Product catalog summary

Introduction
NIBCO BlazeMaster® CPVC Fire Sprinkler products are crafted from high-quality CPVC, offering benefits over traditional metal systems such as better hydraulics, easier installation, and faster assembly. These products have a reliable service history spanning over 40 years.

Specifications and Engineering Data
BlazeMaster® CPVC fittings are rated for continuous service at 175 psi at 150°F. They comply with NFPA 13, 13D, and 13R standards and are NSF listed for potable water use. They are also approved by Factory Mutual, Underwriters Laboratories, and the Loss Prevention Safety Board.

Compatibility
The fittings are compatible with other manufacturers' CPVC pipes and fittings that meet UL and FM standards. Installers must ensure product suitability according to each manufacturer's guidelines.

Product Specifications
Designed for use with SDR 13.5 dimension pipes as per ASTM F 442, BlazeMaster® CPVC Fire Sprinkler Products are available in Schedule 40 and Schedule 80 dimensions, UL and C-UL Listed, and FM Approved for a working pressure of 175 psi at 150°F.

Installation Instructions
Refer to NIBCO's "Installation and Design Manual" or the "Pocket Guide" for detailed installation instructions.

Standard Fire Protection Fittings
The catalog includes various fittings such as adapters, bushings, caps, couplings, crosses, elbows, flanges, tees, and unions, each with specific dimensions and weight details.

Business-to-Business Solutions
NIBCO offers B2B solutions including NIBCOpartner.com for secure web applications, Electronic Data Interchange (EDI) for efficient document exchange, and Vendor Managed Inventory (VMI) for automated inventory management.

Contact Information
NIBCO INC. WORLD HEADQUARTERS, 1516 Middlebury St., Elkhart, IN 46516-4740, USA. Phone: 1.800.234.0227, Tech Services: 1.888.446.4226, Fax: 1.888.336.4226, International Office: +1.574.295.3327, Fax: +1.574.295.3455.

Installation Guidelines for CPVC Fire Sprinkler Systems
Specifications and Procedures:

Ensure compatibility of thread sealants, gasket lubricants, or firestop materials with CPVC.
Store pipes and fittings in original packaging and cover with an opaque tarp if outdoors.
Use tools designed for plastic pipes and follow proper handling procedures.
Apply the correct solvent cement and adhere to application instructions.
Protect interior finishes with a drop cloth and ensure pipe ends are cut square, deburred, and beveled.
Rotate the pipe 1/4 turn when inserting into the fitting socket and avoid solvent cement on sprinkler head threads.
Follow recommended cure times before pressure testing and fill lines slowly at proper pressure.
Support sprinkler heads properly and use insulation or glycerin and water solutions for freeze protection.
Ensure installers are trained according to the NIBCO BlazeMaster® CPVC Fire Sprinkler System Installation and Design Manual.

Prohibitions:

Avoid using edible oils, petroleum, or solvent-based materials as lubricants or sealants.
Do not use glycol-based solutions as antifreeze or contaminate the CPVC system with oils.
Do not use expired or discolored solvent cement or allow it to plug the sprinkler head orifice.
Avoid connecting rigid metal couplers to CPVC grooved adapters and do not thread or groove CPVC pipe.
Do not pressure test with air or exceed recommended pressure levels.
Avoid using ratchet cutters below 50°F and do not use unprotected CPVC pipe stored outdoors.
Do not install in cold weather without allowing for expansion or in dry systems.

Product Information:

NIBCO offers a range of CPVC fittings with specific sizes and cross-reference numbers for different manufacturers.
Products are manufactured under ISO-9001 standards and are available through authorized distributors.

Warranty:

NIBCO provides a 10-year warranty on BlazeMaster® CPVC fittings against defects in materials and workmanship.
In case of defects, contact NIBCO Technical Services for inspection and potential replacement.

Company Overview:

NIBCO is a vertically integrated manufacturer with a global presence, offering a wide range of fire protection solutions.
The company emphasizes quality, service, and compliance with industry standards such as UL, ULC, FMRC, and NYC.

Product Overview

Valves: Includes a variety of valves such as steel ball valves, pneumatic and electric actuators, grooved ball and butterfly valves, high-performance butterfly valves, UL/FM fire protection valves, MSS specification valves, bronze specialty valves, low-pressure gate, globe, check and ball valves, frostproof sillcocks, quarter-turn supply stops, quarter-turn low-pressure valves, PVC ball valves, CPVC CTS ball valves, and Just Right® recirculating valves.
Fittings: Offers wrot and cast copper pressure and drainage fittings, cast copper alloy flanges, wrot and cast press fittings, ABS and PVC DWV fittings, Schedule 40 PVC pressure fittings, CPVC CTS fittings, CPVC CTS-to-metal transition fittings, Schedule 80 PVC and CPVC systems, CPVC metric piping systems, and CPVC BlazeMaster® fire protection fittings.
CHEMTROL®: Provides thermoplastic pipe, valves, and fittings in PVC, Corzan® CPVC, polypropylene, and PVDF Kynar®, along with pneumatic and electric actuation systems.
TOLCO®: Includes pipe attachments, structural attachments, pipe rollers, threaded products and accessories, seismic components, and standard and specialty supports, serving markets such as commercial, industrial, and fire protection.
eNIBCO: Features electronic data interchange (EDI), vendor managed inventory (VMI), and online platforms NIBCO.com and NIBCOpartner.com.

Note: Corzan® and BlazeMaster® are registered trademarks of The Lubrizol Corporation, and Kynar® is a registered trademark of Arkema Inc.

Catalog excerpts

AHEAD OF THE FLOW® CPVC BlazeMaster® F i r e P r o t e c t i o n F i t t i n g s CATALOG C-BLZM-1009

Open the catalog to page 1

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH:1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1.574.295.3327 • FAX: +1.574.295.3455 www.nibco.com The velocity with which e-business evolves demands that new products and services be continuously developed and introduced to keep our customers at the center of our business efforts. NIBCO provides an entire suite of business-to-business solutions that is changing the way we interact with customers. Look to NIBCO for technology leadership. Business-to-Business...

Open the catalog to page 2

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1/574.295.3327 • FAX: +1/574.295.3455 www.nibco.com 5 A H E A D O F T H E F L O W® www.nibco.com Revised 10/1/2009 50 = CPVC Fire Protection TYPE OF MATERIAL Key to NIBCO Figure Numbers Fitting Terms and Abbreviations FNPT = Female NPT Thread MNPT = Male NPT Thread S or SLIP = Female Socket SPG = Male End (Spigot) G = Grooved L = Large S = Small H = Heavy A = Van Stone 2-piece flange Q = Quart P = Pint 01 = Coupling...

Open the catalog to page 5

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1/574.295.3327 • FAX: +1/574.295.3455 www.nibco.com 6 A H E A D O F T H E F L O W® www.nibco.com Revised 10/1/2009 Specifications and Engineering Data Introduction NIBCO® BlazeMaster® CPVC Fire Sprinkler products produced by NIBCO are manufactured from high quality, Post-Chlorinated Polyvinyl Chloride (CPVC), a specialty thermoplastic material tested and listed by certifying agencies for use in CPVC fire sprinkler...

Open the catalog to page 6

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1/574.295.3327 • FAX: +1/574.295.3455 www.nibco.com 10 A H E A D O F T H E F L O W® www.nibco.com Revised 10/1/2009 BlazeMaster® Fire Protection Fittings – STANDARD ELBOWS 5006 45° Elbow UNIV. NOM. APPROX. DIM. J JOINT FIG. NO. SIZE NET WT./LBS. INCHES 5007 90° Elbow 5007-R UNIV. NOM. APPROX. DIM. A DIM. B JOINT FIG. NO. SIZE NET WT./LBS. INCHES INCHES 5007 3/4" 0.08 0.56 0.56 SXS 5007 1" 0.14 0.69 0.69 SXS 5007...

Open the catalog to page 10

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1/574.295.3327 • FAX: +1/574.295.3455 www.nibco.com 11 A H E A D O F T H E F L O W® www.nibco.com Revised 10/1/2009 BlazeMaster® Fire Protection Fittings – STANDARD FLANGES Future Offering 5019-H Blind Flange – Solid UNIV. NOM. APPROX. DIM. G DIM. OB FIG. NO. SIZE NET WT./LBS. INCHES INCHES 5051-A 5019-H 3/4" 0.32 0.58 0.80 5019-H 1" 0.43 0.64 0.84 5019-H 1-1/4" 0.57 0.69 0.94 5019-H 1-1/2" 0.69 0.78 1.00 5019-H...

Open the catalog to page 11

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1/574.295.3327 • FAX: +1/574.295.3455 www.nibco.com 13 A H E A D O F T H E F L O W® www.nibco.com Revised 10/1/2009 BlazeMaster® Fire Protection Fittings – STANDARD UNIONS 5033-E Unions (O-ring Material EPDM) UNIV. NOM. APPROX. DIM. A DIM. L JOINT FIG. NO. NOM. SIZE NET WT./LBS. INCHES INCHES 5033-E 3/4" 0.27 2.46 0.43 SXS 5033-E 1" 0.40 2.70 0.43 SXS 5033-E* 1-1/4" 0.87 3.31 0.79 SXS 5033-E* 1-1/2" 0.93 3.58...

Open the catalog to page 13

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1/574.295.3327 • FAX: +1/574.295.3455 www.nibco.com 15 A H E A D O F T H E F L O W® www.nibco.com Revised 10/1/2009 BlazeMaster® Fire Protection Fittings – THREADED ADAPTERS 5003-BI Female Adapter with Metal Thread Inserts UNIV. NOM. APPROX. DIM. A JOINT FIG. NO. SIZE NET WT./LBS. INCHES 5003-BI 3/4" 0.28 1.19 SXFNPT 5003-BI 1" 0.63 1.59 SXFNPT 5003-BI 1-1/4" 1.02 1.96 SXFNPT 5003-BI 1-1/2" 1.26 1.98 SXFNPT 5003-BI...

Open the catalog to page 15

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1/574.295.3327 • FAX: +1/574.295.3455 www.nibco.com 16 A H E A D O F T H E F L O W® www.nibco.com Revised 10/1/2009 BlazeMaster® Fire Protection Fittings – THREADED ADAPTERS Spigot Female Sprinkler Head Adapter with Metal Thread Inserts 5003-2-S-BI 5003-2-S-BI 1"X1/2" 0.16 1.84 SPGXFNPT 5003-2-S-BI 3/4"x1/2" 0.15 1.53 SPGXFNPT 5004-BI Male Adapter with Metal Thread Inserts 5004-BI 3/4" 0.22 1.35 SxMNPT 5004-BI...

Open the catalog to page 16

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1/574.295.3327 • FAX: +1/574.295.3455 www.nibco.com 17 A H E A D O F T H E F L O W® www.nibco.com Revised 10/1/2009 Sprinkler Head Back To Back Cross with Metal Thread Inserts 5035-3-S-BI-S 5035-3-S-BI-L UNIV. NOM. APPROX. DIM. A DIM. B DIM. C DIM. D JOINT FIG. NO. SIZE NET WT./LBS. INCHES INCHES INCHES INCHES 5035-3-S-BI-S 1x1"x1/2"x1/2" 0.46 1.69 1.69 0.62 0.62 SXSXFNPTXFNPT 3-3/8" Take Out 5035-3-S-BI-L 1x1"x1/2"x1/2"...

Open the catalog to page 17
