Force & Torque Measurement Products

Product catalog summary

Overview
Mark-10 specializes in the design and manufacture of force and torque measurement instruments, serving industries such as automotive, medical, pharmaceutical, and electronics. All products are made in Copiague, New York, and adhere to NIST calibration standards.

Product Categories

Automotive: Products include ergonomics and switch testing.
Medical/Pharmaceutical: Includes blade sharpness and syringe insertion testing.
Electronics: Features crimp pull strength and keypad testing.
General Manufacturing: Encompasses spring testing and chain tension.

Digital Force and Torque Gauges

Series EG: Suitable for compression and tension with peak memory recall.
Series BG/CG: Advanced gauges with data outputs.
Series MG/MGT: Economical for push, pull, and torque testing.
Series CT: Designed for closure torque testing.

Universal Digital Force/Torque Gauge
The BGI model offers flexibility with interchangeable sensors for diverse applications.

Test Stands

Manual and Motorized: Ensure consistent force or torque application.

Grips and Attachments
Various grips and attachments enhance testing versatility.

Specifications
Specifications include accuracy, sampling rate, and power options. Ordering information is provided for different models and capacities.

Force Sensors

Models: SS, SSM, SJR, SBC, SHP
Capacity: 0.25 lbF to 10000 lbF
Resolution: Up to 0.0001 lbF
Accuracy: ±0.15% to ±0.5% of full scale
Safe Overload: 150% of full scale

Torque Sensors

Models: STJ, STH, STE, STC, STB
Capacity: 10 ozin to 5000 ozin
Resolution: Up to 0.01 ozin
Accuracy: ±0.15% to ±0.7% of full scale
Safe Overload: 150% of full scale

Manual Test Stands

Models: ES10, ES20, ES30, TSB, TSA, TSC, TSF, TST
Capacity: 100 lbF to 1000 lbF

Motorized Test Stands

Models: ESM, ESMH, TSFM500, TSTM
Capacity: 50 lbF to 500 lbF

Key Features Across Models

Precision and repeatability in testing applications.
Modular designs for custom configurations.
Optional features like digital displays.

Mounting Kits
Includes kits for mounting sensors and test stands, enhancing setup flexibility.

Statistical Printer
The DP-1VR Mitutoyo SPC printer provides statistical reports and supports data output via RS-232C.

WinWedge Software
Facilitates data transfer from gauges to Windows applications, offering advanced parsing capabilities.

Accessories
Includes cables and adapters for data transfer and overload protection modules.

Ergonomics Testing Kits
Series MK kits test muscle strength and task requirements, available in 200 lbF and 500 lbF capacities.

Dimensional Drawings
Provides measurements for proper installation and usage of gauges and test stands.
