NIBCO
Ball Valve Catalog

Ball Valve Catalog

Product catalog summary

Overview: The NIBCO Ball Valves catalog is a comprehensive guide detailing the company's range of ball valves, emphasizing business-to-business solutions and technological leadership. It includes information on various types of ball valves such as bronze, carbon steel, stainless steel, and flanged ball valves, along with their specifications, options, and accessories.

Business-to-Business Solutions: NIBCO offers secure web applications through NIBCOpartner.com, providing 24/7 access to customer-specific information and online order processing. Features include online order entry, price checks, invoice viewing, and inventory availability. The Electronic Data Interchange (EDI) and Vendor Managed Inventory (VMI) enhance transaction efficiency and inventory management.

Product Specifications: The catalog details various ball valve models with one, two, and three-piece body designs, including threaded, solder, and grooved ends. Each model is identified by a figure number key, detailing body type, port size, pressure rating, and material composition. It also addresses dezincification issues in valve products.

Valve Types and Features: Sections are organized by valve materials and designs, such as bronze, carbon steel, and stainless steel ball valves, with detailed specifications including pressure and temperature ratings.

Options and Accessories: A section outlines available options and accessories for ball valves, including technical data on NIB-SEAL® and various seat materials like PTFE and RPTFE, along with a quick reference guide for ball valve options.

System Control Products: This section covers ball valve actuation and control, circuit balancing valves, and provides data sheets for actuator mounting, including torque charts and mounting data for different valve series.

Engineering Data: The catalog concludes with engineering data, including ball valve specifications, temperature limits, flow data, and installation tips, along with a comparison of figure numbers and warranty information.

Dezincification: The document discusses dezincification in brass alloys, particularly in valves produced outside the U.S., and specifies that bronze valves should contain no more than 15% zinc to prevent this issue.

Material Composition: Valves are made from materials such as zinc-plated steel, aluminum, stainless steel, brass, and bronze, with specific alloys and standards mentioned.

Dimensions and Weights: Detailed dimensions and weights for each valve type are provided, with measurements in both inches and millimeters.

Pressure and Temperature Ratings: Includes a pressure-temperature chart for detailed operating pressures, indicating the valves' suitability for various applications, including steam.

Contact Information: NIBCO's contact details are provided for further inquiries, including phone numbers and fax numbers for both domestic and international offices.

Certifications and Standards: Valves conform to MSS SP-110 standards and are CSA certified for natural and propane gas applications, also UL listed for various gas and liquid shut-off services.

Recommendations: Advises consulting MSS SP123 for pressure temperature limitations and refers to a pressure temperature chart for detailed operating pressures.

Applications: Valves are suitable for various services, including air, city gas, gasoline, liquified petroleum gas, and different grades of fuel oil.

Material Specifications: Detailed material specifications for each part of the valve, including body, stem, ball, seats, and seals, with materials like stainless steel, carbon steel, and PTFE.

Installation Tips: Emphasizes proper preparation of tube ends and cleaning of surfaces for effective soldering and brazing, with specific instructions for both methods.

Warnings and Recommendations: Provides warnings against throttling ball valves when less than 45° open and advises against throttling gate valves.

Warranty Information: NIBCO offers a 5-year warranty on pressure-rated metal valves, covering defects in materials and workmanship.

Catalog excerpts

AHEAD OF THE FLOW ® Ball Va l v e s CATALOG C-BV-0809

Open the catalog to page 1

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH:1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1.574.295.3327 • FAX: +1.574.295.3455 www.nibco.com The velocity with which e-business evolves demands that new products and services be continuously developed and introduced to keep our customers at the center of our business efforts. NIBCO provides an entire suite of business-to-business solutions that is changing the way we interact with customers. Look to NIBCO for technology leadership. Business-to-Business...

Open the catalog to page 2

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1.574.295.3327 • FAX: +1.574.295.3455 www.nibco.com 3 www.nibco.com Table of Contents Page Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Bronze Ball Valves. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44 Figure Number Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Illustrated...

Open the catalog to page 3

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1.574.295.3327 • FAX: +1.574.295.3455 www.nibco.com 4 A H E A D O F T H E F L O W® www.nibco.com Bronze Ball Valves One, Two, and Three-Piece Body Threaded, Solder and Grooved Ends Revision 11/3/2008 Bronze Ball Valve Figure Number Key T-560-BR-R-20-** BM - Butt Weld ISO Mount G - Grooved GM - Grooved ISO Mount KM - Socket Weld ISO Mount MTT - Male x Female Thread S - Solder ST - Solder x Thread T - Thread TC...

Open the catalog to page 4

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1.574.295.3327 • FAX: +1.574.295.3455 www.nibco.com 5 A H E A D O F T H E F L O W® www.nibco.com Revision 7/28/2009 One-Piece and Two-Piece Bronze Ball Valves Illustrated Index One-Piece Bronze Ball Valve Up to 600 lb. CWP Two-Piece Bronze Ball Valve 600 lb. CWP T-560-BR-20/T-560-BR-66 Sizes ¹" thru 2" Threaded Ends Page 7, 8 Two-Piece Bronze Single Union Ball Valve 600 lb. CWP T or S-585-70-SU Sizes ¹" thru...

Open the catalog to page 5

BallValveBody_0809.indd table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:3.95pt "Arial", sans-serif; } .font1 { font:4.50pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:10.00pt "Arial", sans-serif; } .font4 { font:18.00pt "Arial", sans-serif; } .font5 { font:5.00pt "Georgia", serif; } .font6 { font:5.00pt "Lucida Sans Unicode", sans-serif; } .font7 { font:6.00pt "Lucida Sans Unicode", sans-serif; } .font8 { font:8.00pt "Lucida Sans Unicode", sans-serif; } .font9 { font:12.00pt "Trebuchet MS", sans-serif; } www.nibco.com AHEAD OF...

Open the catalog to page 6

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1.574.295.3327 • FAX: +1.574.295.3455 www.nibco.com 7 A H E A D O F T H E F L O W® www.nibco.com Dezincification Resistant Bronze Ball Valves One-Piece Body • Reduced Port • Bronze Trim • Blowout-Proof Stem 600 PSI/41.4 Bar Non-Shock Cold Working Pressure CONFORMS TO MSS SP-110 T-560-BR-*-20 Threaded MATERIAL LIST PART SPECIFICATION 1. Handle Nut Zinc Plated Steel 2. Identification Plate Aluminum 3. Handle Zinc...

Open the catalog to page 7

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1.574.295.3327 • FAX: +1.574.295.3455 www.nibco.com 8 A H E A D O F T H E F L O W® www.nibco.com Dezincification Resistant Bronze Ball Valves One-Piece Body • Reduced Port • Stainless Trim • Vented Ball • Blowout-Proof Stem 600 PSI/41.4 Bar Non-Shock Cold Working Pressure CONFORMS TO MSS SP-110 T-560-BR-*-66 Threaded MATERIAL LIST PART SPECIFICATION 1. Handle Nut Stainless Steel 300 Series 2. Identification Plate...

Open the catalog to page 8

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1.574.295.3327 • FAX: +1.574.295.3455 www.nibco.com 9 A H E A D O F T H E F L O W® www.nibco.com Dezincification Resistant Bronze Ball Valves Two-Piece Body • Full Port ¹"-1" • Conventional Port 1¹"-3" • Bronze Trim • Blowout-Proof Stem 600 PSI/41.4 Bar Non-Shock Cold Working Pressure 150 PSI/10.3 Bar Saturated SteamŸ CONFORMS TO MSS SP-110 T-580-70 Threaded MATERIAL LIST PART SPECIFICATION 1. Handle Nut Zinc...

Open the catalog to page 9

NIBCO INC. WORLD HEADQUARTERS • 1516 MIDDLEBURY ST. • ELKHART, IN 46516-4740 • USA • PH: 1.800.234.0227 TECH SERVICES PH: 1.888.446.4226 • FAX: 1.888.336.4226 • INTERNATIONAL OFFICE PH: +1.574.295.3327 • FAX: +1.574.295.3455 www.nibco.com 10 A H E A D O F T H E F L O W® www.nibco.com Dezincification Resistant Bronze Ball Valves Two-Piece Body • Full Port ¹"-1" • Conventional Port 1¹"-3" • Stainless Trim • Blowout-Proof Stem • Vented Ball 600 PSI/41.4 Bar Non-Shock Cold Working Pressure 150 PSI/10.3 Bar Saturated SteamŸ CONFORMS TO MSS SP-110 T-580-70-66 Threaded S-580-70-66 Solder MATERIAL LIST...

Open the catalog to page 10
