MarSurf M 300 Mobile Roughness Measuring Device

MarSurf M 300 Mobile Roughness Measuring Device

Product catalog summary

Introduction
The document introduces the MarSurf M 300, a mobile surface roughness measuring device developed by Mahr. It highlights the importance of precise surface measurement in various industries and the evolution from subjective to objective measurement methods.

MarSurf M 300 Description
The MarSurf M 300 is a highly mobile and high-performance unit designed for on-site roughness measurements. It offers flexibility with up to 4 meters of distance between the evaluation and drive units, allowing for easy measurement of large or cumbersome parts. The device features a large, illuminated color display and Bluetooth technology for cable-free operation.

Software
The MarSurf PS1/M 300 Explorer software secures and documents measurement results and profiles. It allows data to be printed in various formats and simplifies data transfer to a PC.

Drive Unit RD 18
The RD 18 drive unit can connect to the MarSurf M 300 via Bluetooth or cable. It includes integrated testing standards for probe accuracy and features a prismatic underside for precise workpiece positioning.

Application Examples
The document provides examples of the MarSurf M 300's application in industries such as flight engineering, shipbuilding, mechanical engineering, and automotive engineering. It emphasizes the device's capability for upside-down measurements and its flexibility in various environments.

Probes and Accessories
Various probes are available for different measuring tasks, including single-skid and dual-skid pick-ups. The document also lists optional accessories like measuring stands, vee-blocks, and calibration standards.

Technical Data
The MarSurf M 300 uses the stylus method for measurement and supports standards like DIN, ISO, JIS, and ASME. It features an integrated memory for up to 40,000 measurements and offers various language options for user interface.

Set and Accessories
The MarSurf M 300 is delivered as a set in a carrying case, including essential components like the evaluation unit, drive unit, and various accessories for comprehensive measurement tasks.
