Moyno, Inc. offers a line of grindingequipment that meets the broad needs of any industry requiring solids reduction or waste condition- ing. With superior engineering and the most diverse line of grinder equipment available, Moyno has the technology to meet your grinder challenge. Backed by years of experience, Moyno sets the standard in grinding equipment. The Moyno > ή Annihilator grinder,with patented spacer cutters, ensures that harsh solids in the primary sludge stream are ground uniformly and efficiently. The Moyno > ٮ Pipeliner continues to surpass all other technologies when it comes...

Ι Municipal Applications Sewage screening from gravityor conveyor systems at lift or pump stationsՕ In-channel raw sewage at treat-ment plants and correctional institutions Primary and secondary sludgetransfer from sedimentation prior to dewateringՕ Solids reduction in wastewaterdischarged from rest areas along highways and mobile home parks Food Processing Vegetable and fruit waste Օ Poultry waste Pulp and Paper Paper and stock waste Hazardous Waste Օ Solids reduction in paint andother chemical waste Solids entrained in waste fuels Chemical Օ Gum-like polymers ground tosmall size for processing...

The Moyno Annihilator utilizes the field-proven counter-rotating, hexagonal shaft design with inter- meshing cutters and spacers. The Annihilator vastly increases the cutting capabilities of other commonly available twin shaft grinders by utilizing cutting teeth on the spacers, thereby improving the cutting efficiency while decreasing the particle size processed through the unit. This patented design also eliminates the greatest cause of failure of conventional units that of stringy material wrapping around the spacers, causing seal failure, mechanical seizure and ultimately, shaft fracturing.The...

FEATURESBENEFITS Improved counter-rotating, twin shaft grinder Rugged and reliable grinder designed to efficiently reduce the size of large solids entrained in fluid flows in a wide variety of applicationsՕProtects downstream equipment from being plugged or damaged from large solids, thus reducing expensive repairs and down-time Slow rotating cutters do the best job on large and dense solids, resulting in Better cleaning of stringy and plastic materials lower total cost ՕImproved cutting efficiency with over double the cutting edges ՕOther cutter combinations, including 11-tooth cam cutters,...

The Moyno > ή Pipeliner has beenproven in thousands of applica- tions worldwide. The Pipeliner design consists of a single shaft rotating a headstockՕ The headstock contains tungstencarbide-tipped cutting edges running against a hardened tool steel shearplate The shearplate contains holesthat allow fluid to pass through. Anything that goes through the Pipeliner must go through these holesՕ As string and other debris passthrough the holes, they are severed by the rotating cutting edge of the headstock. Large pieces of wood or plastic are pushed toward the holes, chipped and hammered into small...

The technologically advanced headstock and shearplate offer the following benefits: Wear-compensating, spring-loaded headstock assembly maintains constant force against the shearplate and produces consistent particle size regard- less of cutter wearՕ Shearplate acts as a screen,rejecting stones, cans, large pieces of metal and wood that may damage pumps, filters, valves and other equipment Tungsten carbide cutters remainin contact with the shearplate for the life of the cutter, eliminating the need for adjustmentՕ Quick, on-site cutter replacementwithout disconnecting piping Headstock, shearplate...

For information about Moyno products or for technical assistance, contact:Moyno, Inc.P.O. Box 960 Springfield, OH 45501-0960 U.S.A. Telephone: 1-877-4UMOYNOFacsimile: 937-327-3572E-Mail: [email protected] Note: Information contained herein is subject to change without notice. Beforemaking a final product selection, please contact your Moyno representative. Your Moyno Authorized Distributor/Representative is: > թ 2008 by Moyno, Inc. Moyno is a registered trademark of Moyno, Inc. Printed in U.S.A.3M PTD 208 TM Annihilator is a trademark of Moyno, Inc.Moyno, Inc. is part of the Fluid Management...
