AVENTUS 1 STREET LIGHTING LANTERN
8Pages

{{requestButtons}}

Catalog excerpts

AVENTUS 1 STREET LIGHTING LANTERN - 2

tr.row {} td.cell {} div.block {} div.paragraph {}

Open the catalog to page 2
AVENTUS 1 STREET LIGHTING LANTERN - 3

Aventus is the NordexΒs solution for lightinghighways, turn-offs, main streets, freeways and car parks. Aventus is created to answer to the aesthetical, mechanical and lighting needs of our customers. This elegant and innovative design can be used in a variety of urban landscapes and the two different models make it suitable for every kind of installation. >

Open the catalog to page 3
AVENTUS 1 STREET LIGHTING LANTERN - 4

The cover can easily accommodate a photocell. Internal gaskets are made of antiageing, tropicalised and weather resistant siliconrubber so ensuring trouble free use. All hardwares are corrosion resistantstainless steel and the fastening clip isstainless steel to AISI 304. The reflector is made of hydro formed0.90mm high purity aluminium (99.85%),electrically brightened, anodised and chemically treated giving an improveddistribution. The socket housing is made of die-castaluminium alloy. This socket can be adjustedfor horizontal mounting with degrees of adjustment in between. This gives...

Open the catalog to page 4
AVENTUS 1 STREET LIGHTING LANTERN - 5

The spigot fixingadapter is reversible and allows the adjustment of the lantern from 0to +15аfor vertical mounting and from 0to -20аfor horizontal mounting, both in steps of 5. The spigot fixing is И 60 mm. Lamp replacementis easily achievedby releasing twolateral screws androtating the lamp holder housing. The pre-wiredcontrol gear tray isalso easily removed should this benecessary byloosening two fingertightened knobs. Optic control in the photometric laboratory AVENTUS > 1 >

Open the catalog to page 5
AVENTUS 1 STREET LIGHTING LANTERN - 6

Body, cover and spigot fixing: die-cast aluminium alloypowder coated in polyester powder (RAL 9007). Socket: E27 or E40 for Aventus 1, E40 for Aventus 2. Cover glass: Thermally toughened 4 mm. flat glass or curvedglass. Electrical accessories: Galvanised pre-wired gear tray. Pole fixing: post-top (from 0to +15а) and side entry (from 0to-20а) suitable for 60 mm spigots. Electrical insulation class: I Reflector: high purity aluminium (99.85%), electrically brightened,anodised and chemically treated. Protection degree: IP 66 Optic type: cut-off and semi cut-off. Fixings: stainless steel AISI...

Open the catalog to page 6
AVENTUS 1 STREET LIGHTING LANTERN - 8

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:4.00pt "Arial", sans-serif; } .font1 { font:5.00pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:9.00pt "Arial", sans-serif; } .font4 { font:7.00pt "Tahoma", sans-serif; } <D <D g_§ □ .« 1^ ^ ~§ Q_ > ° & E o _ o D ^2 ~^ o c O O =E -Ç o S -EL (D >-D5 § _>- Q_ = u X a> cl o J ^ => "O Q_ 0 . _2 ~Q_ -ã Q_ 8 S .i^ Cl u E 2L 8 "1 ^ O >- « -Q CD-o .E (D II ^ « ci ~o o o ^= o J ^ Nordex Industries S.p.A. Via della Meccanica, 29 04011 Aprilia - LT - Italy Tel. +39.06.92.81.666 Fax +39.06.92.81.243...
