SKA_ROTARY
1 / 24 PagesView full catalog
SKA_ROTARY
Product catalog summary
Introduction
The document introduces the SKA Rotary Table series by Motor Power Company, emphasizing its direct drive technology that provides high torque and precision without backlash. These rotary tables are versatile for various applications and can be used with or without an amplifier.
The document introduces the SKA Rotary Table series by Motor Power Company, emphasizing its direct drive technology that provides high torque and precision without backlash. These rotary tables are versatile for various applications and can be used with or without an amplifier.
Direct Drive Technology
The SKA Rotary Tables offer peak torque up to 2400 Nm, speeds up to 1400 RPM, and precision with over 1,000,000 PPR. They ensure absolute accuracy of ±25 and 11 arc seconds, enhancing positioning accuracy and eliminating backlash.
The SKA Rotary Tables offer peak torque up to 2400 Nm, speeds up to 1400 RPM, and precision with over 1,000,000 PPR. They ensure absolute accuracy of ±25 and 11 arc seconds, enhancing positioning accuracy and eliminating backlash.
Technical Improvements
The direct drive system simplifies machine structure, reduces noise, and eliminates lubrication needs, making it suitable for cleanroom environments. It features a compact design, easy wiring, and high energy efficiency.
The direct drive system simplifies machine structure, reduces noise, and eliminates lubrication needs, making it suitable for cleanroom environments. It features a compact design, easy wiring, and high energy efficiency.
Product Lineup
The document details various SKA Rotary Table models, including their stall torque, peak torque, speed, poles, inertia, weight, and dimensions, tailored for specific applications and performance needs.
The document details various SKA Rotary Table models, including their stall torque, peak torque, speed, poles, inertia, weight, and dimensions, tailored for specific applications and performance needs.
Specifications and Ratings
Each model, such as SKA RT 90, 148, 245, 335, and 430, has detailed specifications including stall torque, peak torque, nominal torque, current ratings, speed, torque constant, and thermal resistance, essential for selecting the appropriate model for specific uses.
Each model, such as SKA RT 90, 148, 245, 335, and 430, has detailed specifications including stall torque, peak torque, nominal torque, current ratings, speed, torque constant, and thermal resistance, essential for selecting the appropriate model for specific uses.
Applications
The SKA Rotary Tables are applicable in semiconductor manufacturing, electronic parts assembly, packaging machinery, and alternative energy sectors.
The SKA Rotary Tables are applicable in semiconductor manufacturing, electronic parts assembly, packaging machinery, and alternative energy sectors.
Feedback and Wiring
The document provides detailed feedback specifications and wiring connections for proper installation and operation of the rotary tables.
The document provides detailed feedback specifications and wiring connections for proper installation and operation of the rotary tables.
Conclusion
The SKA Rotary Tables by Motor Power Company offer a versatile and efficient solution for high-precision applications, focusing on energy efficiency and simplified machine integration.
The SKA Rotary Tables by Motor Power Company offer a versatile and efficient solution for high-precision applications, focusing on energy efficiency and simplified machine integration.
Flexi Pro Servo Drive Overview
The document outlines the technical specifications and features of the Flexi Pro Servo Drive, including connectivity options, software capabilities, and power requirements, along with details on cables, connectors, and optional network communication interfaces.
The document outlines the technical specifications and features of the Flexi Pro Servo Drive, including connectivity options, software capabilities, and power requirements, along with details on cables, connectors, and optional network communication interfaces.
Specifications
- Supply Voltage: Options of 230VAC and 380VAC.
- Control Voltage: 24 VDC with ±20% tolerance.
- Rated Current: Varies by model, from 5 A rms to 40 A rms.
- Dimensions: Varying dimensions, e.g., 200 x 54 x 200 mm for some models.
- Weight: Ranges from 1.8 kg to 13 kg depending on the model.
Features
- Integrated brake chopper and EMC filters.
- UL standard modules and free configuration software.
- Multilingual software with automatic commissioning guidance.
- Integrated safety functions according to EN-954-1 category.
Software Capabilities
- Automatic identification of connected servo positioning controller and motor.
- Loading and saving of parameter sets.
- Motion control with speed, torque, and positioning controller.
- 256 freely programmable position sets and various homing methods.
Connectivity
- Standard interfaces include RS 232, CAN bus, and Profibus.
- Optional network communication via Profibus DP and EtherCat.
- EtherCat interface supports cyclic and acyclic data transmission.
Cables and Connectors
- Signal and power cables available in various lengths with specific order codes.
- Flying connectors M23 and optional network connection interfaces available.
Contact Information
The document lists contact details for Motor Power Company offices in Italy, China, and Germany.
The document lists contact details for Motor Power Company offices in Italy, China, and Germany.
