Marsh Bellofram BelGAS Division New Products Brochure

1 / 5 PagesView full catalog

Marsh Bellofram BelGAS Division New Products Brochure

Product catalog summary

Control Valve (Type P119)

Features: Offers on-off or throttling control, low seat leakage, tight shut-off, suitable for gas or liquid service, easy installation, inline maintenance, leak detection, and NACE capability.
Specifications: Spring ranges from 3-15 psi to 30-60 psi. Compatible with corrosive and non-corrosive gases or liquids. Maintenance can be performed inline. NACE construction materials are standard for steel body valves, complying with MR-01-75.
Body and Material: Available in iron and steel with various orifice sizes and seat materials like nitrile or fluorocarbon.

High Flow Gas Regulator (R627 & P630 LP)

Features: Internal relief, low carbon steel construction, suitable for low temperature services. P630 LP offers set points down to 3 PSIG and complies with NACE standards.
Applications: Used in gas gathering, district stations, city gates, farm taps, and storage.

Backpressure Regulator (Type P289)

Features: Functions as a high flow relief valve with adjustable set points, compact design, reliable due to simplicity, and tight shutoff.
Applications: Suitable for fuel gas relief and gas gathering relief.
Specifications: Port size of 2" NPT, maximum relief inlet pressure of 25 PSIG, various relief set pressure ranges, and temperature range from -20 to 300ºF depending on elastomer type.
Materials: Constructed with cast iron body, aluminum bonnet, and components made from nitrile, fluoroelastomer, stainless steel, brass, and zinc-plated steel.

Catalog excerpts

Marsh Bellofram BelGAS Division New Products Brochure-2

A D I V I S I O N O F M A R S H B E L L O F R A M P119 Control Valve Features • On-Off or Throttling Control • Low Seat Leakage • Tight Shut-off • Gas or Liquid Service • Easy Installation • Inline Maintenance • Leak Detection • NACE Capability The Type P119 Control Valve is versatile and can be used for on-off or throttling service. Spring ranges from 3-15 psi to 30-60. The valve can be used in corrosive or noncorrosive gases or liquids, limited by available compatible materials. Maintenance on the valve can be accomplished without removing the valve body from the line (pressure must be removed...

Open the catalog to page 2

Marsh Bellofram BelGAS Division New Products Brochure-3

A D I V I S I O N O F M A R S H B E L L O F R A M R627 P627 LCC High Flow Gas Regulator Features • Internal Relief • Low Carbon Steel • Low Temperature Services belgas.net Specifications R627 Applications • Gas Gathering • Form Top • District Stations • City Gates

Open the catalog to page 3

Marsh Bellofram BelGAS Division New Products Brochure-4

A D I V I S I O N O F M A R S H B E L L O F R A M P630 LP High Flow Gas Regulator Features • Set points down to 3 PSIG • Steel units comply with NACE • Powder Coat Exterior Applications • Farm Tap • Gas Gathering • Storage belgas.net

Open the catalog to page 4

Marsh Bellofram BelGAS Division New Products Brochure-5

A D I V I S I O N O F M A R S H B E L L O F R A M P289 2" Backpressure Regulator Features • Throttling Type Relief • High Flow Rates • Compact • Reliability Due to Simplicity • Tight Shutoff The Type P289 Backpressure Regulator functions as a high flow relief valve with an adjustable set point. The P289 can be used in place of a standard relief valve to provide protection against over pressurization in the downstream system. The design of a large diaphragm area and a pitot tube booster allow the valve to respond quickly and relieve the excessive pressure smoothly, especially in low-pressure settings....

Open the catalog to page 5
