EVERY THING ULTRA SONIC Extract from our online catalogue: cube ultrasonic sensors Current to: 2023-1 1-13 microsonic GmbH / PhoenixseestraRe 7 / 44263 Dortmund / Germany / T +49 231 975151-0 / F +49 231 975151-51 / E info@microsonic.de microsonic® is a registered trademark of microsonic GmbH. All rights reserved.

cube ultrasonic sensors – easy installation: no tools required thanks to QuickLock mounting bracket. Cubic miniature housing Sensor head Easily visable LED display Convenient QuickLock mounting bracket UL gelisted  to Canadian and US safety standards IO-Link interface Smart Sensor Profiles for support of the new industry standard  more transparency between IO-Link Devices 1 Push-Pull switching output 1 Push-Pull switching output and 1 analogue output 3 detection ranges with a measurement range of 65 mm to 5 m microsonic Teach-in by using button T1 and T2 Temperature compensation for...

micro/onic cube ultrasonic sensors

Description The cube ultrasonic sensors are designed in a cubic housing for demanding applications. The cube is available with the QuickLock mounting bracket. This allows the sensor to be mounted quickly and easily. cube sensor with QuickLock mounting bracket The cube can be easily turned in 5 positions thanks to the rotating sensor head. The convenient mounting allows flexible use in numerous applications. Four LEDs show all operating states in any mounting position. The sensor status is clearly visable. There are two output stages available: 1 Push-Pull switching output in pnp- or...

cube sensor using alignment assistance Using the two Teach-in buttons T1 and T2 the cube sensors can be be easily set (microsonic Teach-in). IO-Link cube ultrasonic sensors support IO-Link in version 1.1 as well as Smart Sensor Profile. Set cube sensor via Teach-in procedure The cube sensors with switching output have three operating modes:  Single switching point (Method A and B) Two-way reflective barrier Window mode The operating mode single switching point (Method A) is suitable for applications, in which the actual distance to the object is also the switching point. A typical...

Teach-in of a switching point Method A and Method B The operating mode single switching point +8 % (Method B) is recommended by objects, which move into the detection area from the side. In this case the switching distance is set 8 % further than the actual measured distance to the object. This ensures a reliable switching distance even if the height of the objects varies slightly. Teach-in of a single switching point (Method A)  Place object to be detected (1) at the desired distance Push button T2 for about 3 seconds Then push button T2 again for about 1 second Teach-in of a switching...

Push button T2 for about 3 seconds Then push button T2 again for about 10 seconds Teach-in of a two-way reflective barrier For setting the analogue output  Initially position the object to be detected to the sensor-close window limit (1) Push button T1 for about 3 seconds Then move the object to the sensor-distant window limit (2) Then push button T1 again for about 1 second Teach-in of an analogue characteristic or a window with two switching points For configuration of a window with two switching points on a single switching output, the procedure is the same as setting the analogue...

LinkControl permits comprehensive parameterisation of cube ultrasonic sensors via the LinkControl-Adapter LCA-2 which connects the sensors to the PC. Sensor connected to the PC via LCA-2 for programming Easy to synchronise If several cube ultrasonic sensors are operated in one application, the can be synchronised via pin 5 to prevent. If more than 10 sensors must be synchronised, this can be carried out with the SyncBox1 which is available as an SyncBox1, accessory. Synchronisation via pin 5 is also possible in IO-Link mode. © 2023 microsonic GmbH Imprint microsonic GmbH Phoenixseestraße 7...

Your sales contact: T +49 231 97 51 51 27 E vertrieb@microsonic.de Contact form micro/onic cube ultrasonic sensors

scale drawing detection zone 1 x Push-Pull measuring range design operating mode particularities ultrasonic-specific means of measurement transducer frequency blind zone operating range maximum range resolution reproducibility accuracy 65 - 600 mm cuboidal lO-Link proximity switch/reflective mode reflective barrier window mode kleine quaderformige Bauform lO-Link Version 1.1 Smart Sensor Profile UL Listed QuickLock-Montagehalterung echo propagation time measurement 400 kHz 65 mm 350 mm 600 mm 0.056 mm ± 0.15 % ± 1 % (temperature drift internally compensated) electrical data operating...

micro/onic cube ultrasonic sensors

technical features/characteristics temperature compensation controls scope for settings Synchronisation multiplex indicators particularities yes 2 push-buttons Teach-in via push-button Teach-in via com input on pin 5 LCA-2 with LinkControl lO-Link yes yes 2 x LED green, 2 x LED yellow kleine quaderformige Bauform lO-Link Version 1.1 Smart Sensor Profile UL Listed QuickLock-Montagehalterung The content of this document is subject to technical changes. Specifications in this document are presented in a descriptive way only. They do not warrant any product features. cube ultrasonic sensors

scale drawing detection zone □ 600 mm measuring range design operating mode particularities 65 - 600 mm cuboidal lO-Link proximity switch/reflective mode reflective barrier window mode analogue distance measurement kleine quaderformige Bauform lO-Link Version 1.1 Smart Sensor Profile UL Listed QuickLock-Montagehalterung 2. Ausgang umschaltbar ultrasonic-specific means of measurement transducer frequency blind zone operating range maximum range reproducibility accuracy echo propagation time measurement 400 kHz 65 mm 350 mm 600 mm ± 0.15 % ± 1 % (temperature drift internally compensated)...

micro/onic cube ultrasonic sensors

housing material ultrasonic transducer class of protection to EN 60529 operating temperature storage temperature weight PA polyurethane foam, epoxy resin with glass contents IP 67 -25°C to +70°C -40°C to +85°C 120 g technical features/characteristics temperature compensation controls scope for settings Synchronisation multiplex indicators particularities yes 2 push-buttons Teach-in via push-button Teach-in via com input on pin 5 LCA-2 with LinkControl IO-Link yes yes 2 x LED green, 2 x LED yellow kleine quaderformige Bauform IO-Link Version 1.1 Smart Sensor Profile UL Listed...
