TTB6652T offer 100Ahr or 200Ahr battery options for extended runtime.
  • TTB6652T features a traction system for improved handling.
Twintec Vario TTV678
  • Ride-on model with adjustable working widths (650mm, 750mm, 850mm) and customizable settings.
  • Features include variable cleaning speed, brush speed, and water flow control.
  • Offers extensive versatility with programmable presets and optional battery packs.
Accessories
  • Various brushes and pad drive boards available for different models.
  • Additional kits include floor kits, hose extensions, and replacement blade sets.
Product Specifications
  • Urethane Blade Sets: Available for models TT3450/TTB3450/TT4550/4552 and TT6650/TTB6652, with sizes of 850mm and 650mm respectively.
  • Battery Pack: TTA606167 Xtra Twin 100Ah Battery Pack and Connection Kit.
  • Brushes: Various 300mm Octo brushes including Nyloscrub, Longlife, Polyscrub, and Drive Board, each requiring three pieces.
  • Floor Nozzles: Available for different models with sizes of 650mm and 850mm.
Accessories
  • Optional Floor Nozzles and Dosing Tank Assembly for TTV678.
  • Battery LED Front Light Kit and Wander Floor Kit for TTV678.
  • 38mm Emptying Hose Extension for TTV678.
  • 20m Cable Roll Extensions available for UK and Euro standards.
General Information
  • Photographs may include extra items for illustration purposes only.
  • Specifications are subject to change without prior notice.
Contact Information
  • Numatic United Kingdom, France, Germany, Netherlands, and South Africa contact details provided for customer support and inquiries.
See more

Catalog excerpts

Floorcare Catalogue-1

Photographs may include extra items for illustration purposes only.

 Open the catalog to page 1
Floorcare Catalogue-2

Floors, Floors be The development of floors and flooring materials within the broad range of commercial developments has been very pronounced over the past decade. Not only have floors become more exotic in both design and material selection but, equally, we all expect to see the floor maintained to any exceptionally high standard, literally sparkling clean, in high profile locations; super clean in the workplace and public space... just as we would expect in our own living space. Single disc rotary floor machines constitute the very foundation of hard floor maintenance and by the correct selection...

 Open the catalog to page 2
Floorcare Catalogue-3

beautiful Floors... The Numatic LoLine, NuPower and NuSpeed machine ranges provide a selection of models and specifications to suit the majority of standard, and many specialized, applications ensuring highly efficient performance, excellent results and total operator satisfaction. The old adage is as meaningful today as it always has been:- “The Right Equipment for the Right Job will provide the Right Results...” Floor Machines Loline 332 Loline 415 NPR1515 NPR1523 NPR1530 NPR1545 NuSpeed NuSpeed Large NuSpeed Twin NuSpeed Spraytec NuSpeed Ultra Accessories Floor Accessories 15-17 NR1500 NLL415...

 Open the catalog to page 3
Floorcare Catalogue-4

Slim Folded Profile The Loline range of low profile floorcare machines has been developed to meet both the growing demand and need for a choice of models that are smaller in size, lighter in weight, compact and convenient in storage whilst, at the same time, being quick and easy to use without loss of performance. The new Loline rotaries have been designed specifically to meet this demand and raise the handling and performance levels to an exceptional user friendly standard, be it for men or women operators. The smallest model in the Loline range can claim performance characteristics equal to...

 Open the catalog to page 4
Floorcare Catalogue-5

Large Solution Tank With the increasing demand and need for higher standards of cleanliness, the Lolines will put truly usable power in the hands of the operator, yet with a level of convenience that cannot fail to impress and, subsequently, to improve both efficiency and the final results. The Loline 415 model embodies all of the many unique features of the 332 but is suitable for a range of larger 40cm (16”) brushes and 36cm (14”) floor pads. With this machine running at an operating speed of 150rpm it is a genuine taskmaster, satisfying a whole host of floor maintenance needs, be it polishing...

 Open the catalog to page 5
Floorcare Catalogue-6

NuPower NPR1515 With its enhanced power and performance the NPR-1515 provides a genuine “workhorse” that will take almost anything in its stride. The full 1500 Watt motor unit packs almost 50% more power than normally required and this power is transmitted to the floor through our long established 150rpm, oil filled, low load, planetary gearbox. Simple to Use Operator Handle The big advantage of excess power is to provide scope for many additional tasks where the excess power is both advantageous and needed. Crystallization, floor sanding, scarifying, adding 10 kg or 20 kg of extra weight, all...

 Open the catalog to page 6
Floorcare Catalogue-7

NuPower NPR1523 The universal NPR-1523 is truly two machines in one, providing the optimum balance between the two primary functions of scrubbing and polishing floors. With its oil filled planetary gearbox providing a working speed of 230 rpm, this is 50% more speed than the NPR-1515. You scrub faster, and when it comes to polishing, the speed is a vital ingredient to improved results. Simple to Use Operator Handle With the 1500 Watt power specification “drop on” weights can be added at any time, scrubbing even better and polishing like a dream. As with all NuPower models the NPR-1523 incorporates...

 Open the catalog to page 7
Floorcare Catalogue-8

NuPower NPR1530 Where polishing is the single purpose of a floor machine then the NPR-1530 is an ideal selection. We have shown in our main illustrations the machine fitted with our full power Dustrol vacuum system which acts to vacuum simultaneously with the polishing Simple to Use Operator Handle function, ensuring the highest of dust-free standards. Unlike the NPR-1523 this is a polishing machine only and is not suitable for wet scrubbing operations. With the added 1500 Watt specification the NPR-1530 can be used for spray cleaning and its ATC, Automatic Torque Control, provides superb performance...

 Open the catalog to page 8
Floorcare Catalogue-9

NuPower NPR1545 To run consistently at Xtra high speeds needs the full NPR-1545 specification and the results truly show what it’s made of. Here you have a burnisher with a full 1500 Watt power unit... an oil filled 450 rpm planetary gearbox... ATC Automatic Torque Control that monitors operation and boosts torque as required; Simple to Use Operator Handle ensuring constant operational performance. ATC is particularly useful when spray cleaning at these higher speeds. There is a selection of brushes and pad drives, allowing a complete selection of polishing heads to achieve the desired results...

 Open the catalog to page 9
Floorcare Catalogue-10

Simple to Use Operator Handle NuSpeed is a new generation of floor maintenance machines which is only made possible by a new drive system, introducing a dramatic 50% increase in power output. The unique NuSpeed design concept means that for a machine of such compact proportions, an increase to 40kg in the operating weight can be achieved within the standard specification, with an optional additional 10kg if required... it has the power and weight that do the work and produce the results. In addition to the power and performance, many extra operating features have been added, making this machine...

 Open the catalog to page 10
Floorcare Catalogue-11

When it comes to large areas of floor maintenance or restoration there is no substitute for both size and weight. The NRL uses a range of 550mm brushes or 500mm floor pads and is supplied as standard in a 40kg specification, fitted with the Automatic Torque Control System designed to give constant performance under even the most arduous conditions. In the standard 150rpm specification the NRL is a genuine ‘workhorse’ which, by virtue of its size, weight and drive system, will exhibit excellent handling characteristics in the majority of applications. The Nuspeed series is now equipped as standard...

 Open the catalog to page 11
