RJ45 field plug pro – field assembled, fully shielded and multiport-capable

METZ CONNECT – C6A RJ45 field plug pro The RJ45 field plug pro 180° straight and 360° angled The METZ CONNECT field assembled RJ45 field plug pro is the right choice for structured cabling with industry or data centers with high data transmission rates up to 40 GBit/s where high-performance and reliable connections are needed. The RJ45 field plug pro is available in a 180° straight and 360° angled, 4-pair and 2-pair version. It can easily be connected to all common cable types without much preparation and its new design allows it to be used in restricted spaces. It impresses with its robust zinc...

strain relief through integrated clip 360° fully shielded easy to assemble with insulation displacement connectors (IDC) same stuffer cap for all field plug pro 180° robust and reconnectable zinc die-cast housing IP20 protected Only two parts cable assignment guidance intelligent cable & direct on the stuffer cap wire management > C5 field plug pro: Cat.5 PROFINET 10/100 Mbit/s easy assembling without the need for special tools > C6a field plug pro: Cat.6A Class Ea 10 GBit/s > 25G field plug pro: Class I to 1250 MHz 25 GBit/s > 40G field plug pro: Class I to 2000 MHz 40 GBit/s > field-assembled...

Multiport capability – Network distribution The 360° version with multiple cable outlet makes for flexible use of the connector. The two rear position adapters 4 PA (4 x 90°) and 8 PA (8 x 45°) thus allow a total of 32 cable positions. This also allows jacks that are difficult to access to Multiport capability – Network distribution Direct connection – IP camera Direct connection – Industrial distributors Direct connection – Building automation be reached reliably without problems and without high bending radii. Despite the many different positions it meets the transmission properties.

METZ CONNECT – C6A RJ45 field plug pro Product overview 40G Patch Cord Part number Cable length Part Number RJ45 Cat.8.1 AWG26 S/FTP LSHF yellow 25 GBit 25G RJ45 field plug pro 10 GBit C6A RJ45 field plug pro 360 Part number
