Product catalog summary

Specifications:
The document details equipment and accessories for fluid control and contamination analysis in hydraulic systems. It includes mobile units for optical contamination measurement on 47 mm membranes, particle counters calibrated to ISO 11171 standards, and mobile filter units with various flow rates and motor types. Vibration-dampened rings are mentioned for mounting single pump units on tank covers, with a power range from 0.5 to 22 kW using UNEL-MEC electric motors, focusing on reducing vibration to enhance performance and longevity.

Procedures:
The equipment supports static and dynamic sampling of oils in hydraulic systems and tanks. Particle counters provide contamination data in ISO 4406, NAS 1638, and AS4059 formats, with options for temperature and humidity sensors.

Standards:
References include ISO 11171 for particle counter calibration and ISO 4406, NAS 1638, and AS4059 for contamination reporting standards.

Recommendations:
It is recommended to use specific accessories like metal and nylon filler plugs, air filters, and oil level gauges for optimal performance. The importance of using appropriate bell-housings and couplings for power transmission is also highlighted.

Key Data from Tables and Diagrams:
- Mobile filter units offer flow rates from 15 l/min to 200 l/min, with options for single-phase, three-phase, and direct current motors.
- Particle counters operate under pressures from 2 bar to 400 bar.
- Accessories include metal clamps for pipe fitting, electrical level gauges, and vibration-dampened brackets for pipe installation.

Critical Information:
- Ensure compatibility with ISO standards for accurate contamination analysis.
- Select appropriate motor and pump configurations based on system requirements.
- Utilize recommended accessories to maintain system integrity and performance.

Overview:
MP Filtri, with over forty years of experience in the hydraulic filtration market, offers a comprehensive range of products for various sectors. Since 1964, the company has focused on the study, design, development, and production of hydraulic filters, power transmission components, and accessories.

Quality Standards:
MP Filtri has achieved ISO 9001 Quality System certification and Vision 2000 certification, reflecting its commitment to quality control and adherence to international standards.

Research and Development:
The company emphasizes continuous research and development to tailor products to specific market requirements, ensuring it remains at the forefront of technological advancements in hydraulic filtration.

Market Presence:
MP Filtri has a strong global presence with branches in Italy, the UK, the USA, Canada, and Germany, and aims to expand into new markets by providing high-quality, state-of-the-art products.

Catalog excerpts

Programma di produzione 7-01-2007 14:30 Pagina 3 (1,1) La qualitԠ costituisce la caratteristica essenziale ditutti i prodotti. La serie di analisi, verifiche e controlli ai quali la MP Filtri sottopone i sui prodotti un esempio eloquente di quella vocazione alla qualit che da sempre caratterizzata lo spirito aziendale.La forte sensibilit蠠 da sempre dimostrata nei confrontidi questa problematica, ha consentito alla MP Filtri di ottenere nel corso degli ultimi anni la certificazione dic o n f o rmit del Sistema Qualit ISO 9001 e lac e rtificazione piuࠒ recente Vision 2000, alle cuinormative si...

Open the catalog to page 2

Programma di produzione 7-01-2007 14:30 Pagina 3 (3,1) Ein wesentliches Merkaml all unserer Produkte ist ihreQualitt. Die zahlreichen Analysen, Untersuchungen und Kontrollen, denen MP Filtri seine Produkte unterzieht,sprechen fr das ausgepr伤gte Qualittsbewusstsein, das seit jeher bedeutender Teil unsere r Firmenphilosophie ist.Diesem Qualittsbewusstsein verdankt MP Filtri auchdie bereits vor einigen Jahren m䤼helos erlangteZ e rt i f i z i e rung seines Qualittsmanagementsystemsgem䤟 ISO 9001 und die gem der neueren ISO9001:2000, der alle Prozesse und Standards imUnternehmen unterliegen.Den Kunden...

Open the catalog to page 3

Programma di produzione 7-01-2007 14:30 Pagina 5 (1,1) Filtri inAspirazione Filtresd a s p i r a t i o n Saugfilter Suctionfilters STR > Filtro in aspirazioneimmerso portata fino a 900 l/min (238 gpm) connessioni filettate da 1/2Ҕ a 3 BSP/NPT.Filtre dԒaspirationimmerg, dbit 900l/min (238 gpm) raccords filet驩s 1/2 Ԡ 3 BSP / NPT.SaugkԶrbe, im Tank unterlniveau eingebaut, Volumenstrom bis 900l/min (238 gpm), Gewindeanschlּsse von 3/8 bis 3Ԕ BSP/NPT.Submerged suctionfilter, flow rates up to 900 l/min (238 gpm) threaded connections from1/2 to 3Ԕ BSP/NPT. SF2 250 > Filtro in aspirazionesemi immerso...

Open the catalog to page 4

Programma di produzione 7-01-2007 14:30 Pagina 7 (1,1) Filtri inPressione Filtres pression Druckfilter PressureFilters > Filtro in linea pressionedi lavoro 110 bar (1570 psi) portata fino a 90 l/min (24 gpm) connessioni filettate da 1/2 BSP/NPT/SAE.Filtre en ligne, pressionde service 110bar (1570 psi), dԩbit 90 l/min (24gpm), raccords filets 1/2 BSP/NPT/SAE.Leitungsfilter, max.Betriebs锼berdruck 110bar (1570 PSI), Volumenstrom bis 90l/min (24 gpm), Gewindeanschlsse 1/2 BSP/NPT/SAE.In-line filter, workingpressure 110bar (1570 psi) flow rates up to 90l/min (24gpm) 1/2씔 BSP/NPT/SAE threaded connections....

Open the catalog to page 6

Filtro in linea pressionedi lavoro 420 bar (6000 psi) portata fino a 475 l/min (126 gpm) connessioni filettate fino a 1 1/2 BSP/NPT/SAE e flangiate fino a 1 1/4Ԕ SAE 6000 PSI. Filtre en ligne, pressionde service 420 bar (6000 psi), dbit 475l/min (126gpm), raccords filets 1 1/2驔 BSP/NPT/SAE et brides 1 1/4SAE 6000 PSI.Hochdruck-Leitungsfilter, max. BetriebsԼberdruck 420 bar (6000 PSI), Volumenstrom bis 475l/min (126 gpm), Gewindeanschlsse bis 1 1/2 BSP/NPT/SAE und Flanschanschl씼sse bis 1 1/4SAE 6000 PSI. In-line filter, workingpressure 420 bar (6000 psi) flow rates up to 475l/min (126gpm), threaded...

Open the catalog to page 7

Programma di produzione 7-01-2007 14:30 Pagina 9 (1,1) Filtri inPressione Filtres pression Druckfilter PressureFilters > Filtro in linea pressionedi lavoro 350 bar (5000 psi) portata fino a 500 l/min (133 gpm) connessioni filettate 1 1/2 BSP/NPT/SAE e flangiate 2Ԕ SAE 6000 PSI a piastra. Filtre en ligne, pressionde service 350 bar (5000 psi), dbit 500 l/min (133gpm), raccords filets 11/2驔 BSP/NPT/SAE et brides 2 SAE6000 PSI sur plaque.Hochdruckfilter, max.BetriebsԼberdruck 350bar (5000 PSI), Volumenstrom bis 500l/min (133 gpm), Gewindeanschlsse 11/2 BSP/NPT/SAE, Flanschanschl씼sse 1 1/2 SAE6000...

Open the catalog to page 8

Filtro in linea semplicee doppio pressione di lavoro 35 bar (500 psi) portata fino a 1200 l/min (318 gpm) connessioni filettate 3/4 e 2Ԕ BSP/NPT/SAE e flangiate fino a 3 SAE 3000 PSI. Filtre en ligne simple etdouble, pression de service 35 bar (500psi), dԩbit 1200l/min (318gpm), raccords filets 3/4 et 2锔 BSP/NPT/SAE et brides 3SAE 3000PSI. Niederdruckleitungsfilter ,einfach oder umschaltbar, max. BetriebsԼberdruck 35bar (500 PSI), Volumenstrom bis 1200l/min (318gpm), Gewindeanschlsse 3/4 bis 2씔 BSP/NPT/SAE und Flanschanschlsse bis 3SAE 3000PSI. Single and double in-line filters, working pressure...

Open the catalog to page 9

Programma di produzione 7-01-2007 14:30 Pagina 11 (1,1) Filtri Spin-on Filtres visser Spin-on-Filter Spin-onfilters > Filtro in linea Spin-Onpressione di lavoro35 bar (508 psi) portata fino a 300 l/min (80 gpm) connessioni filettate da 3/4 e 1 1/2ԔBSP/NPT/SAE.Filtre en ligne Spin-On,pression de service35bar (508 psi), dbit 300l/min (80gpm),raccords filets 3/4驔 et1 1/2 BSP/NPT/SAE.Spin-on-Leitungsfilter,max. BetriebsԼberdruck35 bar (508 psi), Volumenstrom bis300 l/min (80 gpm),Gewindeanschlsse von 3/4 bis 1 1/2씔BSP/NPT/SAE.In-line filter Spin-On,working pressure35bar (508psi) flow rates up to...

Open the catalog to page 10

Programma di produzione 7-01-2007 14:30 Pagina 11 (3,1) MPFiltri progetta, sviluppa, realizza tutti i prodotti, controllando lintero processo produttivo tramite la propria fonderia di alluminio, il reparto delle presse ad iniezione plastica, lҒofficina per le lavorazioni meccaniche, le linee per la realizzazione degli elementi filtranti e lassemblaggio finale del prodotto. La gamma dei componenti MPFiltri Ҩ destinata alla realizzazione di sistemi oleoidraulici industriali e per le applicazioni su macchine operatrici mobili MPFiltri conoit, dveloppe et fabrique tous sesproduits et contr穴le la...

Open the catalog to page 11

Programma di produzione 7-01-2007 14:30 Pagina 13 (1,1) ContrledesFluidesControllodeiFluidi Fluid-Controlling FluidControl > Contatore di particellecalibrato secondo ISO 11171, pressione di lavoro da 2 bar (28 psi) a 400 bar (5715 psi). Dati di contaminazione in accordo con alla normativa ISO 4406, NAS 1638 e AS4059. Sensori per la rilevazione della temperatura e dellumidit䒠 residua nellolio. Compteur de particulescalibrҩ ISO11171, pression de service 2 bar (28psi) - 400bar (5715psi) Taux de contamination conforme aux normes ISO 4406, NAS 1638 et AS4059. Capteurs de temprature et dhumidit钩 rsiduelle...
