M 320 Condenser Miniature Microphone with omni directional polar pattern • transformerless output • modern small membrane capsule Delivery Studio condenser microphone Wooden case dark bronze Matched pair of miniature microphones Wooden case dark bronze Accessories Windscreen Popscreen Elastic suspension Microphone holder Microphone bars 0.57 m Connection cable 10 m Connection cable 10 m Order.-Nr. 202401 Order.-Nr. 600097 Order.-Nr. 202358 Order.-Nr. 202303 Order.-Nr. 600177 Order.-Nr. 202212 Order.-Nr. 20221

Technical specifications Condenser Miniature Microphone Polar pattern Acoustical operating principle Frequency range Sensitivity at 1 kHz Output impedance Equivalent loudness level due to inherent noise Signal-to-noise-ratio (re. 1 Pa at 1 kHz) Max. SPL for THD < 0,5% Total dynamic range of the microphone amplifier Current consumption Output connector CCIR 468-4 DIN EN 60651 CCIR-weighted A-weighted M 320 Omni Pressure transducer 20 ... 20000 Hz 16 mV/Pa 100 Ω 25 dB 14 dB-A 69 dB 80 dB 144 dB 130 dB 3,3 mA 3-pin XLR-connector goldplated contacts 125 g 130 mm x 21 mm Frequency responses and polar...
