MICROS General Catalogue

Product catalog summary

Company Overview

MICROS, established in 1994 and ISO 9001 certified since 2004, specializes in manufacturing microscopes and microtomes for medical, biological, and industrial laboratories. The company focuses on ergonomic design, advanced optics, and high-quality customer service.

Product Categories and Key Specifications

Biological Microscopes

PINK MC50: Routine lab microscope with achromatic objectives (4x–100x oil immersion), Abbé condenser (n.A. 1.25), widefield eyepieces, binocular Siedentopf head, quadruple nosepiece, mechanical stage, and 6V 20W halogen illumination. Optional LED lighting and lockable eyepieces available.
POPPY MC50 BAT / SUNBURST MC50 SOLAR: Cordless biological microscopes designed for field use with LED illumination powered by rechargeable lithium batteries or solar modules, offering 6–8+ hours operation.
PETUNIA MCX50 & DAFFODIL MCX100: Reliable all-round microscopes with ICO Plan Infinitive objectives, Koehler illumination, widefield eyepieces, and multiple optional attachments including phase contrast, darkfield, and photo/video capabilities.
CROCUS II MCX100 LCD: Advanced digital microscope featuring an 8.4-inch TFT LCD touchscreen, 2MP CMOS camera, real-time image processing, wireless connectivity, video recording, and calibrated measurement tools.
ROSE MC300 & ORCHID MCX300: Standard and advanced models with ICO Plan Infinitive optics, Koehler illumination, quintuple nosepieces, innovative glass stages, and options for fluorescence, polarization, and multi-user observation.
EDELWEISS MCP300: Polarization microscope for education and research with swing-out condenser, high-eyepoint eyepieces, Koehler illumination, and extensive optional features.
LILY MCX500: Professional research microscope with ELWD condenser, fluorescence illumination, and phase contrast options.
SUNDEW MCX1600: Inverted biological microscope designed for routine examinations with microtome lock integration and adjustable section thickness (0.5 μm to 60 μm).

Microtomes

RAZOR and STEELY: Manual microtomes for biological, medical, and industrial research with sturdy mechanical design and optional polarization, photo/video attachments, and digital cameras.

Metallurgical Microscopes

COPPER MCXM800: High-magnification metallurgical microscope with MET ICO PLAN objectives, ERGO head, iris diaphragm illumination, and options including polarization and photo/video attachments.
GOLD MCXI700: Inverted metallurgical microscope with binocular/trinocular heads, Greenwich optical system, and simultaneous incident and transmitted LED illumination.

Stereomicroscopes

BEE MICRO STEREO 1107: Suitable for hobby, education, and industry with binocular/trinocular heads, zoom magnification (6x–50x), and LED illumination.
HORNET MZ1280 Series (GECKO, SPIDER, VIPER): Infinitive zoom stereomicroscopes with large zoom ratios (up to 1:10), wide magnification ranges (4x–320x), coaxial focusing, LED illumination, and options such as ERGO heads, polarization, darkfield, mechanical and temperature-controlled stages.

Optical and Mechanical Features

Objectives range from achromatic to plan infinity-corrected optics with magnifications from 4x to 100x (including oil immersion) for biological and metallurgical applications.
Eyepieces include widefield, extra widefield, and high-eyepoint designs, some with crosshair reticles.
Illumination systems feature halogen (6V/20W to 12V/100W), LED options, Koehler illumination for optimal contrast, and fluorescence capabilities.
Mechanical components include sturdy cast aluminum or metal bases, Siedentopf or ERGO binocular/trinocular heads with adjustable inclination and rotation, multi-layer mechanical stages with innovative glass plates, and nosepieces ranging from quadruple to sextuple with ball bearing or reverse-angle mechanisms.

Additional Features and Options

LED illumination provides low heat emission, robustness, longer lifespan, and energy efficiency.
Digital integration (e.g., in CROCUS II) enables live image transmission, multi-user viewing, image capture, editing, and measurement.
Accessories include phase contrast, darkfield, polarization, fluorescence attachments, photo/video ports, multi-user observation sets, and protective aluminum cases.
Cordless operation with rechargeable batteries or solar charging modules is available for field use.
Anti-fungus treatment and voltage adaptability (110V/220V, 50/60Hz) are standard or optional across models.

Summary Table Highlights

The product range spans from basic routine microscopes to advanced research instruments, including inverted and metallurgical microscopes, stereomicroscopes, and microtomes. Key parameters such as objective types, eyepieces, illumination methods, mechanical design, and optional features are tailored to diverse applications and user requirements. Modern enhancements include LED illumination and digital integration to improve usability and functionality.

Microscope Series and Models

Metallurgical Microscope Series: Includes METICO PLAN Infinitive models (5x, 10x, 20x, 50x).
Stereo Microscope Series: Includes BEE 1107, HORNET MZ1280, GECKO MZ1000, SPIDER MZ2000, and VIPER MZ3000.
Additional Model: RAZOR STEELY microtomes.

Manufacturer Information

MICROS Austria, headquartered in Vienna, is the manufacturer. Contact details include telephone, fax, email, and website. The company is a member of the Royal Microscopical Society.

Notes

Specifications and equipment are subject to change without prior notice.
Document version dated June 2009.

Catalog excerpts

MICROS company has been founded in February 1994 and is mainly producing and supplying microscopes and microtomes for use in medical - technical laboratories, but also for applications in biological and industrial fields. New ergonomic design and new optics for different applications make our product range so successful. Our flexibility allows us to focus on an extraordinary customer service and to adjust to special inquiries and demands. It is an indisputable fact that quality is of prime importance for success, especially in view of Europe-wide competition and progressive globalization. The...

Open the catalog to page 3

OPTICS Objectives: ACHRO 4x/0.10, 10x/0.25, 40x/0.65 spring loaded and 100x/1.25 oil, spring loaded; Condenser: Abbé brightfield condenser n.A. 1.25, Eyepieces: WF 10x/18 widefield MECHANICS Body: Sturdy base, 270 x 250 mm; Head: Binocular Siedentopf head, 30° inclined, 360° rotatable; Nosepiece: Quadruple ball bearing nosepiece; Stage: Double layer mechanical stage; Illumination: 6V 20W, adjustable for 100 – 240V OPTIONS LED illumination, eyepieces securely lockable, aluminium case pink/poppy PINK MC50 Biological Microscope for Routine Laboratory Applications

Open the catalog to page 4

Same specifications as Pink MC50 but: ILLUMINATION LED lamp powered by Lithium battery or by DC9V power supply. Estimated battery durability is over 8 hours at continuous operation. Recharge time: 5 - 6 hours. The microscope can be used while battery is being recharged. Battery is intended for 400 charges for about 20.000 hours total. Compared to the classical halogen illumination the LED light has several advantages: Unlike halogen bulbs, the LED diodes do not emit heat and thus the housing and the specimen are not exposed to higher temperatures even after several working hours. Because of their...

Open the catalog to page 5

OPTICS Objectives: ICO Plan Infinitive 4x/0.10, 10x/0.25, 40x/0.65, spring loaded, 100x/1.25, Oil, spring loaded; Condenser: Abbé brightfield condenser n.A. 1.25; Eyepieces: WF 10x/18 MECHANICS Body: Sturdy base, 270 x 250 mm; Head: Binocular Siedentopf head, 30° inclined, 360° rotatable; Nosepiece: Quadruple ball bearing nosepiece, Stage: Double layer mechanical stage; Illumination: 6V 20W, adjustable for 100 – 240V OPTIONS LED illumination, different eyepieces, eyepieces securely lockable, darkfield filter (central stop), aluminium case petunia/d PETUNIA MCX50 Reliable Biological Allrounder...

Open the catalog to page 6

OPTICS Objectives: ICO Plan Infinitive 4x/0.10, 10x/0.25, 40x/0.65 spring loaded and 100x/1.25 oil, spring loaded; Condenser: Abbé brightfield condenser n.A. 1.25; Eyepieces: EW 10x/20 widefield MECHANICS Body: Sturdy base, 300 x 270 mm; Head: Arctype Binocular/Trinocular Siedentopf head, 30° inclined, 360° rotatable; Nosepiece: Quadruple, reverseangle mechanism; Stage: Double layer mechanical stage with innovative glass plate; Illumination: Koehler illumination, 6V 20W, adjustable for 100 – 240V OPTIONS LED illumination, different eyepieces, photo/video, phase contrast, darkfield attachment....

Open the catalog to page 7

A COMPLETELY NEW GENERATION OF MICROSCOPES! MICROS CROCUS II represents a big step forward - the computer system is integrated in the microscope and can transmit moving live images via W-LAN or LAN directly from the microscope into a local network. Take a step into a new age of microscopy and learn to use the advantages of digital applications. Perfect for researchers, educational use and many other applications. • The big screen avoids visual fatigue associated with traditional microscope use • Multiple users can share the image simultaneously • The inbuilt image processing software allows for...

Open the catalog to page 8

Optical specification of microscope same as DAFFODIL MCX100 LCD SCREEN • Real time live camera • 8.4 inch (21,3cm) TFT LCD screen (Touch Screen function) • Resolution 800 x 600 • 2 Megapixel CMOS camera, real time camera USB 2.0 • SD interface, AV /VGA connection • Image capture function • Real time operating system WIN CE 5.0 • W-LAN and LAN function • Video recording for MPEG-4 • MIC audio input, digital voice recording function • Support audio output • USB input for keyboard and mouse • Measuring function

Open the catalog to page 9

OPTICS Objectives: S PLAN 4x/0.10, 10x/0.25, 40x/0.65 spring loaded and 100x/1.25 oil, spring loaded; Condenser: Abbé brightfield condenser n.A. 1.25; Eyepieces: WF 10x/18 widefield MECHANICS Body: Sturdy high-tech cast aluminium base, 300 x 295 mm; Head: Binocular/Trinocular Siedentopf head, 30° inclined, 360° rotatable Nosepiece: Quintuple, reverse-angle mechanism; Stage: Double layer mechanical stage with innovative glass plate; llumination: Koehler Illumination, 6V 20W, adjustable for 100 – 240V OPTIONS LED illumination, different eyepieces, phase contrast, darkfield attachment, fluorescence,...

Open the catalog to page 10

OPTICS Objectives: ICO PLAN Infinitive 4x/0.10, 10x/0.25, 40x/0.65 spring loaded and 100x/1.25 oil, spring loaded; Condenser: Abbé brightfield condenser n.A. 1.25; Eyepieces: EWF 10x/20 extra widefield MECHANICS Body: Sturdy high-tech cast aluminium base, 300 x 295 mm; Head: Binocular/Trinocular Siedentopf head, 30° inclined, 360° rotatable Nosepiece: Quintuple, reverse-angle mechanism; Stage: Double layer mechanical stage with innovative glass plate; Illumination: Koehler illumination, 6V 30W, adjustable for 100 – 240V OPTIONS LED illumination, different eyepieces, phase contrast, darkfield...

Open the catalog to page 11

OPTICS Objectives: ACHRO 4x/0.10, 10x/0.25, 40x/0.65 spring loaded and 60x/0.80 spring loaded, Condenser: Abbé brightfield condenser n.A. 1.25, Eyepieces: WF 10x/18 widefield, one pc. with cross hair Polarizer, Analyzer, Bertrand lens, first order compensation red plate, 1/4 wavelength testplate, quartz wedge MECHANICS Body: Sturdy high-tech cast aluminium base, 300 x 295 mm; Head: Binocular/Trinocular Siedentopf head, 30° inclined, 360° rotatable Nosepiece: Quintuple, reverse-angle mechanism; Stage: Round stage, Ø 145 mm; Illumination: Optical light collector system, 6V 20W, adjustable for 100...
