Spraymec 6050 WP - 3

Spraymec 6050 WP TI 100004455 DRW DATE 13.11.2007 PAGE 3 / 4 Diesel-hydraulic Shotcreter APPR. 21.07.2008 Normet Corporation Ahmolantie 6 FI-74510 IISALMI, FINLAND Tel +358 (0) 17 83 241 Fax +358 (0) 17 823 606 ENGINE Deutz TCD 2012 96 kW/2200 rpm TRANSMISSION Dana Spicer powershift 3 speeds forwards and reverse 4-wheel drive AXLES Planetary type TYRES 10.00 - 20 PR 16 BRAKES Drive brake: hydraulic power assisted two-circuit oil immersed multidisc brakes in both axles Safety/Parking brake: hydraulically released fail safe -type brake STEERING Hydraulic frame steering Orbitrol type Frame...

Open the catalog to page 3
Spraymec 6050 WP - 4

Spraymec 6050 WP TI 100004455 DRW DATE 13.11.2007 PAGE 4 / 4 Diesel-hydraulic Shotcreter APPR. 21.07.2008 Normet Corporation Ahmolantie 6 FI-74510 IISALMI, FINLAND Tel +358 (0) 17 83 241 Fax +358 (0) 17 823 606 OPTIONS AND ACCESSORIES: ENCLOSED CABIN Width with enclosed cabin 2000 mm CABIN HEATING AIR CONDITIONING ENGINE Mercedes Benz OM904 LA 90 kW/2200 rpm ACCELERATION PUMP Nordoser 900 EH Liquid flow 1...20 l/min LIGHTS Spot light in cabin 2 pcs HIGH PRESSURE WASHER Hydraulically operated 1. For washing the machine *water pressure 180 bar *water flow 30 l 2. For washing the rock *water...

Open the catalog to page 4
