Reliable connection solutions for every movement

METZ CONNECT – Robotics Connectors and cables for moving applications in industry Robotics applications place the highest demands on connection technology. Cables and connectors are exposed to continuous bending, torsional and acceleration loads and must reliably transmit data, signals and power even during dynamic movement sequences. METZ CONNECT: Connections for moving worlds METZ CONNECT offers robust, practical connection solutions for industrial robotics applications – from guided cable routing in drag chains to highly flexible cables for torsion-loaded axes. The result: high process reliability,...

Connection technology for dynamic applications Whether it's articulated-arm robots, gantry axes, cobots, handling systems or automated production cells; wherever cables are permanently moved, reliable, mechanically resilient and application-specific connection technology is essential. • Industrial Ethernet in moving applications • Sensor/actuator cabling • Robust connectors for harsh industrial environments • Application-specific connection and connecting cables

METZ CONNECT – Robotics From the sensor to the robot arm – M12 connectors in industrial use PC board terminal blocks IP protected wall outlets In a modern production cell with collaborative robots, automated guided vehicles (AGVs) and networked automation components, the versatility of METZ CONNECT connection technology becomes clear: M12 connectors and cable assemblies secure data and signal transmission on robot axes and I/O components, while RJ45 connectors, Single Pair Ethernet, PCB terminal blocks and pin headers and female headers reliably ensure the networking of industrial switches, energy...

Data network technology for the industrial environment Pin headers and female headers Single Pair Ethernet - SPE

METZ CONNECT – Robotics Drag chain or torsion cable? The type of movement is decisive In modern robotic systems, cables are subjected to different loads depending on the axis and movement profile. While controlled cable routing is required for linear or guided movements, torsional loads are paramount for rotating axes. For this reason, drag chains and torsion cables are often used in combination. Drag chain Torsion cable Cable harness Torsion cable

METZ CONNECT - Robotics Drag chain - Guided safety in motion A drag chain, also known as an energy chain, is a This ensures that the cables are routed safely, promechanical guide system made of plastic or metal. tected from mechanical damage, and moved in ac-It accommodates cables, wires and hoses inside cordance with the permissible bending radius. This and guides them in a controlled manner along a reduces the risk of kinks, abrasion, and premature defined movement path. failure - even with a high number of cycles. Typical areas of application: • Linear axes and gantry robots • Pivot axes on...

METZ CONNECT – Robotics Selection guide at a glance Criterion Drag chain Torsion cable linear, guided, predictable rotary, twisting Typical application Axes with defined guidance Axes with torsional movement high torsional flexibility Guide system Installation space Main advantage

METZ CONNECT – Robotics Connection solutions for data transmission Robust, reliable and suitable for industry For reliable data transmission in robotics and automation applications, METZ CONNECT offers high-performance connection and connecting cables with industrial-grade connectors. Depending on the operating environment and interface requirements, solutions with M12 or RJ45 are available. While RJ45 is primarily used in protected environments, M12 offers significant advantages in demanding industrial applications thanks to its robust, lockable design. M12 female connector 4-pin D-coded M12...

METZ CONNECT – Robotics Technical properties of connectors for data transmission Technical properties Insulation resistance Contact resistance Metal, gold-plated Metal, gold-plated Contact carrier material Grip body material Metal, nickel-plated Ambient temperature Contact material Seal material (female connector) Degree of protection when mated Mechanical service life Pollution degree Your advantages in robotics • Reliable data transmission even under mechanical load • Robust connectors for industrial environments • Secure locking for vibration-loaded applications • Flexible choice of codings,...

M12 Industrial Ethernet connection/ connecting cables, D- and X-coded Shielded M12 Industrial Ethernet connection/connecting cables for secure, industrystandard data transmission in automation and fieldbus technology. Various cable types for increased mechanical loads such as abrasion, bending, vibrations, drag-chain operation and torsion, in various performance classes Cat.5 (100 MBit/s), Cat.6A (10 GBit/s) with D- and X-coded connectors. Typical interfaces M12 female connector M12 male connector Angled M12 male connector RJ45 plug Free cable end Create cable in the configurator:

METZ CONNECT - Robotics In addition to data transmission, the reliable transmission of sensor and actuator signals also plays a key role in robotics applications. M12 sensor/actuator connection and connecting cables are available in various versions for this purpose. METZ CONNECT solutions are designed for industrial requirements and enable a secure connection even under dynamic conditions. • M12 sensor/actuator connection and connecting cables, A-coded • Shielded and unshielded variants • Different numbers of poles and cable lengths • Straight and angled connectors • Variants with free cable...

Technical properties of connectors for signal transmission Technical properties Insulation resistance Contact resistance Ambient temperature Contact material Metal, gold-plated Contact carrier material Grip body material Seal material (female connector) Degree of protection when mated Mechanical service life Pollution degree Metal, nickel-plated
