U|Contact - SM99 and SR99 Compact Single Pole Terminal Blocks – Quick, Safe, Reliable!

Product catalog summary

Overview: The SM99 and SR99 are compact single pole terminal blocks designed for quick, safe, and reliable connections. They feature a height of 6.6 mm and accommodate wire cross sections up to 1.5 sqmm. These terminal blocks are suitable for various applications in industrial and building automation.

Specifications:

Design: Single pole spring clamp terminal block, available in SMT and THR designs.
Dimensions: 5.8 x 6.6 x 14.5 mm (w x h x d).
Connection Direction: 90°.
Reflow-capable and automation-compliant packaging (Tape & Reel).
Cable Range: 0.2 – 1.5 sqmm.
Nominal Current: 9 A.
Colour Coded Finger Actuators: Available in multiple colors including graphite black, cream white, signal yellow, and more.

Features:

Finger Push-Button: Facilitates quick and easy conductor insertion and release.
Visual Inspection Window: Allows users to verify correct conductor insertion.
Continuity Test Point: Enables electrical checks to confirm correct connections.

Applications: The SM99S and SR99S terminal blocks are ideal for use in PCB designs due to their flexibility in orientation and placement, making them suitable for industrial and building automation applications.

Contact Information: For sample orders and additional product information, visit www.metz-connect.com or contact METZ CONNECT GmbH at their Blumberg, Germany office.

Catalog excerpts

U|Contact - SM99 and SR99 Compact Single Pole Terminal Blocks – Quick, Safe, Reliable!-1

SM99S and SR99S Compact Single Pole Terminal Blocks – Quick, Safe, Reliable!

Open the catalog to page 1

U|Contact - SM99 and SR99 Compact Single Pole Terminal Blocks – Quick, Safe, Reliable!-2

SM99 and SR99 – Compact Single Pole Terminal Blocks SM99S|SR99S The SM99 and SR99 single pole terminal blocks are compact in design with a height of 6.6 mm and accept wire cross sections up to 1.5 sqmm. The finger push button facilitates quick and easy conductor insertion and release. An in-built inspection window allows users to check visually the conductor is inserted the connector correctly.The additional continuity test point allows the users to complied an electrical check ingle pole spring clamp terminal block, S SMT and THR designs onnection direction 90° C Reflow-capable utomation-compliant...

Open the catalog to page 2
