Novaflex Rubber Hose brochure.pdf

Product catalog summary
Overview: This document outlines the specifications and applications of Novaflex industrial hoses, designed for diverse uses such as water suction, discharge, oxygen transfer, hot air transfer, and food and beverage applications. Each hose type is tailored to specific industrial requirements, including temperature range, working pressure, and material compatibility.
1. Water and Air Hoses:
  • Novaflex 2152 Water Suction Hose: Features a black synthetic EPDM rubber tube, polyester tire cord reinforcement, and a smooth black weather-resistant cover. Suitable for portable pumps with a temperature range of -30°F to 180°F.
  • Novaflex 2150 Water Discharge Hose: Designed for discharge applications with a working pressure of up to 250 psi, similar in construction to the suction hose.
  • Novaflex 9131 Oxygen Charging Hose: Rugged hose for oxygen transfer, featuring neoprene rubber and a working pressure of 500 psi.
  • Novaflex 1208 Hot Air Blower Hose: For transferring hot air, capable of withstanding temperatures up to 375°F intermittently.
2. Food and Beverage Hoses:
  • Novaflex 6505 Wine Hose: Crush-resistant with a chlorobutyl microbe-resistant tube, suitable for food applications.
  • Novaflex 6500 Connoisseurs Food & Beverage Hose: Full vacuum hose for non-oily products, compliant with FDA, USDA, and 3-A standards.
  • Novaflex 6300 Nitrile Food Suction & Discharge Hose: Designed for oily transfer applications with a white FDA grade tube.
3. Petroleum Transfer Hoses:
  • Novaflex 3253 Tank Truck Hose: Suitable for oil and gasoline, featuring a nitrile tube and neoprene cover.
  • Novaflex 3859 Nitrile Hot Tar & Asphalt Hose: For high-temperature petroleum products, with a temperature range up to 350°F.
4. Specialty Hoses:
  • Novaflex 2636 Slip Ring/Coupless Rubber Water Hose: Lightweight layflat hose for dewatering and irrigation, featuring a unique coupling system.
  • Novaflex 3265 Corrugated Dock Hose: Designed for barge unloading, featuring a corrugated cover for flexibility.
5. Chemical Transfer Hoses:
  • Novaflex 4200: EPDM chemical suction hose for general industrial use, with a temperature range of -30°F to +225°F.
  • Novaflex 4700: UHMWP chemical suction and discharge hose, lightweight and flexible, with a temperature range of -40°F to +250°F.
  • Novaflex 4600: FEP chemical transfer hose with high chemical resistance, suitable for tank truck and barge loading.
6. Material Handling Hoses:
  • Novaflex 5000: Slurry King hose with a pure gum liner, designed for abrasive material handling.
  • Novaflex 5785: Concrete pumping hose with high pressure capability, featuring an abrasion-resistant SBR tube.
  • Novaflex 5332: Sand suction hose with a black abrasion-resistant synthetic rubber tube.
7. High Temperature Hoses:
  • Novaflex 5520: Red low-pressure non-conductive steam hose, ideal for medium-duty steam transfer.
  • Novaflex 9155: Furnace door fiberglass hose designed to withstand extreme external heat.
8. Specialty Hoses:
  • Novaflex TPU: Urethane heavy-duty vacuum hose for abrasive material transfer, including underwater applications.
  • Novaflex Yellow Jack: Pumper-sanitation hose designed for flexibility and crush resistance.
Conclusion: Novaflex offers a comprehensive range of hoses tailored for specific industrial applications, each designed with unique materials and construction to meet demanding requirements such as temperature extremes, pressure, and chemical compatibility.
Additional Products:
  • Superflex Dust Collector Hose: Recommended for mining dust collectors and roof-bolt drills, featuring a corrugated cover for flexibility and meeting MSHA requirements.
  • Novaflex 143 PVC Conduit Hose: Serves as a cable cover in the mining industry, offering low cost, flexibility, and easy installation.
  • Novaflex 7005 Mining Conduit Hose: Designed for electrical cable protection in mines, non-reinforced and flame-resistant.
  • Novaflex 5010 Sludge Slayer Hose: Heavy-duty hose for industrial vacuum equipment, suitable for full vacuum applications.
  • Novaflex 5050 Vacuum Boom or Port Hose: Heavy-duty corrugated vacuum hose designed for full vacuum boom applications.
  • Engineered Hoses and Custom Expansion Joints: Custom hose constructions and expansion joints designed to protect piping systems from vibration and thermal stress.
  • End Configurations: Custom end configurations for hoses, including built-in nipples, integral flanges, and beaded ends.
See more

Catalog excerpts

Novaflex Rubber Hose brochure.pdf-1

Industrial Rubber Products ®

 Open the catalog to page 1
Novaflex Rubber Hose brochure.pdf-2

1 Air & Water HOSE Novaflex 2152 Water Suction Hose This heavy duty water suction hose is designed for use on portable pumps by contractors, quarries and mine sites. Construction: Tube: Black synthetic EPDM rubber Reinforcement: Plies of polyester tire cord with wire helix Cover: Smooth black weather and abrasion resistant rubber Lengths: 100 ft (30.5m) Temperature range: -30°F (-34°C) to 180°F (82°C) Style No:2152BE Novaflex 2150 Water Discharge Hose Construction Tube: Black synthetic EPDM rubber Reinforcement: Plies of polyester tire cord Cover: Smooth black weather and abrasion resistant rubber...

 Open the catalog to page 2
Novaflex Rubber Hose brochure.pdf-3

2 Novaflex 2200 Water Jetting Hose Designed to be extremely flexible, lightweight high pressure water jetting hose. Premium cover provides protection against cuts, gouging, scuffs and ozone. Construction: Tube: Black EPDM Reinforcement: Polyester tire cord Cover: Smooth black EPDM cover Length: 100ft (30.5m) Temperature Range -30°F (-34°C) to 180°F (82°C) Working Pressure: 2” to 500psi (34Bar), 3” to 400psi (27Bar), Style No: 2200BE Available in high pressure style 2250BE Novaflex 2140 Papermill Washdown Hose with Nozzle (50ft. lengths) A quality wash down hose used in paper mills and other industrial...

 Open the catalog to page 3
Novaflex Rubber Hose brochure.pdf-4

3 Novaflex 6505 Wine Hose (Crush Resistant) 250psi WP Connoisseur “Crush Resistant” hose is designed be the ultimate food hose. This unique hose construction uses a special monofilament helix which provides flexibility, kink resistance in a light weight hose. Full vacuum through 3”ID and 20” hg in 4” FDA, USDA, 3-A Construction: Tube: Chlorobutyl Microbe resistant tube Reinforcement: Multiple plies of polyester tire cord Cover: Purple EPDM Lengths: 100ft (30.5m) Temperature Range: -40°F (-40°C) to +240°F (115°C) Working Pressure: 250psi (17Bar) Style No: 6505 Novaflex 6501 Connoisseurs Food &...

 Open the catalog to page 4
Novaflex Rubber Hose brochure.pdf-5

4 Novaflex 6300 Nitrile Food Suction & Discharge Hose 150psi WP Recommended for the food transfer application that demands both flexibility and ruggedness with a clean white FDA grade tube. The food grade nitrile tube is odorless and tasteless for those oily transfer applications. Excellent for suction and discharge applications. Construction: Tube: White Nitrile (FDA) Reinforcement: Multiple plies of tire cord with dual helix wire Cover: Gray PVC Nitrile Lengths: 100 ft (30.5m) Temperature Range: -30°F (-34°C) to +225°F (107°C) Working Pressure: 150psi (10Bar) Style No: 6300WT Novaflex 6301...

 Open the catalog to page 5
Novaflex Rubber Hose brochure.pdf-6

5 Novaflex 3253 Tank Truck Hose Nitrile tube designed for use with oil, gasoline and other petroleum products. Ideal for pressure, gravity flow or suction service from tank trucks, tank cars or bulk plants. Steel wire helix is spiraled between multiple plies of tire cord to reinforce hose to resist crushing and kinking. Black neoprene cover is abrasion, oil and weather resistant. Construction: Tube: Nitrile Reinforcement: Multiple plies polyester tire cord and steel wire helix Cover: Black neoprene Length: 100 ft (30.5m) Temperature Range: -30°F (-34°C) to +180°F (82°C) Working Pressure: 150psi...

 Open the catalog to page 6
Novaflex Rubber Hose brochure.pdf-7

6 Novaflex 3859 Nitrile Hot Tar & Asphalt Hose Designed for the transfer of tar, asphalt, hot oils and other high temperature petroleum based products. Construction: Tube: Black high grade nitrile rubber Reinforcement: Plies of polyester tire cord with helix wire Cover: Smooth black abrasion resistant nitrile Length: 100 ft (30.5m) Temperature Range: -40°F (-40°C) to 350°F (176°C) Working Pressure: 150psi (10Bar) (intermittent service only) Style: 3859BT Novaflex 2019 Coolant Hose Designed for heavy duty industrial or automotive coolant service. This three ply construction hose has a specially...

 Open the catalog to page 7
Novaflex Rubber Hose brochure.pdf-8

7 Novaflex 3550 Heavier Duty Petroleum Discharge Hose Designed to be flexible with a hose cover that provides extra abrasion resistance to meet the demanding requirements of industry. Handles all grades of petroleum with aromatic contents to 55%. Construction: Tube: Black Nitrile Reinforcement: Multiple plies tire cord with static wire Cover: Red oil and abrasion resistant rubber Length: 100 ft (30.5m) Temperature Range: -30°F (-34°C) to +180°F (82°C) Working Pressure: 250psi (17Bar) Style No: 3550BT Novaflex 3257 Corrugated Low Temperature Tank Truck Hose A medium duty low temperature petroleum...

 Open the catalog to page 8
Novaflex Rubber Hose brochure.pdf-9

8 Medium Duty Material Handling Hose Static Conductor* An lighter more flexible economical alternative to rubber hose when static buildup is a concern. Construction: Extruded Red TPR and Black Static Conductive helix Lengths: 50 ft (15.2m) & 100 ft (30.5m) Temperature Range: -20°F (-28°C) to +165°F (74°C) Working Pressure: 6” to 30psi (2Bar) Style No: 9NFSCAP * Conductivity of hose should be tested regularly. Test with OHMS meter using conductive fittings inserted into each end of hose. Novaflex TPU Urethane Heavy Duty Vacuum Hose Designed specifically for transfer of abrasive materials under...

 Open the catalog to page 9
Novaflex Rubber Hose brochure.pdf-10

9 Novaflex 4200 EPDM Chemical Suction Hose A medium duty chemical suction and discharge hose designed to meet the general needs of the industry. Construction: Tube: Black high grade EPDM Reinforcement: Multiple plies of tire cord with dual helix wire Cover: Yellow EPDM Length: 100 ft ((30.5m) Temperature Range: -30°F (-34°C) to +225°F (107°C) Working Pressure: 150psi (10Bar) Style No: 4200BE Consult chemical resistance chart Not for steam service, can be open end steam cleaned. Available with high grade weather resistant cover. Novaflex 4700 UHMWP Chemical Suction & Discharge Hose A lightweight...

 Open the catalog to page 10
Novaflex Rubber Hose brochure.pdf-11

10 Novaflex 4201 EPDM Chemical Discharge Hose A high quality discharge hose designed to transfer common chemicals found in industrial service. Construction: Tube: Clear Ultra High Molecular Weight polyethylene Reinforcement: Multiple plies of high tensile textile with monofilament helix Cover: Green abrasion resistant EPDM (Available in red, blue, yellow black and grey, white & orange - with 400ft order) Length: 100 ft ((30.5m) Temperature Range: up to -40°F (-40°C) to +250°F (121°C) Working Pressure: 150psi (10Bar) Style No: 4700CU Consult chemical resistant chart. Not for steam service, can...

 Open the catalog to page 11
