Novaflex Rubber Product Guide 2010
Novaflex Rubber Product Guide 2010
- Plastic Extruded Hose and Duct: Includes fish vacuum and discharge hoses, and static conductor hoses.
- Rubber Hose and Connections: Offers hoses for material handling, petroleum, food grade, chemical, and mining applications with custom end configurations.
- Marine Hose and Connections: Complies with ABYC, U.S. Coast Guard, and I.M.O. regulations, suitable for ship-to-shore and ship-to-ship transfers.
- Composite Petro-Chemical Hose: Lightweight hoses with optimum chemical resistance, available with dry seal fittings.
- Consult the Novaflex Chemical Resistance Chart for compatibility and avoid exceeding temperature limits.
- Follow NAHAD Assembly Guidelines for hose coupling and pressure specifications.
- Regular inspection and testing of hoses every 6 months is recommended.
- Remove hoses from service if there is any doubt about their condition.
- Air Hose & Compressed Gas Hose: Includes various models like Novaflex 1000 and 1011, designed for industrial pneumatic tools.
- Chemical Hose: Features hoses like Novaflex 4600 and 4700, designed for chemical transfer and resistance.
- Food & Beverage Hose: Includes hoses like Novaflex 6300 and 6400, suitable for food and beverage applications.
- Marine Hose: Offers products like Novaflex 360-09 for marine fuel and water systems.
- Material Handling Hose: Includes products like Novaflex 5000 Slurry King Hose for heavy-duty applications.
- Petroleum Hose: Features hoses like Novaflex 3254 for oil return and tank truck applications.
- Hot Air Blower Hose: Novaflex 9131 and 1971 designed for transferring hot air to tanks on dried bulk material trucks.
- Chemical Transfer Hoses: Novaflex 4600, 4700, 4704, 4705, 4800/4878, and 4801/4879 designed for high chemical resistance.
- Petroleum Service Hoses: Uni-Chem PG, PS, SG, SS, Uni-Oil GG, and Uni-Zene designed for in-plant liquid transfer and tank truck delivery.
- Special Chemical Service: Uni-FLon designed for highly aggressive media.
- All hoses have specific temperature ranges and are not suitable for steam service.
- Compatibility with chemicals should be verified using Novaflex's chemical resistance charts.
- Elevated temperatures can affect chemical resistance, and users must ensure compatibility.
- Food & Beverage Hoses: Designed for food transfer applications, meeting FDA, USDA, and 3-A standards.
- Composite Hoses: Suitable for transferring water, light chemicals, and petroleum products.
- Hoses are available in various sizes with specific inner and outer diameters, working pressures, burst pressures, and minimum bend radii.
- Couplings are available in different materials, including carbon steel and stainless steel, to meet specific application requirements.
- Elevated temperatures can alter the chemical resistance of hoses, and users must verify compatibility with the intended chemicals.
- Novaflex hoses should not be used beyond the specified ratings to avoid failure.
- Uni-BL Hoses: Customizable for special chemical applications, color-coded to API standards.
- Uni-VR Hoses: Designed for petroleum and petrochemical vapor recovery systems.
- Uni-FLON™ HT: High-temperature composite hose with a Teflon® tube.
- Uni-Oil™ 250 HT: High-temperature petroleum hose.
- Uni-BioFuel 100: Designed for biodiesel and ethanol service.
- Check chemical resistance charts for compatibility, especially at elevated temperatures.
- Do not exceed the temperature and pressure ratings specified by Novaflex.
- Temperature Ranges: Vary from -40°F to +240°F for food hoses, up to +180°F for potable water hoses, and up to 1000°F for high-temperature hoses.
- Compliance: Many hoses meet FDA, USDA, USCG, NMMA, ABYC, and ISO standards.
- Construction: Hoses are constructed with various materials including chlorobutyl, EPDM, neoprene, and nitrile, with reinforcements like polyester tire cord and helix wire.
- Payment and Shipping: Payment terms are net 30 days. All goods are sold FOB manufacturing location, with delivery dates as estimates.
- Warranty and Liability: Hoses are warranted against defects in material and workmanship. Liability is limited to replacement or repair of defective goods.
- Returns and Cancellations: Unauthorized returns are not accepted. A 25% handling charge applies to returned goods. Made-to-order items are non-returnable.
- Force Majeure: The company is not liable for delays caused by events beyond its control, such as natural disasters or government orders.
Catalog excerpts
Plastic Extruded Hose and Duct NovaFlex manufactures a complete line of extruded thermo-plastic duct and hose products manufactured for use in material handling, clean room environments, fume control, welding, exhaust, agriculture, cable conduit and custom OEM applications. This product line has been designed to offer superior flexibility; high temperature, chemical resistance and abrasion resistance using advanced plastics technology. New products include, Fish vacuum and fish discharge hose, static conductor hose. Brands: NovaFlex Hose Rubber Hose and Connections NovaFlex manufactures a complete...
Open the catalog to page 2
Industrial Rubber, Plastic Hose & Composite Hose Guide March 2010 NovaFlex offers the most complete selection of industrial rubber and plastic hose. NovaFlex continuously seeks ways to improve product quality and processes. Success is based on an ability to create value with innovative products and services that exceed expectations and requirements. NovaFlex is an industry leader whose quality products are sold both across North America and around the world. Rev 10 Mar 2010 Canada U.K. U.S.A. Whitby, Ontario Bromborough, Wirral West Berlin, NJ Indianapolis, IN Burlington, NC Tel: 905.666.4970...
Open the catalog to page 3
Please read this information carefully before using any of the information in this book. This catalogue is a guide for use in selecting the correct hose for the correct application. It contains warnings, reference directions and directions for the safe use of industrial hose. All guidelines should be clearly understood before specifying or using any Novaflex product. Failure to follow recommended application information and recommended procedures may result in premature failure, resulting in bodily injury or property damage. Contact Novaflex or your local Novaflex distributor for assistance....
Open the catalog to page 4
Table of contents Air Hose & Compressed Gas Hose Novaflex 1000 Textile Air Hose 1 Novaflex 1011 Textile Air Hose 1 Novaflex 1015 Textile GP & Air Hose 2 Novaflex 1015 Textile Coupled Jackhammer with Universal Couplings 2 Novaflex 1025 Wire Braid Air Hose 2 Novaflex 9131 Oxygen Charging Hose 3 Novaflex 1208 Hot Air Blower Hose 3 Novaflex 1971 Hot Air Blower Corrugated Hose 3 Chemical Hose Novaflex 4600 FEP Chemical Transfer Hose 4 Novaflex 4700 UHMW Chemical Suction-Smooth Hose 4 Novaflex 4704 UMWP Chemical Suction & Discharge Hose 4 Novaflex 4705 UHMW Crush & Kink Resistant Hose 5 Novaflex 4800/4878...
Open the catalog to page 5
Table of contents Novaflex 5010 Sludge Slayer Hose 28 Novaflex 5015 Material Handling Hose 1/8” gum tube 28 Novaflex 5016 Material Handling Hose 1/4” gum tube 28 Novaflex 5017 Bulk Material Transfer Hose 29 Novaflex 5018 Bulk Material Transfer Hose 29 Novaflex 5020 Industrial Vacuum Hose 29 Novaflex 5770/5771/5772 Bulk Material Discharge Hose 30 Novaflex 5284 Elephant Trunk Hose 30 Novaflex 5785 Concrete Pumping Hose 30 Novaflex 5328 Plaster Hose 31 Novaflex 5331 Dredge Sleeves/Sand Discharge Hose 31 Novaflex 5332 Sand Suction Hose 31 Novaflex 5300 Premium Sandblast Hose 32 Novaflex 5760/5761/5762...
Open the catalog to page 6
® 1 Novaflex 1000* Textile Air Hose Designed for heavy-duty use on industrial pneumatic tools in mines, quarries and construction jobs. Construction: Tube: Medium oil resistant. Reinforcement: Plies of polyester tire cord Cover: Yellow weather and abrasion resistant rubber Length: 100 ft Temperature Range: -30° to +180°F *Available in a non-conductive and 400psi version Novaflex 1011 Textile Air Hose Designed, utilizing a multiply construction to supply high working pressures. Special cover compound is designed to prove excellent performance in those demanding construction applications. This...
Open the catalog to page 7
2 ® Novaflex 1015 Textile GP & Air Hose Designed utilizing a multi-ply construction to supply high working pressures. The special cover compound is designed to provide excellent performance in those demanding construction applications. This hose is mandrel built, wrapped cover construction designed to provide excellent resistance to cuts and abrasion. Construction Tube: Medium oil resistant Reinforcement: Multiple braids of cord Cover: Red abrasion resistance EPDM blend Length: 100 ft Temperature Range: -40° to +180°F Novaflex 1015 Textile Coupled Jackhammer Hose with Universal Couplings Novaflex...
Open the catalog to page 8
3 ® Novaflex 9131 Oxygen Charging Hose Used for industrial applications where high pressure oxygen is needed. Construction: Tube: Black Neoprene rubber Reinforcement: Plies of polyester tire cord Cover: Green weather and abrasion resistant neoprene rubber, pin pricked Length: 100 ft Temperature Range -30° to +180°F Made on stainless steel mandrels, no petroleum lubrications, ends capped. Novaflex 1208 Hot Air Blower Hose A flexible lightweight hose designed for transferring hot air to tanks on dried bulk material trucks. EPDM to withstand temperatures up to 375°F on an intermittent basis. Construction:...
Open the catalog to page 9
4 ® Novaflex 4600 FEP Chemical Transfer Hose Recommended for the transfer of products that require a hose tube with the highest level of chemical resistance. The FEP teflon-type” tube provides that extra margin of safety; with a white chemical resistant back up rubber stock for high adhesions. FEP transfer hose is excellent for tank truck, barge loading, storage tank transfer and in plant applications requiring flexibility and durability. Construction: Tube: FEP Reinforcement: Multiple plies of polyester tire cord with helix wire Cover: Blue EPDM (available in black, gray, yellow, green, white...
Open the catalog to page 10
5 ® Novaflex 4705 UHMW Crush & Kink Resistant Chemical Hose Special kink and crush resistant version of 4700 design utilizing a multi-ply construction with dual special monofilament helix rods. Excellent for use in those demanding abusive transfer applications. To utilize the maximum temperature rating of the hose always permanently attach couplings *WARNING!! Construction: Tube: Ultra high molecular weight polyethylene. Reinforcement: Multiple plies of tire cord with dual monofilament helix, static wire. Cover: Green EPDM rubber. Length: 100 ft. Temperature Range: -40°F to +180°F. (May be used...
