NEOTON MOTOR
MOTOR DRIVER

MOTOR DRIVER

Product catalog summary

Overview: This document is a technical catalog for various motor drive series, including AC Servo Drives, Digital Stepper Drives, Closed-Loop Stepper Servos, and BLDC Motor Drives. It provides detailed specifications, connection interfaces, and mechanical drawings for each product series.

AC Servo Drives:

Pulse Type: Power range from 50W to 3kW, voltage of Single/Three-Phase 220V AC, RS485 communication, and control modes including Position, Speed, and Torque. Applications include CNC machine tools and robotics. Protection features include overspeed and main power overvoltage.
EtherCAT Bus Type: Similar power range and voltage, with EtherCAT communication at 100Mbps and a cycle time of <=250us. Additional protections include undervoltage and overcurrent. Suitable for multi-axis synchronous control and semiconductor equipment.

Digital Stepper Drives - CWD Series: Models like CWD556 and CWD860 support input voltages from 20-80VDC and output currents from 2.1A to 8.2A, with microstepping up to 51200 steps/rev.

Closed-Loop Stepper Servos - CWDS Series: Features encoder feedback with a resolution of 1000 PPR, operating with input voltages from 20-90VAC or 24-110VDC and output currents up to 8A.

BLDC Motor Drives:

BLD510 and GT510 Series: Designed for compact, efficient applications, supporting RS232 and RS485 communication respectively, with natural air cooling.
BLAR Series High-Power: Suitable for industrial OEM motion systems, offering continuous currents from 30 to 210 Arms and peak currents up to 300 Arms. Control modes include speed and torque control.

Specifications: The BLAR High-Power BLDC Drive Series specifies an input voltage range of 8-90 VDC and 135/180 VDC. Environmental conditions include a non-corrosive, non-flammable atmosphere, altitude below 1,000 meters, and temperature range of -20°C to +50°C.

Electrical Connections: Detailed pin configurations for connectors, including motor phases, feedback signals, control signals, and optional communication interfaces.

Mechanical Drawings & Torque Curves: References to mechanical drawings and torque curves for different models in the BLAR series.

Ordering Note: It is important to specify the NTC-resistor when ordering.

Conclusion: This catalog serves as a comprehensive guide for selecting the appropriate motor drive based on specific application requirements, offering a range of options for different industrial needs.

Catalog excerpts

MOTOR DRIVER PRODUCT CATALOG

Open the catalog to page 1

TABLE OF CONTENTS Frame Size / Series AC Servo Drives (Pulse Type) AC Servo Drives (EtherCAT Bus Type) Digital Stepper Drives Closed-Loop Stepper Servos CWDS Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BLDC Motor Drives BLAR Series High-Power BLDC Drives BLAR Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Motor Driver Product Catalog

Open the catalog to page 2

AC SERVO DRIVE -- PULSE TYPE AC Servo Drives (Pulse Type) Power: 50W - 3kW | Single/Three-Phase 220V AC | RS485 | Position / Speed / Torque Control CNC machine tools, robotics, packaging machinery, textile equipment, and precision automation requiring pulse-type closed-loop servo control with RS485 communication. Motor Driver Product Catalog

Open the catalog to page 3

Drive Type Pulse Simple-Type Pulse High-Performance Pulse Simple-Type Pulse High-Performance Pulse High-Performance Protection Functions Overspeed / Main power overvoltage / Overspeed / Main power overvoltage / Overspeed / Main power overvoltage / Overspeed / Main power overvoltage / Overspeed / Main power overvoltage / Monitor Functions Speed / Current position / Command Speed / Current position / Command Speed / Current position / Command Speed / Current position / Command Speed / Current position / Command Control Input 1: Servo enable 2: Alarm clear 3: CCW 1: Servo enable 2: Alarm clear 3:...

Open the catalog to page 4

CN1 Control signal input/output connector Control signal input/output connector Control signal input/output connector Control signal input/output connector CN2 Encoder signal connector (DB15 Female) Encoder signal connector (DB15 Female) Encoder signal connector (DB15 Female) Encoder signal connector (DB15 Female) CN3 / CN4 Communication connectors (RJ45, for Communication connectors (RJ45, for Communication connectors (RJ45, for Communication connectors (RJ45, for L1, L2 Main power input terminals Main power input terminals Main power input terminals Main power input terminals P, D, C, N Dynamic...

Open the catalog to page 5

CN1 Pins 14-26 Reserved Reserved Reserved Reserved -- CN2 Pin 1 -- 5V Encoder power +5V Encoder power +5V Encoder power +5V Encoder power +5V -- CN2 Pin 2 -- 0V Encoder power 0V Encoder power 0V Encoder power 0V Encoder power 0V -- CN2 Pin 3 -- A+ (Input) Encoder A phase positive input Encoder A phase positive input Encoder A phase positive input Encoder A phase positive input -- CN2 Pin 4 -- A- (Input) Encoder A phase negative input Encoder A phase negative input Encoder A phase negative input Encoder A phase negative input -- CN2 Pin 5 -- B+ (Input) Encoder B phase positive input Encoder B...

Open the catalog to page 6

CN2B -- -- -- -- Encoder signal connector -- connected to L1, L2, L3 -- -- -- -- Main power input terminals P, D, C, N -- -- -- -- Braking resistor connection terminals U, V, W -- -- -- -- Motor output terminals -- connect to servo PE -- -- -- -- Protective earth terminal -- connect to CHARGE LED -- -- -- -- Main circuit power indicator LED. [U+25B2] Increase key -- -- -- -- Increase parameter number or value; long [U+25BC] Decrease key -- -- -- -- Decrease parameter number or value; SET key -- -- -- -- Confirm key -- operate to confirm [U+25C4] Exit key -- -- -- -- Menu back -- operate to cancel...

Open the catalog to page 7

AC SERVO DRIVE -- PULSE TYPE P Series (Pulse) Series - Mechanical Drawings & Torque Curves Mechanical Drawings ACSDP100S-40 Motor Driver Product Catalog

Open the catalog to page 8

AC SERVO DRIVE -- ETHERCAT BUS TYPE AC Servo Drives (EtherCAT Bus Type) Power: 50W - 3kW | Single/Three-Phase 220V AC | 100Mbps EtherCAT | <=250us Cycle Time Multi-axis synchronous control, semiconductor equipment, laser cutting, and high-speed automation requiring EtherCAT bus servo drives with sub-millisecond cycle time. Motor Driver Product Catalog

Open the catalog to page 9

AC SERVO DRIVE -- ETHERCAT BUS TYPE P Series (EtherCAT) Series Parameter Output Power Input Voltage Full Specifications Model Drive Type Control Mode Protection Functions Position (PP) / Speed (PV) / Torque (PT) / JOG (HM) / Trial Run / CSP / Position (PP) / Speed (PV) / Torque (PT) / JOG (HM) / Trial Run / CSP / Position (PP) / Speed (PV) / Torque (PT) / JOG (HM) / Trial Run / CSP / Overspeed / Main power overvoltage / Undervoltage / Overcurrent / Overspeed / Main power overvoltage / Undervoltage / Overcurrent / Overspeed / Main power overvoltage / Undervoltage / Overcurrent / Monitor Functions...

Open the catalog to page 10

AC SERVO DRIVE -- ETHERCAT BUS TYPE P Series (EtherCAT) Series (cont.) Parameter Control signal input/output connector Control signal input/output connector Encoder signal connector -- connected to motor encoder Encoder signal connector -- connected to motor encoder EtherCAT Fieldbus Input Port (RJ45) EtherCAT Fieldbus Input Port (RJ45) EtherCAT Fieldbus Output Port (RJ45) EtherCAT Fieldbus Output Port (RJ45) Main power input terminals Main power input terminals External braking resistor terminals External braking resistor terminals Servo motor output terminals -- connect to U, V, W phases of...

Open the catalog to page 11

AC SERVO DRIVE -- ETHERCAT BUS TYPE P Series (EtherCAT) Series (cont.) Parameter Analog input 2+ / Pulse input+ Analog input 2+ / Pulse input+ Analog input 2- / Pulse input- Analog input 2- / Pulse input- Signal ground Signal ground Protective Earth Protective Earth Control signal input/output port CN1 Shell -- PE Cooling Connector Interface -- ACSDP200E CN1 Motor Driver Product Catalog

Open the catalog to page 12

AC SERVO DRIVE -- ETHERCAT BUS TYPE P Series (EtherCAT) Series (cont.) Parameter Encoder signal port -- connected to incremental encoder Encoder signal port -- connected to absolute value encoder EtherCAT communication input port (RJ45) EtherCAT communication output port (RJ45) Main power input terminals External regenerative resistor terminals Servo motor connection terminals -- connect to servo motor U, V, W Protective Earth (ground) terminal -- connect to power supply and motor Main circuit power indicator. Indicates main circuit capacitor is charged. ECAT IN port status indicator Left LED...

Open the catalog to page 13
