Table Top Conveyor

Product catalog summary

Standard Conveyor Components for Table Top Chain

This document outlines the essential components used in standard conveyors designed for Table Top Chain systems.

1. Drive Unit

The drive unit is the primary mechanism responsible for powering the conveyor chain, ensuring movement and operation of the conveyor system.

2. Idler End

The idler end serves as the opposite end to the drive unit, providing tension and support to the conveyor chain.

3. Beam

The beam acts as the structural support for the conveyor, maintaining alignment and stability of the conveyor components.

4. Wheel Bend

The wheel bend allows the conveyor chain to change direction smoothly using wheels to guide the chain around bends.

5. Plain Bend

The plain bend facilitates directional changes in the conveyor path without additional guiding wheels, suitable for certain chain types.

6. Vertical Bend

The vertical bend enables the conveyor chain to navigate vertical directional changes, allowing elevation adjustments in the conveyor layout.

Chain Type

The document references the specific chain type used in the conveyor system, which is critical for compatibility with the components.

7. Conveyor Support

Conveyor supports provide foundational stability and maintain the conveyor's position and height.

8. Conveyor Guide

Conveyor guides ensure the chain remains on track during operation, preventing derailment and maintaining smooth movement.

Catalog excerpts

standard conveyor components for, Tabic Top Chain vMODU A SUrvp&Lcity/ • SodutUxns/

Open the catalog to page 1

Modular TTC Conveyor System This system integrates the main components of the TTC conveyor into an easy-to-install solution. All components are designed and manufactured in Malaysia. It is designed for flexibility and is compatible with most standard chains available on the market for quick delivery. For optimal performance and suitable chain selection, please contact the MODU System sales representative to ensure the best match for your application.

Open the catalog to page 2

Part Number Description Part Number Part Number Description Part Number Direct Drive, TT325 DD R/L Combined Drive, TT325 DT R/L Intermediate Drive, TT325 Dl R/L Suspended Drive, TT325 DS R/L Catenary Drive TT325 DC R/L Direct Drive, TT450 DD R/L Combined Drive, TT450 DT R/L Suspended Drive TT450 DS R/L Direct Drive, Combined Drive Direct Drive, Combined Drive Innovative Solutions For a Competitive Industry In today's highly competitive marhet,MODU System has introduced a new series designed to meet the evolving needs of modern industries. The TableTop Conveyor (TTC) has become an essential component,...

Open the catalog to page 3

8. CONVEYOR GUIDE The TTC conveyor system also includes various types of support structures, designed to be compatible with nearly all conveyor systems available on the market. MODU System also offers a wide range of guides that can be directly applied to TTC conveyors Below are several guide types that are well-suited to meet specific customer requirements.

Open the catalog to page 4
