EDCBDV TEST BENCH High Voltage Test System for Breakdown Voltage Validation Electrical insulation verification for stators, hairpins, enameled wires, and other HV components

WORKSHOP INSTRUMENTS flexibility measurements OVERVIEW For researchers and development engineers, understanding the dielectric limits of materials and components is key to designing reliable and efficient electrical machines. As insulation systems are increasingly pushed to their physical boundaries, accurate and reproducible testing becomes essential. The EDC BDV Test Bench provides a dedicated and controlled environment to precisely assess insulation performance, supporting material characterization, design optimization and early detection of potential weaknesses. Example of BDV test on Hairpin...
