NTC STAVEBNI TECHNIKA spol. s r. o. PRODUCTS INFORMATION

Company NTC STAVEBNÍ TECHNIKA spol. $ r.o. was established in 1991; the main activity is development, production and sale of professional construction machinery. The NTC products are used in both Czech Republic and abroad. High quality of products and services is secured by the ISO 9001:2009 quality control system. Besides of production of construction equipment, NTC is active in the following fields: • renting of construction machinery and equipment • servicing and repairing of construction machines •sale of spare parts • sale of new and used construction machines of other brands

CONTENT Forward vibratory plates VD Elegant page 4 Forward vibratory plates VD Practic page 5 Forward vibratory plates VD Easy page 6 Forward vibratory plates VD Classic page 7 Reversible vibratory plates VDR page 8 Walk-behind vibratory rollers VVV page 10 Tandem vibratory rollers VT page 12 Vibratory tampers NT page 14 Floor saws RZ page 15 Generators TR, TRT, TRH page 16 3

Universal compaction machines suitable for compaction of soil, asphalt and paving. High-frequency vibration is especially suitable for asphalt compaction. modern styling integrated watertank large watertank filler folding handle resiliently mounted handle high-frequency vibratorforsmooth ride rounded edges of the compaction plate do not leave Compact, plate dimens. I Centrifugal force Standard accessories: Sprinkling kit for asphalt compaction Soft pad for pavement compaction Wheel kit for easy handling on the jobsite Throttle lever on the handle

modem styling resilienti)? mounted handle high-frequency vibratorforsmooth ride rounded edges of the compaction plate do not leave mpact. plate dimens. (WxL) Centrifugal force Universal compaction machines suitable for compaction of soil, asphalt and paving. High-frequency vibration is especially suitable for asphalt compaction. Soft pad for pavement compaction Wheel kit for easy handling on the jobsite Hour counter Sprinkling kit for asphalt compaction

FORWARD VIBRATORY PLATES VD EASY Application: Universal compaction machines suitable for compaction of soil and paving. • • • • modern styling resiliently mounted handle high-frequency vibrator for smooth ride rounded edges of the compaction plate do not leave tracks Weight Compact. plate dimens. (WxL) Frequency Centrifugal force Max. speed Engine Type Fuel Net power/RPM 6 kg mm Hz kN m/min kW/RPM VD 15 E 75 400 x 565 100 15 25 HONDA GX 160 petrol 3,6/3600 Options: Soft pad for pavement compaction Wheel kit for easy handling on the jobsite Hour counter VD 18 E 85 450 x 565 100 18 25 HONDA...

FORWARD VIBRATORY PLATES VD CLASSIC Application: Universal compaction machines suitable for compaction of soil, asphalt and paving. This line of machines is recommended for rental usage. • • • • • • robust design protective frame folding handle resiliently mounted handle best compaction effect in this category throttle lever on the handle Weight Compact. plate dimens. (WxL) Frequency Centrifugal force Max. speed Engine Type Fuel Net power/RPM kg mm Hz kN m/min kW/RPM Options: Sprinkling kit for asphalt compaction Soft pad for pavement compaction Wheel kit for easy handling on the jobsite...

REVERSIBLE VIBRATORY PLATES VDR Application: Powerful compaction machines, especially suitable for soil compaction. Alternatively can be used also for compaction of asphalt layers or pavement (particularly for reversible plates up to 250 kg). W Weight C Compact. plate dimens. (WxL) F Frequency C Centrifugal force M Max. speed E Engine T Type F Fuel N Net power/RPM 8 kg mm Hz kN m/min kW/RPM VDR 22 120 400 x 630 100 22 24 HONDA GX 160 petrol 3,6/3600 VDR 26 160 450 x 700 95 26 22 HONDA GX 200 petrol 4,1/3600 VDR 32 210 500 x 750 90 32 22 HONDA GX 200 petrol 4,1/3600 VDR 52 330 600 x 895 75...

REVERSIBLE VIBRATORY PLATES VDR • modern styling • high compaction effect • protective frame • robust design • resiliently mounted handle • throttle lever at the handle • smooth travel speed control, forward and reverse • hydraulic travel control system • advanced hydraulic system with automatic deaeration and setting Weight Compact. plate dimens. (WxL) Frequency Centrifugal force Max. speed Engine Type Fuel Engine power/RPM kg mm Hz kN m/min kW/RPM Options: Sprinkling kit for asphalt compaction (VDR 22/26/32) Soft pad for pavement compaction (VDR 22/26/32) Wheel kit for easy handling on...

WALK-BEHIND VIBRATORY ROLLERS VVV Application: Walk-behind rollers of the VVV line are suitable for both asphalt and soil compaction. They are often used at construction of sidewalks, parking lots, finishing works, road repairs, etc. Weight Dimensions (LxWxH) Frequency Centrifugal force Speed forward/reverse Max. gradeability Drum width Engine Type Fuel Net power/RPM 10 kg mm Hz kN km/h ° mm kW/RPM VVV 600/12 560 2270 x 730 x 1040 60 12 0–5/0–2 20° 600 HONDA GX 200 petrol 4,1/3600 VVV 601/12 610 2600 x 730 x 1040 60 12 0–5/0–2 20° 600 HONDA GX 200 petrol 4,1/3600 VVV 700/22 875 2710 x 830 x...

WALK-BEHIND VIBRATORY ROLLERS VVV • • • • • • • • robust and reliable design hydrostatic system of propulsion smooth travel speed control, forward and reverse mechanical drive of vibrator with electromagnetic clutch all controls at the control bar safety devices – parking brake, „dead man´s control“ central lifting eye electric starting for diesel engines Options: Hour counter Steering wheel for easy manipulation (marked as 601, 701) Steering wheel scraper and sprinkling for 601, 701 versions. Weight Dimensions (LxWxH) Frequency Centrifugal force Speed forward/reverse Max. gradeability Drum...

Tandem rollers VT are used for compaction of asphalt, compaction of non-cohesive and cohesive soils and compaction of stabilized soils. Parking lots, industrial areas and road repairs. robust and reliable design hydrostatic system of propulsion, vibration and steering smooth travel speed control, forward and reverse single-lever control vibration on both drums pressure sprinkling with electronic adjustment plasticwatertankwith large filler ergonomie operator's station unobstructed view to drum edges enables compaction close to walls and raised curbs Standard accessories: Folding ROPS frame...
