versaflex Flat Top Chain Conveyor System
16Pages

{{requestButtons}}

Catalog excerpts

versaflex Flat Top Chain Conveyor System - 1

Flat Top Chain Conveyor System TECHNOLOGY GROUP

Open the catalog to page 1
versaflex Flat Top Chain Conveyor System - 2

Versaflex – versatile and flexible  Flexible solution »construction kit. from the « The versatile and flexible flat top chain conveyor system Versaflex, formerly the plastic chain conveyor of E-M-M-A GmbH, features a modular design. The standardized modules and components make it simple and cost effective to integrate the system into any production process, as well as to adapt and expand it. Versaflex is a conveyor system that grows with your requirements. More over, it is compatible with systems that are currently available on the market. The single-track design and curve radii starting at...

Open the catalog to page 2
versaflex Flat Top Chain Conveyor System - 3

Economical realisation of complex track designs Simple and fast configuration and commissioning Suitable for all industries and compatible with existing systems Modular system of standardized components Turnkey or as assembly kit User friendly and low maintenance Can be quickly adapted to new production and environmental conditions Saves energy and space Accessories, side rails etc. can be attached in the slots on the conveyor frame profile

Open the catalog to page 3
versaflex Flat Top Chain Conveyor System - 4

System Conveyor * also available as variant A045 with a system height of 52 mm for compact applications ** higher conveying speeds on request

Open the catalog to page 4
versaflex Flat Top Chain Conveyor System - 5

The conveyor chain The conveyor chains are made from the material POM and are available in a wide variety of designs for virtually all applications – with an adhesive surface for inclines, with steel covering for sharp-edged parts or flocked for transporting very delicate items. In addition, a large number of different cleats are available – rollers in a wide range of dimensions for accumulating products, or flexible cleats for implementing clamping conveyors. Furthermore, chain links with embedded magnets can be used to transport magnetizable parts. Cleated chain Cleated roller chain...

Open the catalog to page 5
versaflex Flat Top Chain Conveyor System - 6

Versaflex – modular and standardised The Benefits Economical realisation of complex track designs Simple and fast configuration and commissioning Upper rail guide Suitable for all industries and compatible with existing systems Wheel bend Roller bridge Plain bend horizontal Single stand

Open the catalog to page 6
versaflex Flat Top Chain Conveyor System - 7

Head drive Stand with levelling feet Plain bend vertical Side rail Areas of application Primary and secondary-packaged products from, among others, the food, pharmaceutical, chemical or consumer goods industry. Also for the transport of workpiece carriers in assembly lines e.g. of the automotive industry and for the linking of machines in the manufacturing industry.

Open the catalog to page 7
versaflex Flat Top Chain Conveyor System - 8

Versaflex – turnkey or as assembly kit Complete system. Spare your own resources. Horizontal conveyor Clamping conveyor Alpine conveyors Workpiece carrier circulation Conveyor with gradient Vertical conveyor with guide rollers

Open the catalog to page 8
versaflex Flat Top Chain Conveyor System - 9

Module. Simply build yourself. Chains and cleats Profiles and wear strips Side rails

Open the catalog to page 9
versaflex Flat Top Chain Conveyor System - 10

Versaflex – also as a workpiece carrier system » Safe solution for automated processes. To ensure the precise positioning of products, workpiece carriers can also be transported on the A08 system. As described above, the system is 85 mm wide (chain width 83 mm) and is designed for products weighing up to 10 kg per carrier. The carriers have a standard width of 150 mm and are guided by side rails and positioned exactly in three levels in the locating stations. So the products are fixed, buffered and transported gently, safely and accurately. The workpiece carrier can be customised and...

Open the catalog to page 10
versaflex Flat Top Chain Conveyor System - 11

Benefits of Versaflex workpiece carrier system S imple and accurate positioning for automated processes S tability even for products with unfavorable geometry G entle product transport also for sensitive product surfaces S afe transport even with changes in position H igher machine autonomy B uffer function for cycle decoupling in manu facturing process

Open the catalog to page 11
versaflex Flat Top Chain Conveyor System - 12

Versaflex – used very successfully in all areas 4-track Versaflex flat top chain conveyor A06 with cleats Versaflex flat top chain conveyor with guide rollers for vertical transport Versaflex flat top chain conveyor with wheel bend and side rail

Open the catalog to page 12
versaflex Flat Top Chain Conveyor System - 13

Versaflex flat top chain conveyor as clamping conveyor Automatically adjustable side rails ASTRRA Versaflex flat top chain conveyor as a parallel multi-line system Versaflex flat top chain conveyor with customised separation

Open the catalog to page 13
versaflex Flat Top Chain Conveyor System - 14

Our service – your benefit » Dependable consulting and technical support throughout the entire life cycle. « Productivity is the key to your company’s success in a globally competitive market. Your machines and systems must run continuously and dependably throughout the entire life cycle if you want to be able to fulfil your customer's requirements quickly, efficiently and ensure the utmost quality at all times. We offer comprehensive services to assist you at every stage of your project. Based on your specific application, the mk field team provides on-site consulting and helps with...

Open the catalog to page 14
versaflex Flat Top Chain Conveyor System - 15

Maschinenbau Kitz, the parent company of the mk Technology Group, is one of the leading suppliers of components, modules and systems for factory automation. With our dense production sales and service network consisting of subsidiaries, sales partners and external service providers, we guarantee our customers fast access to our expert advice and outstanding products. Our more than 450 highly qualified and dedicated employees work to fulfil customer orders with precision and dependability in over 28,000 m2 of production area space. HeadquartersSubsidiaries Maschinenbau Kitz GmbH...

Open the catalog to page 15
versaflex Flat Top Chain Conveyor System - 16

Maschinenbau Kitz GmbH Headquarters of the mk Technology Group AmperestraRe 18 53844 Troisdorf Germany Tel +49 228 4598-0 info@mk-group.com www.mk-group.com

Open the catalog to page 16
