Fire Protection Valve Catalog

Fire Protection Valve Catalog

Product catalog summary

Overview: The document is a catalog from NIBCO Inc. detailing their range of fire protection valves, emphasizing technology leadership and customer-centric solutions, including online order processing and inventory management.

Business-to-Business Solutions: NIBCO offers secure web applications through NIBCOpartner.com, providing 24/7 access to order status, price checks, invoices, and inventory availability. Key services include Electronic Data Interchange (EDI) and Vendor Managed Inventory (VMI) for efficient transactions and inventory management.

Product Specifications: The catalog includes detailed specifications for various valves, such as bronze and iron UL/FM valves, hi-rise valves, and butterfly valves. Each entry provides size, pressure ratings, material composition, and compliance with industry standards.

Dezincification Resistance: NIBCO's bronze valves are resistant to dezincification, ensuring quality and longevity.

Technical Details: Material lists and dimensions are provided for specific valve models, including components like the body, ball, seat ring, and stem.

Compliance and Standards: The catalog notes compliance with standards such as UL, ULC, and FM approvals, and highlights listings like the California State Fire Marshal Listing.

Additional Information: Includes sections on flow data, valve material properties, typical fire sprinkler systems, and warranty information.

Valve Types and Features:

175 PSI WWP Bronze Hose Gate Valves: Screw-in bonnet, non-rising stem, solid wedge, UL Listed, FM Approved.
300 PSI WWP Bronze Hose Angle Valves: Rising stem, renewable disc, UL Listed, FM Approved.
175 PSI WWP Bronze Globe Valves: Threaded ends, rubber disc, UL Listed for trim and drain use.
400 PSI WWP Bronze Side Outlet Globe Valves: 3-way valve, integral seat, renewable disc.
200 PSI WWP Bronze Check Valves: Horizontal swing, rubber disc, conforms to MSS SP-80.
600 PSI WWP Bronze Ball Valves: Two-piece body, chrome plated ball, conforms to MSS SP-110.

Key Considerations:

Valves are designed for non-shock cold water applications.
Dezincification resistance is a common feature.
Installation guidelines emphasize correct positioning and usage.

Specifications: Valves are UL/ULC listed, FM approved, and meet AWWA C-509 & 515 standards. Certified lead-free by IAPMO R&T to NSF/ANSI 372.

Material List: Details specifications for valve parts, including ductile iron, bronze, stainless steel, and EPDM, with ASTM standards.

Dimensions and Weights: Provides dimensions and weights for valve sizes from 4 inches to 12 inches.

Freezing Weather Precaution: Gate valves should be left open after testing to prevent freezing damage.

Lead-Free Compliance: Valves comply with the Safe Drinking Water Act, ensuring lead content ≤ 0.25%.

Installation Notes: For horizontal flow, install with the disc hinge pin vertical. Not for steam or near reciprocating air compressors.

Indicator Posts: Details for upright and wall post indicator posts for non-rising stem gate valves.

Check Valves: Describes grooved silent check valves for fire protection, with installation cautions and material lists.

Fire Protection Valves: UL listed and FM approved, designed for easy installation between standard class 125 flanges.

Gate Valves: Iron body with bronze trim, suitable for high-pressure applications up to 500 PSI WWP.

Warnings and Precautions:

Not for steam applications or near reciprocating air compressors.
Proper installation is crucial to avoid turbulence.

Contact Information: NIBCO provides contact details for technical services and international offices.

Ordering Information: Specify quantity, figure number, and size. Returns require prior agreement and a 20% rehandling fee.

Technical Assistance: Available via phone, fax, or writing.

Warranty: 5-year warranty on pressure-rated metal valves against defects, with replacement and installation cost compensation.

Company Overview: NIBCO is a global manufacturer adhering to ISO-9001 standards, offering high-quality flow control solutions.

Product Range: Includes PEX piping systems, thermoplastic pipes, valves, fittings, and actuation systems for various applications.

Global Operations: Manufacturing and distribution centers in the U.S. and internationally, with direct shipping from Elkhart, Indiana, and Lodz, Poland.

Catalog excerpts

Business-to-Business Solutions Look to NIBCO for technology leadership. The velocity with which e-business evolves demands that new products and services be continuously developed and introduced to keep our customers at the center of our business efforts. NIBCO provides an entire suite of business-to-business solutions that is changing the way we interact with customers. NIBCOpartner.comsm is an exclusive set of secure web applications that allow quick access to customer-specific information and online order processing. This self-service approach gives you 24/7 access to your order status putting...

Open the catalog to page 2

Table of Contents Visit our website for the most current information . Bronze UL/FM Valves and Trim . . . . . . . . . . . . . . . . . 4-17 Iron UL/FM Butterfly Valves . . . . . . . . . . . . . . . . . . 37-45 Butterfly Indicator Post . . . . . . . . . . . . . . . . . . . . . . . . 44 Properties of Valve Materials . . . . . . . . . . . . . . . . . 48-49 Gate Valve Dimensions for Supv. Switch . . . . . . . . . . 50 Grooved Pipe Specification . . . . . . . . . . . . . . . . . . . . . 51 Figure Number Comparisons . . . . . . . . . . . . . . . . . . . . . 52 Typical Fire Sprinkler System . . . . ....

Open the catalog to page 3

Bronze UL/FM & Trim Valves Illustrated Index Dezincification Resistant UL/ULC Listed • FM Approved Bronze Gate Valve Outside screw and yoke 175 PSI WWP UL Listed • FM Approved Bronze Ball Valve with weather-proof indicating gear operator 300 PSI WWP UL Listed • FM Approved Bronze Hose Gate Valve with cap and chain 175 PSI WWP UL Listed • FM Approved Bronze Angle Valve with cap and chain 300 PSI WWP T-104-O Sizes ¹⁄₂" thru 2" Threaded ends Page 5 KT-505-W-8 Threaded ends KG-505-W-8 Grooved ends Page 6 T-103-HC Size 2¹⁄₂" Threaded ends Page 7 T-331-HC Size 2¹⁄₂" Threaded ends Page 8 UL Listed Bronze...

Open the catalog to page 4

175 PSI WWP Bronze Gate Valves Dezincification Resistant Fire Protection Valve • Screw-over Bonnet • Outside Screw and Yoke • Solid Wedge 175 PSI/12.1 Bar Non-Shock Cold Water (400 PSI Non-Shock CWP General Service) UL/ULC Listed* • FM Approved • Approved by the New York City B.S.A. 143-69-SA Material List 1. Set Screw 2. Handwheel 3. Yoke Bushing 4. Gland Bolts 5. Packing Gland 6. Packing 7. Bonnet 8. Stem 9. Stem Collar 10. Wedge Pin 11. Wedge 12. Body Steel ASTM A307 Malleable Iron Brass ASTM B16 Steel ASTM A307 Zinc Plated Bronze ASTM B62 Non Asbestos Aramid Fibers w/Graphite Bronze ASTM...

Open the catalog to page 5

300 PSI WWP Bronze Ball Valves Dezincification Resistant Fire Protection Valve • Threaded or Grooved Body Style • Full Port Design 1" - 2" • Standard Port Design 2¹⁄₂" 300 PSI/20.7 Bar Non-Shock Cold Water Conforms to MSS SP-110 • FM Approved for indoor and outdoor service • UL Listed for Indoor and Outdoor Service* • California State Fire Marshal Listing No. 7770-1243:103 Material List 1. Body 2. Ball 3. Seat Ring 4. Thrust Washer 5. Stem 6. Stem O-Ring 7. Retaining Washer 8. Retaining Ring 9. Ground Wire Screw 10. 505-8 Act Assy. 11. Body End 12. Mounting Screw 13. Lock Washer 14. Handle Pin...

Open the catalog to page 6

175 PSI WWP Bronze Hose Gate Valves Dezincification Resistant Fire Protection Valve •Screw-in Bonnet • Non-Rising Stem • Solid Wedge 175 PSI/12.1 Bar Non-Shock Cold Water Conforms to MSS SP-80 • UL Listed* • FM Approved Material List Part 1. Handwheel Nut 2. Handwheel 3. Stem 4. Packing Nut 5. Packing Gland 6. Packing 7. Stuffing Box 8. Bonnet 9. Body 10. Wedge 11. Hose Cap 12. Hose Cap Gasket 13. Safety Chain Brass ASTM B16 Malleable Iron Silicon Bronze ASTM B371 Alloy C69430 Bronze ASTM B62 Brass ASTM B16 Non Asbestos Aramid Fibers w/Graphite Bronze ASTM B62 Bronze ASTM B62 Bronze ASTM B62...

Open the catalog to page 7

300 PSI WWP Bronze Hose Angle Valves Dezincification Resistant Fire Protection Valve • Rising Stem • Renewable Disc • Screw-in Bonnet 300 PSI/20.7 Bar Non-Shock Cold Water Conforms to MSS SP-80 • UL Listed* • FM Approved Material List Part 1. Handwheel Nut 2. Handwheel 3. Stem 4. Packing Nut 5. Packing Gland 6. Packing 7. Bonnet 8. Body 9. Disc Holder Nut 10. Drive Screw 11. Disc Holder 12. Hose Cap 13. Seat Disc 14. Hose Cap Gasket 15. Safety Chain 16. Seat Disc Nut 17. Cotter Key Brass ASTM B16 Malleable Iron Silicon Bronze ASTM B371 Alloy C69430 Bronze ASTM B62 Bronze ASTM B16 or ASTM B62...

Open the catalog to page 8

175 PSI WWP Bronze Globe Valves Dezincification Resistant Fire Protection Valve • Threaded Ends • Rubber Disc • Screw Over Bonnet 175 PSI/12.1 Bar Non-Shock Cold Water UL Listed* Material List Part 1. Handwheel 2. Handwheel Screw 3. Stem 4. Packing Nut 5. Packing 6. Bonnet 7. Body 8. Seat Disc 9. Seat Screw 10. Pack Washer Aluminum Carbon Steel Stainless Steel (1") Bronze ASTM B584 Alloy C84400 or ASTM B505 Alloy C84400 Bronze ASTM B584 Alloy C83600 or ASTM B16 Graphite Impregnated (Non Asbestos) Bronze ASTM B584 Alloy C84400 Bronze ASTM B584 Alloy C84400 EPDM Rubber (1/4" - 3/8") Nitrile (1/2"...

Open the catalog to page 9

175 PSI WWP Bronze Globe Valves Dezincification Resistant Fire Protection Valve • Screw-in Bonnet • Integral Seat • Renewable Disc 175 PSI/12.1 Bar Non-Shock Cold Water Conforms to MSS SP-80 • UL Listed* Material List Part 1. Handwheel Nut 2. Identification Plate 3. Handwheel 4. Stem 5. Packing Gland 6. Packing Nut 7. Packing 8. Bonnet 9. Disc Holder Nut 10. Disc Holder 11. Seat Disc ‡12. Disc Nut 13. Body 300 Series Stainless Steel Aluminum Aluminum Commercial Alloy 380 Silicon Bronze ASTM B371 Alloy C69430 Bronze ASTM B62 or ASTM B584 Alloy C84400 or ASTM B282 or ASTM B16 Bronze ASTM B62 or...

Open the catalog to page 10

175 PSI WWP Bronze Angle Valves Dezincification Resistant Fire Protection Valve • Threaded Ends • Rubber Disc • Screw Over Bonnet 175 PSI/12.1 Bar Non-Shock Cold Water UL Listed* Material List Part 1. Handwheel 2. Handwheel Screw 3. Stem 4. Packing Nut 5. Packing 6. Bonnet 7. Body 8. Seat Disc 9. Seat Screw 10. Pack Washer Aluminum Carbon Steel (¹⁄₂" & ³⁄₄") Stainless Steel (1") Bronze ASTM B584 Alloy C84400 Bronze ASTM B584 Alloy C83600 or ASTM B16 Graphite Impregnated (Non Asbestos) Bronze ASTM B584 Alloy C84400 Bronze ASTM B584 Alloy C84400 Nitrile Rubber Stainless Steel Sheet Brass * UL Listed...

Open the catalog to page 11
