Overview
Maple Systems' Silver Series Operator Interface Touchscreens (OITs) range from 5.7” to 10.4” and are designed to be powerful, affordable, and feature-rich, offering advanced capabilities at no extra cost.

Specifications and Features
The Silver Series includes models with different screen sizes and resolutions, supporting up to 256 colors. They are equipped with a 200 MHz RISC-based processor, 4 MB flash memory, and a real-time clock. The touchscreens are rated for NEMA 4 IP65 installations and comply with CE standards for electric noise emissions and immunity.

Connectivity
These touchscreens support over 85 controllers from more than 35 manufacturers, ensuring broad compatibility with PLCs. Enhanced models feature Ethernet ports for high-speed data communication, enabling data sharing and monitoring.

Software and Usability
The EZware-500 configuration software allows easy screen design with drag-and-drop technology, bitmap import, and predefined graphics. Users can create up to 1990 screens, utilize multi-language support, and employ animation for dynamic displays.

Data Management
The Silver Series supports data entry through various keypads and offers features like linear scaling, password protection, and floating point format. It includes a macro script feature for creating BASIC-like scripts to interact with PLC registers.

Graphical and Alarm Features
Users can design screens with bar graphs, trend graphs, meters, and XY plots. The system supports unlimited alarms and events, with customizable display options for monitoring and capturing operational anomalies.

Additional Features
The touchscreens offer compact flash support for easy project downloads, a tag database for efficient PLC management, and technical support resources. They are designed for durability and long-term use, with a minimum lifespan of over 1 million keypresses.

Company Overview
Maple Systems specializes in operator interface solutions, offering products that communicate with over 80 families of controllers from leading manufacturers. Their products are known for quality, versatility, and affordability, supporting Modbus and ASCII communications.
