NovaFlex PROVIDING HOSE & DUCT SOLUTIONS

Novaflex™ 5011 Vacuum Boom or Port Hose Heavy duty corrugated vacuum hose. Corrugated outer cover for easy of handling. Designed for full vacuum boom applications. Smooth inner tube for enhanced material flow. Abrasion resistant tube for extended wear. Construction: Tube: 3/16”(4.76mm) Tan abrasion resistant rubber Reinforcement: Plies of fabric with helix wire Cover: Black corrugated Length: 50 ft (15.24m) Temperature Range: -40°F (-40°C) to +160°F (+71°C) Novaflex™ 5010WG Sludge Slayer™ Hose 5/16”(8mm) Gum Hose Heavy duty material handling hose designed for portable and central industrial vacuum...

DEBRIS COLLECTION/ BOOM HOSE Nova-Vac™ 5053BG Tapered Connector Sleeve Designed to meet O.E.M.’s specifications for serviceability. This abrasion resistant smooth tube with full vacuum tapered sleeve is used to connect different size piping on vacuum truck applications for sound dampening and vibration elimination. Construction: Tube: Black smooth abrasion resistant rubber Reinforcement: Helix wire and textile Cover: Black abrasion resistant rubber Length: Standard lengths and made to order Temperature: -40°F (-40°C) to +160°F (+71°C) I.D.” Length” Part No. Vacuum 8 x 10 10 5053BG--08000-98-010...

Nova-Vac™ 5063BG Leaf / Debris Hose Designed to meet O.E.M.’s specifications for serviceability. This highly flexible, internally and externally corrugated vacuum hose has a high abrasion resistant rubber tube with 4”(102mm) soft cuffs on each end for easy installation. Construction: Tube: Black corrugated abrasion resistant rubber Reinforcement: Helix wire and textile Cover: Black corrugated abrasion resistant rubber Temperature range: -40°C(-40°C) to 160°F (+71°C) I.D.” Length Part No. Vacuum 12 48 5063BG-12000-00-048 4 Hg 12 100 5063BG-12000-00-100 4 Hg 12 120 5063BG-12000-00-120 4 Hg 12 144...

STREET SWEEPING HOSE Nova-Vac™ 5060 Street Sweeper Hose Designed to meet O.E.M.’s specifications for serviceability. This highly flexible, internally and externally corrugated vacuum hose has an abrasion resistant rubber tube with 4” (102mm) integral cuffs on each end for ease of installation. Ultra flexible and compressible construction to accommodate sweeper vacuum movements. Used for under truck installation. Construction: Tube: Black abrasion resistant rubber Reinforcement: Helix wire with plies of fabric Cover: Black corrugated Temperature range: -40°F (-40°C) to 160°F (+72°C) I.D.” Length...

Nova-Green™ Urethane Hose A lightweight urethane alternative to cumbersome PVC hose. Designed specifically for the landscaping market. Nova-Green all urethane tube provides superior abrasion resistance and excellent flexibility. The hose features a smooth interior with a uniform .045” wall gauge for even abrasion resistance throughout. The exposed rigid helix allows the hose to drag easily across surfaces when the hose is fully charged while providing protection to the hose wall. Applications: Terra-seeding Bark Blowing Mulch Blowing Construction: Material: UV stabilized urethane wall, rigid...

Spiral Clamps For use on corrugated hose covers. Viewing the end of the hose determines whether the spiral is in a clockwise or counter clockwise direction. Clockwise spirals requires a right hand clamp, counter clock wise requires a left hand clamp. Bridge Clamps For use on Novaflex ducting. The bridge clamp has a formed spacer designed to fit over the helix wire on Novaflex, U-Lok and plastic ducts. I.D.” Hose O.D. Range Right Hand Spiral Clamp Part No. Left Hand Spiral Clamp Part No. 6 6.25 to 7” SC600 SCC600 8 8.5 to 9.25” SC800 SCC800 10 10.62 to 11.25” SC1000 SCC1000 I.D.” Clamp Part No....
