Compact controller and data logger – Simple control and energy monitoring in buildings, machines, and systems

METZ CONNECT - Compact controller and data logger METZ CONNECT - Compact controller and data logger Compact controller & data loggerSimple control and energy monitoring in \ D> M D, „ buildings, machines, and systems > Simple quick wiring with jumper plug for connection of extension/ function modules > M-BUS interface with integrated level converter for 80 M-Bus loads > Reading out M-Bus meters (parameterizable readout interval) > Buttons and LEDs for manual operation and display > 1 x Modbus RTU interface for 32 participants The EWIO2 device families are high-performance data loggers and mini...

METZ CONNECT – Compact controller and data logger METZ CONNECT – Compact controller and data logger User/ operator Ethernet Network FTPS Visualization via Node-RED User/ operator Web interface Meter 1 Meter 2 Modbus TCP, BACnet/IP M-BUS TCP/IP (Daisy Chain) Modbus RTU S0 pulse inputs SO/M-F converter Product overview Hardware management – easy installation and commissioning Logic module Data logger Ethernet-I/O controller

METZ CONNECT - Compact controller and data logger Node-RED Editor Web-based graphical programming interface Node-RED about blog documentation foium nows gitbub Low-code programming for event-driven applications Node-RED Essentials The easiest way to collect transform and visualize real-time data. Flow example Data stream oriented programming via drag & drop Node-REDs goal is to enable anyone to bold appiicatons that coilea, transform and visualize their data; building flows that can automate tneir world its low-code natore makes it accessible to users of any background, whether for home automation,...

METZ CONNECT – Compact controller and data logger METZ CONNECT – Compact controller and data logger System and expansion components M-Bus modules and accessories S0/M-Bus converter with 4 channels for recording pulses generated by energy meters via a standardized interface according to DIN EN 62053-31 class A Temperature/M-Bus converter with 4 individually adjustable channels. Selectable characteristic curves for sensors: PT100, PT500, PT1000, Ni100, Ni1000, NTC1k8, NTC10k, NTC 20k, KTY10 6 x M-Bus, 2 x voltage M-Bus distributor in IP65 surface mount housing for structured M-Bus cabling. With...

METZ CONNECT - Compact controller and data logger METZ CONNECT - Compact controller and data logger 8 configurable temperature or voltage inputs Modbus RTU Energy Meter, via current transformer (secondary 1 A / 5 A) Modbus RTU Energy meter, via current transformer (secondary 50 mV / 333 mV) 2 two-phase relay outputs, manual control level For monitoring levels and leakages, as well as switching of solenoid valves 4 current inputs 0-20 mA, 4 relay outputs, 4 voltage inputs 0-10 V manual control level 4 triac outputs, manual control level 4 digital outputs (photo MOS) 4 digital outputs (relay) 6...
