Marsh Bellofram - BelGAS Catalogue

Marsh Bellofram - BelGAS Catalogue
52Pages

Catalog excerpts

TABLE OF CONTENTS BELGAS INTRODUCTION >

P627 HIGH FLOW GAS REGULATOR Wide Range of Flow CapacitiesՕDurable Powder Coated ExteriorInstallation VersatilityՕNACE Construction AvailableThe P627 is a spring loaded, direct-operated regulator for both low and high pressureapplications in the oil and gas industries. These regulators provide durability, from the powder-coated epoxy exterior finish, as well as installation versatility, from the multi- position body and spring case configurations. These regulators are also available in an external pressure registration model (P627M), and NACE construction. > Farm Tap RegulationՕMonitoring...

Open the catalog to page 3

Kit Includes Part Number Kit Includes Part Number P627Low Pressure Nitrile diaphragms (2), Nitrile valve disk, Orings, back-up rings, and retaining pin. 971-627-000 P627 LowPressure NACE Nitrile diaphragms (2), SS Nitrile valve disk, OҒrings, back-up rings, and retaining pin. 971-627-N00 P627Low Pressure Nitrile diaphragms (2), Nylon valve disk, Orings, back-up rings, and retaining pin. 971-627-001 P627 LowPressure NACE Nitrile diaphragms (2), SS Nylon valve disk, OҒrings, back-up rings, and retaining pin. 971-627-N01 P627High Pressure Neoprene diaphragm, Nitrile valve disk, Orings, back-up...

Open the catalog to page 4

P627 HIGH FLOW GAS REGULATOR ITEM DESCRIPTION PART NUMBER 1 Cover Adj. Screw, plastic 610-053-000 2 Adjustment Screw 648-465-000 3 Locknut 634-154-000 4 Bonnet, P627 - aluminumBonnet, P627M, P627H & P627HM - Steel 604-210-000604-211-000 > 5 Vent Screw Assembly 836-005-000 6 Spring Guide, Upper 626-079-000 Range Spring 5-20 PSIGYellow 655-661-000 15-40 PSIG֖Green 655-661-001 7 35-80 PSIG & 10-95PSIG Blue 655-661-002 70-150 PSIG֖Red 655-661-003 140-250 PSIGBlue240-500 PSIG֖Red 655-661-002 655-661-003 8 Spring Guide, Lower (P627 or P627M only) 643-191-000 Build Screw, Spring Case (8 required)...

Open the catalog to page 5

1. Capacity is based on 20 percent droop unless otherwise noted below. 2. For pressure setting under 10 PSIG (0.69 BAR) limit the input pressure to 100 PSIG (6.9 BAR) to obtain the setpoint.3. For 5 PSIG (0.34 BAR) pressure set point, the droop is 2 PSIG (0.14 BAR) >

Open the catalog to page 6

P630 HIGH FLOW GAS REGULATOR Stainless Steel Internals are StandardՕSteel Units comply with NACE MR0175Durable Powder Coated ExteriorՕWide Range of Flow CapacitiesThe P630 is a spring loaded, direct-operated regulator for high pressure, and high flowapplications. The heavy duty construction, made possible by the addition of stainless steel internal components and a powder-coated epoxy exterior finish, makes it ideally suited for the oil and gas industries. All P630 steel units meet NACE MR0175 material requirements for corrosive (sour gas) environments. > First cut or second stage...

Open the catalog to page 11

P630 HIGH FLOW GAS REGULATOR

Open the catalog to page 12

P630 HIGH FLOW GAS REGULATOR PORT SIZE > "B" "F""C" "D" "A" "E" OUT IN 1"08 2"16 SPRING RANGE PSIGBAR 30-702.1-4.8070 50-953.4-6.6095 75-1755.2-12.1175 150-25010.3-17.2250 DIAPHRAGM Fluorocarbon2 Neoprene3 CASING MATERIAL Ductile Iron0 Steel (standard NACE)1 > 971-630-000 Neoprene diaphragm, Nylon valve disk, one body gasket, and 2 orifice gaskets. 971-630-100 Neoprene diaphragm, TFE valve disk, one body gasket, and 2 orifice gaskets. > 971-630-200 Fluorocarbon diaphragm, Nylon valve disk, one body gasket, and 2 orifice gaskets. 971-630-300 Fluorocarbon diaphragm, TFE valve disk, one body...

Open the catalog to page 14

P630 HIGH FLOW GAS REGULATOR 1 Nameplate (requires 4 drive screws for mounting) 632-472-000 2 Drive Screw (4 required) 648-464-000 Adjusting ScrewSpring Range 27-50 PSIG 648-462-002 46-95 PSIG 648-462-001 3 90-150 PSIG 648-462-000 150-200 PSIG 648-462-000 200-275 PSIG275-500 PSIG 648-462-000 648-462-000 4 Hex Nut 634-000-056 5 Upper spring guide - Pressure range to 275 PSIG Upper spring guide - Over 275 PSIG 626-077-000626-078-000 6 Bonnet - IronBonnet - Steel 604-204-000604-205-000 Range SpringSpring Range 27-50 PSIGRed Stripe 655-659-000 46-95 PSIG֖Olive Drab 655-659-001 7 90-150...

Open the catalog to page 15

Dimensions Table A B C D P39 w/T-Handle0-30, 0-60, 0-120, 0-150, 0-225 PSIG range > mminches 1566.14 582.3 853.33 642.50 SPRING RANGE 0-30 PSIG0-2.1 BAR030 > P39 GAS REGULATOR P39 w/Allen Head0-30, 0-60, 0-120, 0-150, 0-225 PSIG range 0-60 PSIG0-4.1 BAR060 mminches 1505.90 582.30 853.33 190.75 0-120 PSIG0-8.3 BAR120 0-150 PSIG0-10.3 BAR150 0-225 PSIG0-15.5 BAR225 0-500 PSIG *0-34.5 BAR500* Not available in Stainless Steel P39 w/T-Handle0-500 PSIG range mminches 1776.98 752.96 853.33 1526.0 VERSIONS Standard0 P39 w/Allen Head0-500 PSIG range mminches 1726.78 752.96 853.33 321.25 PED (for...

Open the catalog to page 17

P50 & P50 NACE FILTER REGULATORS P50 FILTER REGULATOR P50 NACE FILTER REGULATOR Sensitivity 1" ( 25.4 mm) Water Column 1" ( 25.4 mm) Water Column Flow Capacity 20 SCFM ( 565 LPM) 18 SCFM (510 LPM) Effect of Supply Pressure variation (25 PSIG) on Outlet Pressure < 0.2 PSIG (0.01 BAR) < 0.2 PSIG (0.01 BAR) Exhaust Capacity (5 PSIG above 20 PSIG set point) 0.10.45 SCFM Typical (2.8֖12.7 LPM) 0.10.45 SCFM Typical (2.8֖12.7LPM) Maximum Input/Supply Pressure 250 PSIG (17.2 BAR) 250 PSIG (17.2 BAR) Effect of Changes in Flow on Regulated Pressure (100 PSIG/6.9 BAR Supply) 4 PSIG ( 0.3 BAR) over...

Open the catalog to page 19

P51SSR Regulator P51SSFR Filter Regulator P51SSAR Auto Filter Regulator P51SSF P51SSAF built in 40 micron filter with manual drain built in 40 micron filter with automatic drain 40 micron filter with manual drain 40 micron filter with automatic drain > P51SS GAS REGULATOR Filter n/a Maximum Supply Pressure 250 PSIG (17.3 BAR) 250 PSIG (17.3 BAR) 250 PSIG (17.3 BAR) 250 PSIG (17.3 BAR) 250 PSIG (17.3 BAR) 0-30 PSIG (0-2.1 BAR)0-60 PSIG (0-4.1 BAR)0-100 PSIG (0-6.9 BAR)2-150 PSIG (0.1-10.3BAR) 0-30 PSIG (0-2.1 BAR) 0-60 PSIG (0-4.1 BAR)0-100 PSIG (0-6.9 BAR)2-150 PSIG (0.1-10.3BAR) 0-30 PSIG...

Open the catalog to page 21

NATURAL GAS & PROPANE REGULATOR Superior regulation and excellent stability make the P32 Regulator ideal for lower flow applications.Square head adjustment screw allows for easy in-field calibration. The P32 is available with handwheel adjust- ment, output pressure gauge and/or mounting bracket as options. FEATURESBENEFITS60-mesh screenՕHarmful particles blockedUL listed (Standard P32)ՕNACE construction available > This reliable precision preset regulator is ordered with the exact pressure regulation required. Idealfor areas requiring tamper resistant components or where incidental...
