1-4 Quick Selector Marsh Gauge Selection Made easy! 5-8 Filters Regulators Lubricators Miniature (M1) & Standard (M2) FRL’s, Filters, Regulators, Filter-Regulators, Lubricators (5) 9-13 General Service Gauges Marshalltown Value Series (9) General Service (10-13) 14-19 Severe Service Gauges 40mm & 50mm (14), 63mm Severe Service (15-16), 100mm Severe Service (17-18), 63mm & 100mm Brass Gauges (19) 20-30 Precision Service Gauges 100mm Stainless Steel (19), Quality Series 100mm Stainless Steel Internal (21), Quality Series 100mm Copper Alloy Internal (22), ‘HW’ 160mm Stainless Steel (23), 100mm Elite...

1 Quick Selector G A U G E S E R I E S : MARSHALLTOWN VALUE SERIES G A U G E S E R I E S : GENERAL SERVICE G A U G E S E R I E S : 40/50MM LIQUID FILLED G A U G E S E R I E S : SEVERE SERVICE 63MM & 100MM G A U G E S E R I E S : 63MM & 100MM BRASS GAUGE A C C U R A C Y A S M E : Grade B = ±3/2/3 (±2% of range across middle half of scale) A C C U R A C Y A S M E : Grade B = ±3/2/3 (±2% of range across middle half of scale) A C C U R A C Y A S M E : ±2.5% of range across full scale A C C U R A C Y A S M E : 63mm: Grade B =±3/2/3 (±2% of range across middle half of scale) 100mm: Grade A ±2/1/2 (±1%...

2 Quick Selector G A U G E S E R I E S : 100MM STAINLESS STEEL G A U G E S E R I E S : 100MM STAINLESS STEEL NACE G A U G E S E R I E S : ‘HW’ 160MM STAINLESS STEEL G A U G E S E R I E S : 100MM ELITE G A U G E S E R I E S : QUALITY GAUGE A C C U R A C Y A S M E : Grade 1A = ±1% full scale A C C U R A C Y A S M E : Grade 1A = ±1% full scale A C C U R A C Y A S M E : Grade 1A = ±1% full scale A C C U R A C Y A S M E : Grade 1A = ±1% full scale A C C U R A C Y A S M E : Grade A = ±2/1/2 (±1% of range across middle half of scale) C A S E S I Z E : 100mm diameter C A S E S I Z E : 100mm diameter...

3 Quick Selector G A U G E S E R I E S : TEST GAUGE G A U G E S E R I E S : MASTER TEST GAUGE G A U G E S E R I E S : INSPECTOR’S TEST GAUGE G A U G E S E R I E S : PROCESS GAUGE G A U G E S E R I E S : DIAPHRAGM GAUGE A C C U R A C Y A S M E : Grade 2A = ±0.50% full scale A C C U R A C Y A S M E : Grade 3A = ±0.25% full scale A C C U R A C Y A S M E : Grade 2A = ±0.50% full scale A C C U R A C Y A S M E : Grade 2A = ±0.50% full scale A C C U R A C Y A S M E : Grade A = ±2/1/2 (±1% of range across middle half of scale) and Grade B = ±3/1/3 (±2% of range for ranges below 30" H2O) C A S E S I Z...

4 Quick Selector G A U G E S E R I E S : GAS PRESSURE TEST SET G A U G E S E R I E S : GAS TEST GAUGES G A U G E S E R I E S : PAPER MACHINE GAUGE G A U G E S E R I E S : BIMETAL THERMOMETERS A C C U R A C Y A S M E : Grade A=±2/1/2 (± 1% of range across middle half of scale) and Grade B=±3/1/3% for ranges (below 30" H2O) A C C U R A C Y A S M E : Grade B ±3/2/3% (±2% of range across middle half of scale) A C C U R A C Y A S M E : Grade A = ±2/1/2 (±1% of range across middle half of scale) A C C U R A C Y A S M E : ±1% of span C A S E S I Z E : 212" C A S E S I Z E : 2" Diameter C A S E S I Z...

5 FRL’s TYPE M1–MINI TYPE M2–STANDARD FILTERS Port Size 18, 14 NPT 14, 38, 12 NPT Filtration (micron) 5ì, 25ì, 50ì 5ì, 25ì, 50ì Maximum Supply Pressure 1.0 MPa 10 BAR 145 psi 1.0 MPa 10 BAR 145 psi Temperature Range 41º–140º F / 5º–60º C 41º–140º F / 5º–60º C Drain Manual / Semi-Auto Manual / Semi-Auto / Auto Bowl Capacity 0.75 inch3 2.75 inch3 Flow (based on 100 psi inlet pressure with 50 micron filter) 55, 85 SCFM 120, 120, 120 SCFM REGULATORS Effect of Supply Pressure variation (25 psig) on Outlet Pressure < 0.2 psig (13.8 mBAR) < 0.2 psig (13.8 mBAR) Exhaust Capacity (5 psig above 20 psig...

6 FRL’s FRL FEATURES Modular design for service & interchangeability Miniature (M1), Standard (M2) Small package size and light weight construction Competitively priced FILTERS M1 has polycarbonate bowl, M2 have polycarbonate bowl with metal guard STOCK ELEMENTS - 5, 25 or 50 micron Manual, semi-auto or auto drain available REGULATORS Bellofram® Rolling Diaphragm for superior regulator performance Panel, pipe, or bracket (included) mounting Metal body, polycarbonate bonnet and knob Non-rising adjustment knob with push-pull lock ring feature FILTER REGULATORS Aluminum and polycarbonate construction...

8 FRL’s REPLACEMENT PARTS Description Model # Miniature Size Connector Kit M1K Miniature Size Connector Kit FR+L M1K2 Standard Size Connector Kit M2K Standard Size Connector Kit FR+L M2K2 Miniature Size Filter or Lubricator Bracket M1FB Standard Size Filter or Lubricator Bracket M2FB Miniature Size Regulator or Filter Regulator Bracket M1RB Standard Size Regulator or Filter Regulator Bracket M2RB Description Model # Miniature 5 micron Filter Element M1FK05 Miniature 25 micron Filter Element M1FK25 Miniature 50 micron Filter Element M1FK50 Standard 5 micron Filter Element M2FK05 Standard 25 micron...

9 General Service MARSHALLTOWN VALUE SERIES GAUGE • ASME Grade B Accuracy • Extra Savings with Quantity Pricing • 4 Standard Mounting Options: LM, CB, Right & Left Marshalltown Value Series are the most economical, general purpose gauges in the Marsh gauge line. Suited for use with water, oil, air, gas, or other non-corrosive media. Typical applications include FRL’s, compressors, pumps, boilers, regulators, dryers as well as commercial and industrial equipment. SPECIFICATIONS ACCURACY ASME Grade B = ±3/2/3% (±2% of range across middle half of scale) CASE SIZES 112" and 2" diameter CASE MATERIAL...

10 General Service TYPE GENERAL SERVICE GAUGES Size 112" 2" Case Material Steel Steel Internals Copper Alloy Copper Alloy Mounting / Case Style LM UC CB LM LM CB CB Connection 18 NPT 18 NPT 18 NPT 18 NPT 14 NPT 18 NPT 14 NPT Scale Standard psi/kPa psi/kPa 0 to 30" Hg VAC J0405 J0505 J0605 J1105 J1405 J1805 J2005 30" Hg VAC to 15 psi 30" Hg VAC to 30 psi J1412 30" Hg VAC to 60 psi J1414 30" Hg VAC to 100 psi 30" Hg VAC to 150 psi J0418 J0518 J0618 J1118 J1418 J1818 J2018 30" Hg VAC to 200 psi J0420 J0520 J0620 J1120 J1420 J1820 J2020 30" Hg VAC to 300 psi J0424 J0524 J0624 J1124 J1424 J1824 J2024...
