EP 16S ac / 18S ac - EP 20S ac / 22S

EP 16S ac / 18S ac - EP 20S ac / 22S

Product catalog summary

Overview: This document provides technical specifications for the pedestrian-operated electric pallet trucks models EP 16S ac, EP 18S ac, EP 20S ac, and EP 22S, manufactured by MANITOU. These trucks are battery-powered and designed for pedestrian operation.

Specifications:

Power Source: All models are powered by a battery.
Nominal Capacity: Ranges from 1.6 to 2.2 tons depending on the model.
Height to Centre of Gravity: Consistent at 600 mm across all models.
Wheelbase: Varies slightly between models, with the EP 22S having the longest wheelbase.

Weights and Load Distribution:

Weight in Working Order: Ranges from 410 kg to 560 kg.
Axle Loading: Detailed for both laden and unladen conditions, showing front and rear distribution.

Wheels and Tyres:

Tyres: All models use polyurethane tyres.
Wheel Dimensions: Front and rear wheel dimensions are specified, with variations in rear wheel configurations.

Dimensions:

Standard Lift: 125 mm for all models.
Overall Length and Width: Length varies by model, while width remains constant at 680 mm.
Fork Dimensions: Consistent across models, with slight variations in fork pitch.

Performance:

Travel Speed: Slight variations in speed when loaded versus unloaded.
Lifting and Lowering Speeds: Detailed for both loaded and unloaded conditions.
Maximum Slope: Capable of handling slopes up to 10% when laden and 25% when unladen.

Drive and Brake Systems:

Drive Brake: Electromagnetic across all models.
Parking Brake: Handle release mechanism.

Drive Unit:

Drive Motor Power: 1.2 kW for most models, with the EP 22S at 1 kW.
Battery Specifications: Voltage and capacity vary slightly, with the EP 22S having the highest capacity.

Miscellaneous:

Speed Control: Utilizes AC Mosfet Variator, with the EP 22S using Sepex Mosfet Variator.
Sound Level: Average sound level at the driver’s ears is 65 dB(A).

Note: MANITOU reserves the right to improve and modify the products without notice.

Catalog excerpts

EP 16S ac / 18S ac EP 20S ac / 22S Pedestrian operated electric pallet trucks

Open the catalog to page 1

1.1 1.2 1.3 1.4 1.5 1.6 1.8 1.9 Manufacturer Model type Powered by: battery, diesel, petrol, LPG, mains electric Driving method: manual, walk-along, upright, seated, preparation Nominal capacity Height to centre of gravity Distance from fork face to track wheels (in raised pos’n) Wheelbase (drive axle to track wheels), top/bottom position Weights 2.1 Weight in working order 2.2 Axle loading when laden (front/rear) 2.3 Axle loading when unladen (front/rear) Wheels 3.1 3.2 3.3 3.4 3.5 3.6 3.7 Q c x y MANITOU EP 16S ac EP 18S ac EP 20S ac EP 22S Battery Battery Battery Battery Pedestrian Pedestrian...
