PHEN Automation PHEN AUTOMATION Directional Valve Small size, fast response, high flow rate, energy saving With indicator light and voltage protection circuit, it has good safety, theairoutletcan be changed, and it can be directly piped

PHEN Automation PHEN AUTOMATION 4V Series Solenoid Valve Ordering Code 4V 2 10 - 08 M E4 - □ □ W Main Dimension Valve Code 4V: 5/2, 5/3 Valve Valve Body Size 1:100 Series 10: Single Control 2 Position 20: Double Conlrol 2 Position 30: Double Conlrol 3 Position Center Close 40: Double Conlrol 3 Position Center Exhaust 50: Double Conlrol 3 Position Center Pressure Connect Type And Initial State Blank: Pipe Connect Type M: 5/2 Ptate Connect Type(Namur) NC: 5/2 Normal Close Type NO: 5/2 Normal Open Type Wire Connect T: NPT Thread PT: BSPT Thread Pilot Type Blank: Internal Pilot- Basic Type Flying...

PHEN Automation PHEN AUTOMATION 3V Series Solenoid Valve Directional Valve Ordering Code 3V 2 10 - 08 M E4 - □ □ W Valve Code 3 V: 3/2 Valve Main Dimension Basic Type Flying Leads Type Double Control Valve Valve Body Size 1:100 Series 2:200 Series 3:300 Series 4:400 Series 10: Single Control 2 Position 20: Double Control 2 Position Connect Type And Initial State Blank: Pipe Connect Type M: 3/2 Plate Connect Type (Namur) NC: 3/2 Normal Close Type NO: 3/2 Normal Open Type Directional Valve Symbol RP Wire Connect Blank: G Thread T: NPT Thread PT: BSPT Thread Specification Pilot Type Blank: Internal...

PHEN Automation PHEN AUTOMATION 4A Series Air Control Valve Ordering Code Main Dimension Directional Valve Valve Code 4V: 5/2, 5/3 Valve Valve Body Size 1:100 Series 2:200 Series 3:300 Series 4:400 Series 10: Single Control 2 Position 20: Double Control 2 Position 30: Double Control 3 Position Center Close 40: Double Control 3 Position Center Exhaust 50: Double Control 3 Position Center Pressure Single Air Control Double Air Control 5/3 Air Control Directional Valve Symbol Thread Blank: G Thread T: NPT Thread PT: BSPT Thread Specification Model

PHEN Automation PHEN AUTOMATION 3A Series Air Control Valve Ordering Code 3 A 2 1 Main Dimension Directional Valve Valve Code 3V: 3/2Valve Single Air Control Double Air Control Valve Body Size 1:100 Series 2:200 Series 3:300 Series 4:400 Series 10: Single Control 2 Position 20: Double Control 2 Position Directional Valve Symbol Thread Blank: G Thread T: NPT Thread PT: BSPT Thread Specification Model

PHEN Automation PHEN AUTOMATION PVF Series JIS Standard Solenoid Valve Ordering Code PVF 3 Main Dimension Directional Valve Symbol Valve Code PVF: 5/2, 5/3 Valve Valve Body Size 2:200 Series 3:300 Series 5:500 Series 10: Single Control 2 Position 20: Double Control 2 Position 30: Double Control 3 Position Center Close 40: Double Control 3 Position Center Exhaust 50: Double Control 3 Position Center Pressure Specification Model Valve Code 3V: 3V Valve 4V:4V Valve PVF:PVF Valve Valve Body Size 100:100 Series 200:200 Series 300:300 Series 500:500 Series Station Number 1:1 Stations 2:2 Stations

PHEN Automation PHEN AUTOMATION PSY Series JIS Standard Solenoid Valve Ordering Code PSY 5 Directional Valve Valve Code PSY: 5/2, 5/3 Valve Valve Body Size 1: Single Control 2 Position 2: Double Control 2 Position 3: Double Control 3 Position Center Close 4: Double Control 3 Position Center Exhaust 5: Double Control 3 Position Center Pressure Tube Connect Port size Directional Valve PSY Series Valve Manifold Wire Connect L: Elbow type leads M: Straight Leads Wire Length Blank: G Thread T: NPT Thread PT: BSPT Thread Valve Code PSY: 5/2, 5/3 Valve Valve Body Size Station Number PSY3000 Series PSY5000...

PHEN Automation PHEN AUTOMATION Directional Valve Two-position Single Type Situation With Bottom Bracket Two-position Single Type Situation With Bottom Bracket T“ PSY3120 Series PSY5120 Series PSY3120 Series Directional Valve Unit(mm)

PHEN Automation PHEN AUTOMATION Directional Valve Two-position Single Type Valve Code 4R: 5/2 Hand Pull Valve 3R: 3/2 Hand Pull Valve Series Code 2:200 Series 3:300 Series Hand Pull Valve 10 10: Single Head Double Position Hand Push Valve 4H 2 10 06 L □ Valve Code 4H: 5/2 5/3 Hand Push Valve Series Code 2:200 Series 3:300 Series 4:400 Series 10: Double Position 30C: Three Position Center Close 30E:Three Position Center Exhaust 30P:Three Position Center Press Type Code Blank: 5/3 Spring Rest Type Blank: G Thread T: NPT Thread PT: BSPT Thread Directional Valve | Two-position Double Type Valve Code...

PHEN Automation PHEN AUTOMATION Anti Explode Namur Valve EX Directional Valve Symbol 5 way 2 position 3 way 2 position Directional Valve Specification Working Pressure Coil Power Product Features: 1, Ex-proof approved products, this valve can work on the Anti Explode Application 2, This valve is 3/2 and 5/2 convertible solenoid valve, It can control the sigle acting and double acting actuator directly 3, Connecting method can be Namur Connecting or Thread-Tubing Connecting 4, The manual handle makes its work more easily operated 5, The internal air access at pilot part are all designed internal,...

PHEN Automation PHEN AUTOMATION PF Series Air Treatment Unit PF Air Treatment Unit Symbol Specification Ordering Code Pressure Regulating Range Filter Precision Body Size MINI MIDI MAX Drain Type Blank:Manual Drain S:Differencial Drain D:Auto Drain Blank: G Thread T: NPT Thread PT: BSPT Thread 1/4 [3] Second pressure gauge connection 14 Bleed screw for oil reservoir f5l Oil adjusting screw Full auto drain Air Treatment Unit Model

PHEN Automation PHEN AUTOMATION PA Series Air Treatment Unit Air Treatment Unit Symbol Ordering Code PA Series JIS Standard FRL Type Code Body Size 10:1000 Body Size 20:2000 Body Size 30:3000 Body Size 40:4000 Body Size Combination Style 00:F+R+L Three Unit 10:FR+L Two Unit Port Size 01:1/8" (20 size) Filter Precision Drain Type Blank:Manual Drain S:Differencial Drain D:Auto Drain Blank: G Thread T: NPT Thread PT: BSPT Thread Main Dimension PAC 1000-2000 PAC3000-4000 PAC5000 Specification Model Air Treatment Unit Sign
