Company Overview
NIKDIM Ltd., located in Kazanlak, Bulgaria, is a prominent manufacturer of low and medium voltage electrical apparatus since 1991. The company employs around 200 skilled personnel and operates certified quality management systems (ISO 9001:2000). It produces a broad range of electrical products including medium voltage fuses, fuse holders, NH fuses and bases, screw type low voltage fuses, disconnecting switches, lever breakers, porcelain insulators, and custom electrical porcelain appliances. NIKDIM serves Bulgaria's electric power system and exports over 40% of its production internationally.
Product Range
- Medium Voltage Fuses: Rated for 6.3 kV to 35 kV, including Series I-IV with varying pin strike forces and breaking capacities.
- Fuse Holders and Bases: Indoor and outdoor types compliant with IEC and BDS standards, some with integrated arresters.
- NH Fuses and Bases: Low voltage high power fuses (sizes 000 to 4), rated up to 1250 A, with detailed electrical and mechanical specifications.
- Screw Type Low Voltage Fuses: Types DII E27 and DIII E33, rated 500 V with 50 kA breaking capacity.
- Disconnecting Switches: Types RM, ROM, ROS for 10 kV to 35 kV networks, available in indoor/outdoor mounting, manual operation, with safety blocking features.
- Lever Breakers and Switches: Manual devices rated up to 1000 V and 1000 A.
- Porcelain and Epoxy Insulators: Wide range for low and medium voltage applications, including bushing, carrying, and support insulators compliant with BDS, IEC, and DIN standards.
- Custom Electrical Porcelain Appliances: Manufactured by pressing or shaping, including special purpose and steatite appliances for industrial and military use.
Technical Specifications
Medium voltage fuse links are designed per IEC 282-1 with rated currents from 2 A to 160 A and breaking capacities up to 60 kA. Series I and II are for normal pin strike (20 N), Series III for higher pin strikes (50-120 N), and Series IV for 24 kV applications. High voltage fuses for measuring transformers cover voltages up to 36 kV with rated currents of 2 A.
Fuse bases and holders meet IEC 282-1 and BDS standards, designed for specific voltage ratings and mounting conditions. NH fuse links and bases comply with BDS EN 60269-1:2002, with detailed power loss and resistance data. Screw cap fuses conform to BDS ND 630.31 S2:2002.
Disconnecting switches cover rated voltages of 10 kV, 20 kV, and 35 kV with rated currents up to 1250 A. They include indoor porcelain-insulated types and outdoor vertical/horizontal mounting variants, some equipped with arc chambers and stainless steel components for harsh environments. Manual operation is via RLZ series drives with safety blocking mechanisms.
Standards and Quality Assurance
- Compliance with IEC 282-1, BDS 8945-79, BDS EN 60269-1:2002, BDS EN 60129+A1+A2, BDS ND 630.31 S2:2002, DIN 40680, DIN 41580, and other relevant standards.
- Materials include porcelain type C-110, epoxy, copper and brass contacts with nickel plating, and stainless steel for corrosion resistance.
- Quality management certified under ISO 9001:2000.
Installation and Operational Recommendations
- Select fuses matching rated current, voltage, and breaking capacity requirements.
- Install fuse bases and holders according to indoor or outdoor specifications to ensure safety and performance.
- Disconnecting switches are intended for no-load switching; manual operation and blocking devices are critical for safe use.
- Consider environmental factors such as temperature (-10°C to +60°C), humidity (60% at 40°C), and altitude (up to 1000 m) during installation.
- Custom fuse designs and special purpose porcelain appliances are available to meet specific customer needs.
Additional Product Details
- Bushing Insulators: PRB and PRBO series for 10 kV and 20 kV substations with rated currents 200-1000 A, tested for variable frequency and impulse voltages.
- Medium Voltage Carrying Insulators: Type VHD for overhead lines up to 25 kV, with mechanical and electrical test data.
- Rill Insulators: For electrical panels up to 1000 V, with detailed dimensions and weights.
- Epoxy Insulators: Cylindrical and conical types rated for 10 kV and 20 kV, suitable for high voltage fuse applications.
- Isolating Bodies for NH Fuses: Porcelain bodies compliant with BDS and DIN standards.
- Ceramic Bodies for Chemical Industry: Designed for filling applications with strict dimensional tolerances.
- Installation Electroporcelain Appliances: Manufactured by half-dry pressing method per BDS and DIN standards.
- Special Purpose Appliances: Made from electro-porcelain and steatite for radio-electronic and military industries.
- Material Properties: Low water permeability (≤1.5%), high density (≥2.2 g/cm³), strong mechanical properties (bending strength ≥30 MPa), high electrical resistivity, and thermal stability.
New Developments
- Power disconnecting switches for horizontal outdoor mounting with remote control for line sectioning.
- Rotary-type disconnecting switches for indoor mounting, designed for transformer substation integration.
Contact and Sales Network
NIKDIM maintains multiple sales offices and warehouses across Bulgaria with comprehensive contact details for general inquiries, sales, export, and management. Website: www.nikdim.bg
Catalog excerpts
Production of electrical appliances >
Open the catalog to page 1
Production of electrical appliances NIKDIM Ltd. Kazanlak, BULGARIA, is a leading company specialized in the production of electro appa-ratus low and medium voltage. Since it was founded in 1991, the rm has established itself as the leading manufacturer of the follow-ing electrical goods: > Medium voltage fuses HV type. Nominal voltage - 6,3 kV, 10 kV, 20 kV and 35 kV;Օ Fuse holders for HV fuses indoor and outdoor mounting - 10 kV, 20 kV and 35 kV;л NH fuses. Sizes - 000, 00, 0, 1, 2, 3, 4;Րە NH fuse bases. Sizes 000, 00, 0, 1, 2, 3, 4;ە Screw type low voltage fuses - DII E27; DIII E33;л Disconnecting...
Open the catalog to page 4
Production of electrical appliances ӐݐؐڐԐؐܔ ЕООД - гр. Казанлък е водеща българска фирма, специализирана в производството на електроапаратура ниско и средно напрежение. Основана през 1991 година, тя е утвърдена на пазара като производител на следните електрически изделия: > ՐҐؑPސڐސҐސۑސҐ ؐߑՐԐߐАאؑՐې ؑؐ ߐҐҐ ߐא АݐАߑՐՐݐؑ - 6,3 kV, 10 kV, 20kV ϐ 35 kV;ؕ Стойки за открит и вътрешен монтаж - 10 kV, 20 kV и 35 kV;л ՐҐؑPސڐ ސܐޑɐݐ ؐߑՐԐߐАאؑՐې ؑؐ ߐҐߐݐ ݐݐؑPڐ ސݐАߑՐՐݐؐ ՐӐАѐБؑ 000,00, 0, 1, 2, 3, 4;ؐە Основи за високо мощни предпазители тип ОВП габарит 00, 0, 1, 2, 3,4;л ՐҐؐݑސҐ (ؐѐؑސҐ) ؐߑՐԐߐАאؑՐې ؐא АݐؑPڐ ސݐАߑՐՐݐؐ...
Open the catalog to page 6
Production of electrical appliances Времетокова характеристика > TIME (Seconds) CURRENT (Amperes) Времетокова характеристика > Cut-o current Ток на изключване Prospektive short circuit current Ток на късо съединение 11 >
Open the catalog to page 14
Тип Номинално напреж. Тегло kV Вид монтаж Стойка за ВвП с катоден отвод e test parameters of the fuse bases meet the requirements of IEC 282-1. e dimensions are according to BDS 8945-79 > Изделията, по отношение на на изпитвателните параметри са в съответствие с изискванията на IEC 282-1 Размерите отговарят на БДС 8945-79
Open the catalog to page 15
TIME (Seconds)лTIME (Seconds) Времетокова характеристика на габарит 000уВреметокова характеристика на габарит 00 > TIME (Seconds) TIME (Seconds) Времетокова характеристика на габарит 1 Времетокова характеристика на габарит 0 >
Open the catalog to page 18
TIME (Seconds) Времетокова характеристика на габарит 2 > TIME (Seconds) Времетокова характеристика на габарит 3 >
Open the catalog to page 19
NH 00NH 0NH 1 NH 2NH 3NH 4 Nominal current Nominal Voltage Dimensions, Weight Type > Номинален ток Номинално напрежение Размери Тегло Package > Тип (mm) Опаковка AVABCDEFGHIJKLMkg > NH 00160690100578058M87-3825-120-200.203/81NH 01606901507413073M87-48251217010200.403/36лNH 12506901758015085M10113060251220024280.623/18NH 24006902008015495M12113068251423024350.923/18NH 363069021080160106M16113080251425024401.503/14лNH 41250690270100220138M161330102251131013452.601/1 e NH fuse bases are according to standard BDS EN 60269-1:2002 Основите за високомощни предпазители отговарят на стандарт БДС ЕN 60269-1:2002...
Open the catalog to page 21
Rated curent > Номинален ток A1601602504006301250Nominal voltage > Номинално напреж. V690690690690690690Rated frequency > Номинална честота Hz505050505050Alternative standing voltage > Напрежение на изолацията V300030003000300030003000Rated power loss > Загуби W102228425484 Standard > Стандарт IEC 60269-1:1998, БДС EN 60269Fuses contacts Cu(copper), CuZn37 (brass) > Контакти на предпазителя мед, месинг Мaterial of fuse base contacts Cu(copper), CuZn37 (brass) > Материал на контактите на основата мед, месинг Material contacts surface > Покритие на контактните повърхнини Ni (Nckel)Тemperature rise...
Open the catalog to page 22
ؐՐӐې ސАאܐՑ (mm) ؐސߐАڐސҐڐ (pcs.) DII E 272pink розов 2722.56304brown ՐڐБđϐ 2722.56306green ҕ зелен 3022.563010red ՑǐՑҐՐ 3022.583016gray ݕ сив 3022.5103020blue ՑPؐ 3422.5123025yellow ݕ жълт 3422.51430DIII E 3335black ՑǐՑՐ 4528162050white ݕ бяло 4828182063copper ՐܐՐԐՐ 5128202080*silver ݕ сребърен 52282040100*red ՑǐՑҐՐ 52282040 > Размери (mm) Тип (A) (V) Тегло Опаковка (g) ؐАאܐՑ (mm) ؐؐ (A) (V) ߐՐӐې ސސߐАڐސҐڐ (g) Размери (mm) Тип (A) (V) Тегло Опаковка (g) (pcs.) E 272550012342373620E 336350017547444315 Rated voltage 500V class gl-gG Breaking capacity at 1,1 Un 50kA cosφ=0,2 Standards BDS НД 630.31...
Open the catalog to page 23
Production of electrical appliances 1О21 RMmMZkNP10kV/20kVcurrent (А) 1 РМмMЗкНП10kV/20kVток (А) rated current > номинален ток rated voltage > номинално напрежение fuses avaible > наличност на предпазители type of the contact system > вид на контактната система type of earthing (ZӔ or ZkӔ cable) > тип на заземяване (Ӑה или Ӑאڔ кабелен) loaded breaking capacity > възможност за изключване под товар type of disconnecting switch > тип на разединителя one pole disconnecting switch > еднополюсен разединител size="-2">
Open the catalog to page 24
RMm 20 kVРМм 20 kV RMmZkN 20 kVСРМмЗкN 20 kVСRMmN 20 kVРМмН 20 kVRMmZk 20 kVРМмЗк 20 kVСRMmZk 10 kVРМмЗк 10 kV RMm 20 kVРМм 20 kV RLZ -15СРЛЗ -15 > Standards BDS EN 60129+А1+А2 Стандарт БДС EN 60129+А1+А2 www.nikdim.bg >
Open the catalog to page 25
АאܐՑ Type Un(kV)In(A)Umax(kV)Current of termal resistance ؐؐ ߐސ ڐݐ БՑܐؑǐݐ БÑQސّǐؐҐޑQ ސ ڐݐ АԐؐݐАܐؑǐݐ БÑQސّǐؐҐޑQ abcdefROSM kA Current of dynamicresistance kA ܐxDimensions, АސM 2040024205064514907259286851120 >
Open the catalog to page 31
Production of electrical appliances л Power disconnecting switch for horizontal outdoor mounting with a mechanism for switching Ր on and o with a remote control for sectioning of distribution lines. ە Power and standard disconnecting switch for indoor mounting type rotaryӔ for mounting into panels. > л л ՐܐޑɐݐޑQՐ ݑАאՐԐؐݐؑՐ ېא БŐޑؐאސݑАېՐ ݐޑڑؑ ܐސݑА ֑ PܐՑŐАݐؐבʐ ܐא АҐڐۑΑǐҐАݐ Ր ؐ ېؐאڑΑǐҐАݐ Ց PԐؑQАݑƐؐސݐݐ ޑÐߑАҐېՐݐؐ Րא БPՐڑƐؐސݐؑАݐ Րݐ АՐېՐڑސߑސҐސԐ. ؕ Разединител мощностен и обикновен за вътрешен монтаж тип đޑБƐؐސݐՐݓ за вграждане в КТП. 29 >
Open the catalog to page 32
Размери Packing (pcs.) In (A)Un (v)Weight Тегло kgDimensions, ABCDEFG Опаковка (бр.) 100 3801.7108128185255103421 160 3801.9115130185255303103421 250 3803.0130155185255360103671 400 3804.5218210240282360103671 630 3806.3218210240277444103671 1000 38011.5228250297311420103671 > Размери Packing (pcs.) In (A)Un (v)Weight Тегло kgDimensions, ABCDEFG Опаковка (бр.) 100 3802.2159103182265315103421 160 3802.5159103182265315103421 250 3803.6180140185270330136671 400 3807.2255200240300385136671 630 3808.5255200240300385136671 >
