EASYCLAMP

Product catalog summary

Applications

Injection Molding
Press Forming
Diecasting

One Touch Quick Change Mold Clamp

The EASYCLAMP system allows for quick and reliable mold replacement by rotating a block or body, accommodating four different mold base heights with a single type of clamp.

Specifications

Quick detachment and attachment of the body due to its unique shape and clamping washer design.
Flexible clamp positioning enabled by the easily shifted block structure.
Safe and harmless to die plates and bolt holes due to the larger footprint of the block and vertical bolt fixation.
Missing-free structure with linked body and block using links and springs.

Model Sizes and Dimensions

Model	Size (mm)	Block Height	Thickness of Washer	Bolt Size	Weight of 1 set (kg)	Weight of 8pcs. of Bolts (kg)
SS	80	10 x 15	2	M10x70	3.4	0.5
S	80	20 x 25	2.5	M12x80	4	0.7
M	100	20 x 25	3	M16x90	7.6	1.4
MA	120	20 x 25	3	M16x90	8.6	1.4
MB	150	20 x 25	3	M16x90	10	1.4
L	150	30 x 35	3	M20x120	18	2.8
Special	150	30 x 35	4	M24x120	19.6	4.1

Contact Information

Head Office (Osaka, Japan): Tel: +81-72-941-8652, Email: [email protected]

Tokyo Branch: Tel: +81-3-5825-1535, Email: [email protected]

Matex Planetary Drive International, Inc.: Email: [email protected]

Wuxi Matex Precision Co., Ltd.: Email: [email protected]

Catalog excerpts

Mold Clamp １type can fit 4 mold base heights Quick, Easy, yet Reliable mold replacement ◼ One Touch Quick Change body block Injection Molding Press Forming By rotating a block or a body, one type of EASYCLAMP can clamp 4 different heights of mold base

Open the catalog to page 1

⑤washer ④clamping washer ①body ③link ②block 〈Easy, Quick, and Flexible〉 Trouble-free Mold Replacement ●Quick detachment of ①body, by loosening the bolt a bit, thanks to its unique shape. ●Easy attachment of ①body, because ④clamping washer always keeps its direction vertical. ●Flexible clamp position. Thanks to its unique structure, ②block can be shifted easily. ●Harmless to a Dieplate and a bolt hole, thanks to larger foot print of ②block than other clamp. ●Missing free structure. ①body and ②block are linked with ③links and springs. ●Safe to a bolt hole. Different from other types of clamp, The...
