• Diesel-powered articulated chassis with permanent 4-wheel drive.
• Fail-safe, wet multi-disc service brakes with an additional fail-safe emergency-parking brake.
• Heavy-duty alloy profile feeder with stainless steel guide surfaces for improved performance and reduced operation costs.
• Hydraulic joystick steering with full proportional control and shock protection.
• Minimum tramming height: 1.72 m.
• Ergonomic, fully adjustable operator seat with suspension and hydraulically adjustable operator’s protection canopy conforming to FOPS & ROPS regulations.
• B 40L head rotation boom with full automatic parallelism in both planes, also usable for cross-cutting.
• Reliable hydraulic controls ensuring low operating costs and high performance.
• Rotary-percussive rockdrill by Boart Longyear.
• F 7000 series alloy feed, 12ft.
• Deutz diesel engine.
• Tires: 14.00 x 24.
• Typical installed power: 63 kW.
• Dana Off-Highway Powershift Transmission, Torque Converter, and Drive Axles.
• Axial-piston pump with load sensing controls.
• Water booster pump for hole flushing and air compressor for rockdrill lubrication and hole cleaning.
• Tramming and working lights, fire suppression system.

• Face Master 1.7: Low profile single boom drill jumbo.
• Air conditioning for drilling and tramming operations.
• Feeder options: 8ft, 10ft, 14ft.
• Electric cable reel with electric cable and water hose reel with water hose.
• Automatic centralized lubrication system and mist air system.
• Fire detection system.
• B 40L boom with 1500mm extension.
• Additional recirculation independent hydraulic filtration system for both tramming and drilling systems.
• Voltage customizable to customer’s requirements.
• Rotary-percussive rockdrill by Montabert.
• Rod adding system.

• Boom extension: 1000/1500 mm.
• Boom Lift: +40 /-30°.
• Boom Swing: ± 40°.
• Feeder Rotation: 360°.
• Feeder Crowd: 1500 mm.
• Feeder Swing: ± 40°.
• Feeder Tilt: 0-90°.

• Width: 2.20 m.
• Length: 13.40 m.
• Height min.: 1.72 m.
• Weight: 18,000 kg.
• Min. seam width: 4.5 m.
• Gradeability: 15°.
• Cross-grade: 8°.
• Turning radius: Not specified.
