- + MARSURF I MOBILE ROUGHNESS MEASUREMENT DEVICES

- 2 MarSurf. Surface Measuring Instruments PRODUCTION-RELATED ROUGHNESS MEASURING. MOBILE WITH MARSURF Wherever surface structures influence the function, processing or appearance of components or products, careful testing is essential. But how can surfaces be tested? At the start of the 20th Century, experts still had to test by eye and touch. A practiced eye can detect features in the ìm range, and even the much maligned thumbnail test delivered perfectly acceptable results. Now however, we live in an age of exchangeable parts, fits and internationalization, where subjective tests like this...

MarSurf. Surface Measurement MarSurf. Surface Measuring Instruments 3 Important Definitions and Surface Parameters 4 Pocket Surf 5 Technical Data for Pocket Surf 5 Pocket Surf Probes 7 Application and Accessories 8 Perthometer 10 MarSurf Workstation 13 Application Aids 14 MarSurf 15 Pick-ups for Mobile Roughness Measuring Instruments 17 Drive Units for Mobile Roughness Measuring Instruments 19 Applications with PFM Drive Units 20 Accessories 21 Perthometer Sets for Mobile Operation 23

4 Pocket Surf. Portable Surface Roughness Gage - Important Definitions and Surface Parameters Real surface separates a body from the surrounding medium. (DIN EN ISO 4287) Stylus instrument enables two-dimensional tracing of a surface. The stylus is traversed normal to the surface at constant speed. (DIN EN ISO 3274) Traced Profile is the enveloping profile of the real surface acquired by means of a stylus instrument. Parameters usually are defined over the sampling length. An average parameter estimate is calculated by taking the arithmetic mean of the parameter etimates from all the individual...

+ Pocket Surf. Portable Surface Roughness Gage 5 Pocket Surf®* the portable surface roughness gage * US-patent no. 4.776.212 • Solidly built, with a durable cast aluminum housing, to provide years of accurate, reliable surface finish gaging. • Can be used to measure any one of four, switchselectable, parameters: Ra , Rmax/Ry , Rz. • Selectable traverse length 1, 3 or 5 cut-offs of 0.8 mm/ .030“ • Operates in any position – horizontal, vertical, and upside down • Pocket-sized economically priced, completely portable instrument which performs traceable surface roughness measurements on a wide variety...

6 Pocket Surf. Portable Surface Roughness Gage - Probing and Traverse Lengths Traverse Evaluation Number of Cutoffs/ Parameters Length (Nominal) Length Switch Position Ra/Ry 2.0 mm/ .075“ 0.8 mm/ .030“ 1 3.5 mm/ .135“ 2.4 mm/ .090“ 3 Ra/Rz/Rmax 5.0 mm/ .195“ 4.0 mm/ .150“ 5 Traverse Speed 5.08 mm/ .2“ per second Cutoff 0.8 mm/ .030“ ASME 2 RC-filter Probe Type Piezoelectric Maximum Stylus Force 15.0 mN / 1500 mfg Power consumer-type alkaline battery, 9 Volt Battery Capacity Approx. 2500 measurements, depending on frequency of use and output option Operating Temperature 10° to 45°C / 50° to 113°...

+ Pocket Surf. Portable Surface Roughness Gage 7 Probes EGH-1019/EGH-1026 For most surface roughness applications. EGH-1026 With a 90° conical diamond stylus, 5 ìm/ .0002“ radius*. EGH-1019 With a 90° conical diamond stylus, 10 ìm/ .0004“ radius. General Purpose Probes EGH-1020-W1 For gaging sharp edges or small O.D.’s where probe is alligned with (in 180° or closed position) to axis of traverse. 90° sapphire chisel, 10 ìm./ .0004“ radius. Transverse Chisel Probe EGH-1021/EGH-1027 For gaging small bores (3,2 mm/ .125“ minimum I.D.) up to a depth of 19 mm/ .75“. EGH-1027 With a 90° conical diamond...

8 Pocket Surf. Portable Surface Roughness Gage Vee-Adapter Kit EAS-2739 attaches to bottom of Pocket Surf unit, permitting convenient, hand-held measurements of hard-to-reach cylindrical surfaces, such as crankshaft journals without having to fix the workpiece. Suitable for parts with diameters from 5.0 mm/ .19” to 125 mm/ 5”. Order no. EAS-2739 Universal Stand EAS-2426 a heavy duty stand equipped with an adjustable bracket to hold the Pocket Surf for measuring of workpieces, up to 213 mm / 8.375 in tall. Order no. EAS-2426 Height Stand EAS-2496 a compact, convenient fixture with a bracket to...

Portable vee fixture EAS-2421 for measuring small parts with outside diameters from 3.1 mm/ .125“ to 25 mm/ 1“ for lengths of 25 mm/ 1“ minimum - includes PS-145 setting pin. Order no. EAS-2421 Bottom Plate EAS-2584 for measuring cylindrical workpieces too short (less than 89 mm/3.5” long) for the “closed” probe position; for workpieces with short O.D.’s from 6.35 mm/ .25” (minimum 38 mm/ 1.5” long). Order no. EAS-2584 EAS-3048 Mounting Bracket for use with height gages for mounting the Pocket Surf to most standard height gages. The bracket includes a rectangular bar that is 11.5 mm x 6.35 mm...

Perthometer M1. The Basic Model for Roughness Measurements Entry-level roughness measurement Features This instrument serves for determining and documenting the most common parameters as per DIN EN ISO/AMSE/prEN 10049 (Ra, Rz, Rmax, and RPc) and according to the JIS Japanese standard (Rz, Ra). With a minimum of keys, the Perthometer M1 is characterized by a multitude of functions. An automatic function enables periodic and aperiodic profiles to be identified and the cutoff to be set according to standards without any prerious test measurement, such that unintentional non-standard measurements...

+ 11 The operation of this instrument is based on the well-proved catalog of functions which enables instrument settings such as measuring conditions, language and record contents to be selected very easily. The Perthometer M2 thus offers a maximum of comfort and flexibility. Compared with the Perthometer M1, this instrument not only meets the requirements for determination and documentation of selected parameters, but also makes most of the parameters and characteristic curves stipulated in DIN/ISO/JIS available for the evaluation of the profile assessed. Moreover, the Perthometer M2 offers...
