Irrigation Valves Catalog
52Pages

{{requestButtons}}

Catalog excerpts

Irrigation Valves Catalog - 2

Business-to-Business Solutions Look to NIBCO for technology leadership The velocity with which e-business evolves demands that new products and serv- ices be continuously developed and introduced to keep our customers at the center of our business efforts. NIBCO provides an entire suite of business-to-business solutions that is changing the way we interact with customers NIBCOpartner.comsm is an exclusive set of secure web applications that allow quick access to customer-specific information and online order processing. This self-service approach gives you 24/7 access to your order status...

Open the catalog to page 2
Irrigation Valves Catalog - 3

Dezincification Resistant Visit our website for the most current information. Page Bronze and Brass Ball Valves . . . . . . . . . . . . . . . . 23-27 Illustrated Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 T-580 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 T-580-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 T-585-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 T-FP-600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Iron Body Gate Valves . . . . . . . ....

Open the catalog to page 3
Irrigation Valves Catalog - 4

Bronze and Brass Gate Valves Illustrated Index Bronze Gate Valve Screw-in Bonnet 250 PSI Dezincification Resistant PR-113-K Non-Rising Stem • Solid Wedge • Push-on Ends with Joint Restraints Size 2” Threaded Ends Page 5 Brass Gate Valve Screw-in Bonnet • Reduced Port 200 lb. CWP Bronze Gate Valve Screw-in Bonnet 125 lb. SWP 200 lb. CWP Dezincification Resistant Bronze Gate Valve Screw-in Bonnet 200 lb. CWP Dezincification Resistant Dezincification Resistant T-113-K/T-113-BHW/T-113 Non-Rising Stem • Solid Wedge Sizes ¹⁄₄" thru 3" Threaded Ends Page 6 T-29-K/T-29 Non-Rising Stem • Solid Wedge...

Open the catalog to page 4
Irrigation Valves Catalog - 5

Dezincification Resistant 250 PSI CWP Bronze Gate Valve Screw-in Bonnet • Non-Rising Stem • Solid Wedge • Push-on Ends with Joint Restraints 250 PSI/17.2 Bar Bar Non-Shock Cold Working Pressure CONFORMS TO MSS SP-80 MATERIAL LIST 1. Handwheel Nut 2. Identification Plate 3. Handwheel, Cross 4. Stem 5. Packing Nut 6. Packing Gland 7. Packing 8. Stuffing Box 9. Bonnet 10. Body 11. Wedge 300 Series Stainless Steel Aluminum Bronze ASTM B 584 Alloy C84400 Silicon Bronze ASTM B 371 Alloy C69430 or ASTM B 99 Alloy C65100 Bronze ASTM B 62 or ASTM B 584 or Brass ASTM B 16 Bronze ASTM B 62 or ASTM B...

Open the catalog to page 5
Irrigation Valves Catalog - 6

Class 125 Bronze Gate Valves Dezincification Resistant Screw-in Bonnet • Non-Rising Stem • Solid Wedge 125 PSI/8.6 Bar Saturated Steam to 353° F/178° C 200 PSI/13.8 Bar Non-Shock Cold Working Pressure 1. Handwheel Nut 300 Series Stainless Steel 2. Identification Plate Aluminum 3. Handwheel a. Malleable Iron ASTM A 47 (T-113) b. Bronze (T-113-BHW) c. Bronze Cross (T-113-K) 4. Stem Silicon Bronze ASTM B 371 Alloy C69400 or ASTM B 99 Alloy C65100 5. Packing Nut Bronze ASTM B 62 or ASTM B 584 Alloy C84400 or Brass ASTM B 16 6. Packing Gland Bronze Astm B 62 or ASTM B 584 Alloy C84400 or Brass...

Open the catalog to page 6
Irrigation Valves Catalog - 7

200 PSI CWP Bronze Gate Valve Valves Dezincification Resistant Screw-in Bonnet • Non-Rising Stem • Solid Wedge • Compact Design 200 PSI/13.8 Bar Non-Shock Cold Working Pressure 1. Handwheel Screw 2. Handle 3. Stem 4. Stem Seal 5. Bonnet 6. Wedge 7. Body Stainless Steel a. Bronze Cross (T-29-K) b. Aluminum (T-29) Copper ASTM B 99 Alloy C10200 Rubber EPDM ”O“ Ring Cast Copper-based Alloy C84400 Cast Copper-based Alloy C84400 Cast Copper-based Alloy C84400 Threaded with Cross Handle Freezing Weather Precaution – Subsequent to testing a piping system, valves should be in an open position to...

Open the catalog to page 7
Irrigation Valves Catalog - 8

150 PSI CWP Brass Gate Valves Dezincification Resistant Bronze Body • Non-Rising Stem • Reduced Port 150 PSI/10.3 Bar Non-Shock Cold Working Pressure to 180° F/82° C 1. Handwheel 2. Handle Nut 3. Identification Plate 4. Packing Nut 5. Gasket Washer 6. Gasket 7. Bonnet 8. Retainer 9. Washer 10. Stem 11. Disc 12. Body Cast Iron Brass Rod Aluminum Brass Rod PTFE Brass Tube Cast Brass Brass Rod PTFE Brass Rod Cast Brass Cast Brass Freezing Weather Precaution – Subsequent to testing a piping system, valves should be in an open position to allow complete drainage. NIBCO INC. WORLD HEADQUARTERS •...

Open the catalog to page 8
Irrigation Valves Catalog - 9

200 PSI CWP Brass Gate Valves Dezincification Resistant Bronze Body • Non-Rising Stem • Full Port 200 PSI/13.8 Bar Non-Shock Cold Working Pressure to 180° F/82° C 1. Handwheel 2. Handle Nut 3. Identification Plate 4. Packing Nut 5. Packing Gland 6. Bonnet 7. Stem 8. Retainer 9. Washer 10. Disc 11. Body Cast Iron Brass Nut Aluminum Brass Rod Graphite Rubber Cast Brass Brass Rod/Cast Brass Brass Rod PTFE Cast Brass Cast Brass Freezing Weather Precaution – Subsequent to testing a piping system, valves should be in an open position to allow complete drainage. NIBCO INC. WORLD HEADQUARTERS •...

Open the catalog to page 9
Irrigation Valves Catalog - 10

175 PSI CWP Bronze Hose Gate Valves Dezincification Resistant Screw-in Bonnet • Non-Rising Stem • Solid Wedge 175 PSI/12.1 Bar Non-Shock Cold Working Pressure CONFORMS TO MSS SP-80 • UL Listed • FMRC Approved MATERIAL LIST 1. Handwheel Nut 2. Handwheel 3. Stem 4. Packing Nut 5. Packing Gland 6. Packing 7. Stuffing Box 8. Bonnet 9. Body 10. Wedge 11. Hose Cap 12. Hose Cap Gasket 13. Safety Chain Bronze ASTM B 16 Malleable Iron Silicon Bronze ASTM B 371 Alloy C69400 Bronze ASTM B 62 Bronze ASTM B 16 or ASTM B 62 Non-Asbestos Bronze ASTM B 62 Bronze ASTM B 62 Bronze ASTM B 62 Bronze ASTM B 62...

Open the catalog to page 10
Irrigation Valves Catalog - 11

Bronze Globe and Angle Valves Illustrated Index Bronze Globe Valve Screw-in Bonnet 250 PSI CWP Dezincification Resistant Bronze Globe Valve Screw-in Bonnet 125 PSI CWP Bronze Globe Valve Screw-in Bonnet • Cross Handle 125 lb. SWP 200 lb. CWP T-381-WK Integral Seat • Renewable Disc Size 2” Threaded Ends Page 12 75-K Integral Seat • Resilient Disc Sizes ¹⁄₂" thru ³⁄₄" Threaded Ends Page 13 T-211-YK Integral Seat • Renewable Seat and Disc Sizes 1" thru 2" Threaded Ends Page 14 Bronze Globe Valve Screw-in Bonnet 125 lb. SWP 200 lb. CWP Bronze Angle Valve Screw-in Bonnet • Cross Handle 125 lb....

Open the catalog to page 11
