Series 9000 6000 Flanged Ball Valves

Product catalog summary

Overview: The document details the specifications and features of JAMESBURY® polymeric-seated flanged ball valves, suitable for industries such as chemical, petrochemical, refining, pulp and paper, and power. These valves range from 1/2” to 24” and meet ASME B16.34 standards.

Specifications: Available in ANSI Class 150 and 300, the valves feature full-bore and standard-bore designs with a patented flexible-lip seat for bi-directional shut-off. Customization options include various body, trim, and seat materials for specific applications, including chlorine and oxygen services.

FIRE-TITE® and Non FIRE-TITE Valves: FIRE-TITE valves use carbon steel with 316 stainless steel trim and offer seat materials like PTFE and XTREME® for chemical and steam applications. Non FIRE-TITE valves feature UHMW polyethylene and Peek® seats.

Compliance and Features: The valves comply with API 607 and API 608 standards and are CE marked for the European Pressure Equipment Directive. They include a new stem seal system for enhanced sealing life and ISO 5211 Bonnet for global conformity.

Technical Data: Detailed tables provide maximum working pressures, flow coefficients, and valve dimensions, along with valve seat ratings and material specifications for various temperature and pressure conditions.

Materials and Construction: Constructed from materials like carbon steel and 316 stainless steel, the valves use seat materials such as PTFE, XTREME, and PFA. The document lists parts and materials for both FIRE-TITE and Non FIRE-TITE valves.

Additional Features: Valves can be paired with JAMESBURY actuators and digital monitors for improved automation and performance. XTREME seats offer longer life and superior performance.

Specifications and Features: Series 9000 ball valves include optional round and oval handles, with oval handles padlockable for security. Stem extension kits improve accessibility, and PTFE cavity fillers in full bore valves prevent cross-contamination in sanitary applications.

Accessories: Locking devices allow valves to be padlocked for safety, with part numbers provided for ordering.

Valve Torque Data: Torque charts guide actuator selection, with adjustments for media characteristics and operation frequency. Specific torque requirements are outlined for different seat materials, advising larger actuators for difficult services.

Ordering Information: A detailed guide specifies necessary codes for ordering valves, including size, series, style, construction, materials, and seat/stem seal materials.

Standards and Specifications: Valves comply with international standards like ISO 9001, API 598, and ANSI/ASME, with optional standards including BS 5351 and NACE MR0103.

Contact Information: Contact details for Metso Automation Inc. are provided for regions including Europe, North America, South America, Asia Pacific, China, and the Middle East.
