Moyno 2000 CC Brochure
8Pages

Moyno Sets the Standard > Moyno ή 2000 pumps set the standard in positive displacement pumping applications. The proprietary Moyno 2000 gear-type universal joint design effectively handles radial and thrust loads for maximum performance and long life. These rugged pumps are able to handle abrasive materials in excess of 80% solids and offer a performance range to 4,500 GPM with pressure to 1,500 PSI. By incorporating advanced technology, superior design and proprietary manufacturing processes, Moyno 2000 pumps offer the best value, and the most effective pumping solutions for the most...

Ε Stator elastomers formulated for specific fluid conditions Over 40 stator elastomers availableՕ Highly researched formulationsprovide optimal blend of poly- mers and special ingredients Outstanding performance andlong service life Օ Optimized geometric profiles for rotor and stator High capacity, high efficiency,low internal velocities, minimal slip and low abrasive wearՕ Available in 1:2 and 2:3 geome-tries for a broader application range Superior feed and flow efficiencyՕ Widest selection of auger feedtechnologies Available in open throat, bridgebreaker and twin screw feeder...

Fluid Type: Broad range of viscosities and solids Fluid Supply: Via standard pipe Benefits: Robust design with bearings integral to the pump Typical Applications: OilsՕ Polymers Municipal sludge to 10% solids Օ Titanium Dioxide Paper coatings Օ Mining slurries > Fluid Type: Broad range of viscosities and solids Fluid Supply: Via standard pipe Benefits: Best value for majority of applications Typical Applications: Municipal sludge to 10% solidsՕ Scum and grease Dewatering equipment feeding Օ Lime slurry transfer and dosing Polymer transfer and dosing Օ Chemical metering and transfer Influent...

Fluid Type: Viscosity and solids where open inlet is required Fluid Supply: Via wide open-throats and chutesՕ Capable of varying length to match wide feed areas from centrifuges and 1-, 1.5-, and 2-meter length belt filter presses Benefits: Single auger feed mechanism to stuff product into the pump elements forincreased fill efficiency Օ Wide open-throat minimizes plugging that could occur in a standard inlet Typical Applications: Heavy clay slurriesՕ Gypsum Grout Օ Grape must Municipal GBT sludge Օ Municipal sludge to 15% solids Thick industrial sludges > Fluid Type: Medium- to...

Integrated Touch Screen Control > Fluid Type: High-viscosity and high-solids Fluid Supply: Via suction hopper of Twin Screw Feeder (TSF) and chutesՕ Capable of varying TSF length to match wide feed areas from centrifuges and 1- through 3-meter length belt filter presses Benefits: Twin Screw Feeder Capable of varying auger sizes without changing pump arrangement to matchthe width of the TSF opening to the drop zone Օ Concentric rotation in a close tolerance pressure tube allows the TSF to gener-ate positive stuffing pressure to the pump inlet (normally between 10 to 30 PSI at the pump inlet)...

Fluid Type: Low- to medium-viscosity and large solids Fluid Supply: Via standard pipe Benefits: Е Universal joint is out of flow path for unobstructed flow to pump cavity inlet 45հinlet lowers friction loss and provides for more gentle handling of product Patented auger feed on rotor head stuffs product directly into the cavity without obstruction Typical Applications: Օ Vacuum applications from deaerator and evaporators Scum transfer Օ Thick adhesives Municipal sludge in excess of 10% solids Օ Whole fish > Your critical applications demandprompt, responsive service and support. Our network...
