More Precision wireSENSOR // Draw-wire displacement sensors

Draw-wire sensors wireSENSOR Measuring ranges up to 50,000 mm Resolution towards infinity Compact design with large measuring range Easy, fast and flexible mounting High operational safety & long service life Analog and digital outputs Measuring principle Draw-wire displacement sensors measure linear movements using a highly flexible steel wire. The cable drum is attached to a sensor Wire clip element which provides a displacement-proportional output signal. Measurements are performed with high accuracy and dynamics. High quality components ensure a long service life and high operational reliability....

Industrial draw-wire sensors Sensors for high wire accelerations Available outputs per series and measuring range Draw-wire sensors for serial integration & OEM 44 4 Sensors for high wire accelerations Measuring ranges in mm 40 ^Potentiometer ^Voltage JCurrent ^Incremental encoder (HTL, TTL) ^Absolute-encoder (SSI, PROFINET, PROFIBUS, CANopen, EtherCAT, EtherNet/IP) ^CANopen

Applications wireSENSOR Mobile machines: booms, supports & telescopic loaders Measurement of the extension length of telescopic booms Variable support for mobile cranes Measuring the lift height in telescopic loaders Lift tables: lifting platform, scissors lift tables Measuring the lift height in synchronous lifting systems Measuring the lift height in scissors lift tables Industrial vehicles & driverless transport systems Measuring the lift height in forklift trucks Measuring the lift height in driverless transport systems

Medical technology: operating tables & mammography Positioning of operating tables Position measurement in Computer Tomography (CT) Position measurement in mammography Test bench construction and road tests: chassis test benches & crash tests Spring travel measurement in road tests Measuring the pedal travel Displacement measurement in crash tests

Low-cost draw-wire sensors wireSENSOR MK30 analog Robust plastic housing Customer-specific designs Conductive plastic/wire/hybrid potentiometer Smallest design in its class Measuring range 50 mm approx. 8 Mounting clamps with M3 screws Measuring range 150/250/500/750 mm approx. 12 ø3 Mounting clamps with M3 screws

FSO = Full Scale Output 11 Specifications for analog outputs from page 58 onwards. Output type: Potentiometer P50 (linearity ±0.5 % FSO) Potentiometer P25 (linearity ±0.25 % FSO) Potentiometer P10 (linearity ±0.1 % FSO)

Low-cost draw-wire sensors wireSENSOR MK30 digital Robust plastic housing Customer-specific designs Incremental encoder Smallest design in its class Mounting clamps with M3 screws

FSO = Full Scale Output 11 Specifications for digital outputs from page 59 onwards. Output type:

Low-cost draw-wire sensors wireSENSOR MK46 analog Robust plastic housing Customer-specific designs Wire or hybrid potentiometer Mounting clamps with M3 screws Mounting clamps with M3 screws

FSO = Full Scale Output 11 Specifications for analog outputs from page 58 onwards. Output type: CR-P10/P25: potentiometer, integrated cable, radial, 1 m MK46 series Measuring range in mm Output type: CR-P10/P25: potentiometer, integrated cable, radial, 1 m CR-U10: Voltage, integrated cable, radial, 1 m CR-I10: Current, integrated cable, radial, 1 m

Low-cost draw-wire sensors wireSENSOR MK46 digital Robust plastic housing Customer-specific designs Incremental encoder Mounting clamps with M3 screws

FSO = Full Scale Output 11 Specifications for digital outputs from page 59 onwards. Output type:

Low-cost draw-wire sensors wireSENSOR MK77 analog Robust plastic housing Customer-specific designs Wire potentiometer Output P25 approx. 22.5 approx. 34.3 Mounting clamps with M3 screws Output CR-P25 approx. 22.5 approx. 34.3 Mounting clamps with M3 screws

FSO = Full Scale Output Specifications for analog outputs from page 58 onwards. Output type: CR-P25 potentiometer, integrated cable, radial, 1 m

Low-cost draw-wire sensors wireSENSOR MK77 digital Robust plastic housing Customer-specific designs Incremental encoder Mounting clamps with M3 screws

FSO = Full Scale Output 11 Specifications for digital outputs from page 59 onwards. Output type:

Low-cost draw-wire sensors wireSENSOR MK60 analog Robust plastic housing Customer-specific designs Potentiometer, current or voltage output

P: potentiometer U: voltage I: current Connection CR: integrated cable, radial, 1 m MK60 series Measuring range in mm

Low-cost draw-wire sensors wireSENSOR MK60 digital Robust plastic housing Customer-specific designs Incremental encoder

Connection CR: integrated cable, radial, 1 m MK60 series Measuring range in mm

Low-cost draw-wire sensors wireSENSOR MK88 analog Robust plastic housing Customer-specific designs Potentiometer, current or voltage output

P: potentiometer, U: voltage, I current Connection CR: integrated cable, radial, 1 m

Low-cost draw-wire sensors wireSENSOR MK88 digital Robust plastic housing Customer-specific designs CANopen Interface

Output type: CO: CANopen Connection SR12: 5-pin SA connector M12 MK88 series Measuring range in mm

Low-cost draw-wire sensors wireSENSOR MK120 analog Robust plastic housing Customer-specific designs Potentiometer, current or voltage output Measuring range 7500 mm approx. 20.5

P: potentiometer, U: voltage, I current Connection CR: integrated cable, radial, 1 m

Robust draw-wire sensors for OEM wireSENSOR K100 analog Durable and robust sensor design (IP67 / IP69K) Compact sensor with large measuring range Large temperature range from -40 to +85 °C Potentiometer, current or voltage output 3x ø 6.4 Mounting hole Mounting grooves for M

P: potentiometer, U: voltage, I current Connection CR: integrated cable, radial, 1 m

Robust draw-wire sensors for OEM wireSENSOR K100 digital Durable and robust sensor design (IP67 / IP69K) Compact sensor with large measuring range Large temperature range from -40 to +85 °C CANopen Interface 3x ø 6.8 Mounting hole 4x Mounting nuts M6 DIN 562
